113
HCD-RV777D/RV888D/RV999D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
S37 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE/TUNING MODE)
S38 1-762-875-21 SWITCH, KEYBOARD (GAME MIXING)
S39 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S40 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START)
S51 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S52 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD)
S53 1-762-875-21 SWITCH, KEYBOARD (EFFECT ON/OFF)
S54 1-762-875-21 SWITCH, KEYBOARD (TUNING +)
S55 1-762-875-21 SWITCH, KEYBOARD (G/g)
S56 1-762-875-21 SWITCH, KEYBOARD (M ALBUM +)
S57 1-762-875-21 SWITCH, KEYBOARD (m ALBUM –)
S58 1-762-875-21 SWITCH, KEYBOARD (X)
S59 1-762-875-21 SWITCH, KEYBOARD (x)
S60 1-762-875-21 SWITCH, KEYBOARD (TUNING –)
< VIBRATOR >
X101 1-795-058-21 VIBRATOR, CERAMIC (5MHz)
*************************************************************
P-STREAM BOARD
****************
< DIODE >
D134 6-500-809-01 LED SELU5223C-STP15 (ILLUMINATION)
D135 6-500-809-01 LED SELU5223C-STP15 (ILLUMINATION)
D136 6-500-809-01 LED SELU5223C-STP15 (ILLUMINATION)
D137 6-500-809-01 LED SELU5223C-STP15 (ILLUMINATION)
D138 6-500-809-01 LED SELU5223C-STP15 (ILLUMINATION)
D139 6-500-809-01 LED SELU5223C-STP15 (ILLUMINATION)
< RESISTOR >
R62 1-216-837-11 METAL CHIP 22K 5% 1/10W
R119 1-216-864-11 SHORT CHIP 0
R120 1-216-864-11 SHORT CHIP 0
< SWITCH >
S102 1-418-632-11 ENCODER, ROTARY (MASTER VOLUME)
S701 1-786-289-11 SWITCH, DETECTION (l – EQ + L)
*************************************************************
A-4728-690-A RF BOARD, COMPLETE
*******************
< CAPACITOR >
C001 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C002 1-124-779-00 ELECT CHIP 10uF 20% 16V
C003 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C004 1-124-779-00 ELECT CHIP 10uF 20% 16V
C005 1-128-993-21 ELECT CHIP 22uF 20% 10V
C006 1-128-993-21 ELECT CHIP 22uF 20% 10V
C008 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C009 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C010 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C011 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C014 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C015 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C016 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C017 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C018 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C019 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C020 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C021 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C022 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C023 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C024 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C027 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C029 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C030 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C031 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C032 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C033 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C034 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C036 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C037 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C038 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C039 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C040 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C041 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C042 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C049 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C050 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C051 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C052 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN001 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN002 1-784-836-21 CONNECTOR, FFC (LIF(NON-ZIF)) 29P
CN003 1-784-861-21 CONNECTOR, FFC (LIF(NON-ZIF)) 9P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D002 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC001 6-703-922-01 IC SP3723CAF0PM
IC003 6-703-921-01 IC TL343IDBVR
< COIL >
L001 1-412-031-11 INDUCTOR 47uH
L002 1-412-031-11 INDUCTOR 47uH
< TRANSISTOR >
Q001 8-729-903-46 TRANSISTOR 2SB1132-P
Q002 8-729-903-46 TRANSISTOR 2SB1132-P
< RESISTOR >
R001 1-218-668-11 METAL CHIP 100 0.5% 1/10W
R003 1-216-803-11 METAL CHIP 33 5% 1/10W
R004 1-216-803-11 METAL CHIP 33 5% 1/10W
PANEL RFP-STREAM
