HCD-RV777D/RV888D/RV999D
SENSOR
RF
SURROUND AMP
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R005 1-216-841-11 METAL CHIP 47K 5% 1/10W
R006 1-216-817-11 METAL CHIP 470 5% 1/10W
R007 1-216-803-11 METAL CHIP 33 5% 1/10W
R008 1-216-803-11 METAL CHIP 33 5% 1/10W
R009 1-216-841-11 METAL CHIP 47K 5% 1/10W
R010 1-216-817-11 METAL CHIP 470 5% 1/10W
R011 1-216-864-11 SHORT CHIP 0
R012 1-216-864-11 SHORT CHIP 0
R013 1-216-864-11 SHORT CHIP 0
R014 1-216-864-11 SHORT CHIP 0
R015 1-216-864-11 SHORT CHIP 0
R016 1-216-864-11 SHORT CHIP 0
R017 1-216-864-11 SHORT CHIP 0
R018 1-216-864-11 SHORT CHIP 0
R019 1-216-864-11 SHORT CHIP 0
R020 1-216-864-11 SHORT CHIP 0
R021 1-216-864-11 SHORT CHIP 0
R022 1-216-813-11 METAL CHIP 220 5% 1/10W
R023 1-216-820-11 METAL CHIP 820 5% 1/10W
R024 1-216-864-11 SHORT CHIP 0
R025 1-216-809-11 METAL CHIP 100 5% 1/10W
R026 1-218-718-11 METAL CHIP 12K 0.5% 1/10W
R027 1-216-864-11 SHORT CHIP 0
R028 1-216-864-11 SHORT CHIP 0
R029 1-216-864-11 SHORT CHIP 0
R031 1-216-809-11 METAL CHIP 100 5% 1/10W
R033 1-216-845-11 METAL CHIP 100K 5% 1/10W
R034 1-216-817-11 METAL CHIP 470 5% 1/10W
R035 1-216-864-11 SHORT CHIP 0
R041 1-216-821-11 METAL CHIP 1K 5% 1/10W
R046 1-216-833-11 METAL CHIP 10K 5% 1/10W
R047 1-216-839-11 METAL CHIP 33K 5% 1/10W
R091 1-218-913-11 METAL CHIP 560K 0.5% 1/10W
*************************************************************
1-687-132-12 SENSOR BOARD
**************
< CONNECTOR >
CN731 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE) 3P
< IC >
IC731 6-600-022-01 IC RPI-576
*************************************************************
SIRCS BOARD
************
< CAPACITOR >
C205 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN113 1-816-423-11 SOCKET, CONNECTOR 3P
< IC >
IC202 6-600-174-01 IC RPM7240-H4 (IR)
*************************************************************
SUB TRANS BOARD
*****************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
0 C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
C902 1-126-768-11 ELECT 2200uF 20% 16V
C903 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN902 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
(AUS,AR,MX)
CN902 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(EXCEPT AUS,AR,MX)
CN903 1-506-468-11 PIN, CONNECTOR 3P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
0 D902 6-500-522-11 DIODE 10EDB40-TA2B5
0 D903 6-500-522-11 DIODE 10EDB40-TA2B5
0 D904 6-500-522-11 DIODE 10EDB40-TA2B5
0 D905 6-500-522-11 DIODE 10EDB40-TA2B5
< IC >
IC901 6-701-760-01 IC uPC3504AHF
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R901 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-247-791-11 CARBON 22 5% 1/4W
< RELAY >
0 RY901 1-755-467-11 RELAY (POWER)
< SWITCH >
0 S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(EXCEPT AUS,AR,MX)
< TRANSFORMER >
0 T901 1-437-677-11 TRANSFORMER, POWER
*************************************************************
A-1053-983-A SURROUND AMP BOARD, COMPLETE (RV888D)
A-4751-859-A SURROUND AMP BOARD, COMPLETE (RV999D)
******************************
7-685-872-09 SCREW +BVTT 3X8 (S) (RV888D/RV999D)
< CAPACITOR >
C301 1-126-964-11 ELECT 10uF 20% 50V
(RV888D/RV999D)
C302 1-162-294-31 CERAMIC 0.001uF 10% 50V
(RV888D/RV999D)
C303 1-162-286-31 CERAMIC 220PF 10% 50V
(RV888D/RV999D)
SUB TRANSSIRCS
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
