45
HCD-RV777D/RV888D/RV999D
Pin No. Pin Name I/O Pin Description
56 HP-SW I Headphones in/out select signal input (L: out, H: in)
57 MIC-SW I Microphone in/out select signal input (L: out, H: in)
58 A-TRG O Trigger out ON/OFF select signal output (deck A) (L: OFF, H: ON)
59 B-TRG O Trigger out ON/OFF select signal output (deck B) (L: OFF, H: ON)
60 A-SHUT-IN I Reel pulse signal input (deck A)
61 B-SHUT-IN I Reel pulse signal input (deck B)
62 VCC — Power supply pin (+3.3 V)
63 NO-USE I Not used in this set. (Open)
64 VSS — Ground pin
65 CAPM-CONT O Capstan motor ON/OFF select signal output (L: OFF, H: ON)
66 B-REC.FWD I REC (FWD) switch in signal input (deck B) (active L)
67 B-REC.REV I REC (REV) switch in signal input (deck B) (active L)
68 A-HALF I Half in signal input (deck A) (active L)
69 B-HALF I Half in signal input (deck B) (active L)
70 A-PLAY I Playback switch in signal input (deck A) (active L)
71 B-PLAY I Playback switch in signal input (deck B) (active L)
72 AMS-IN I AMS in select signal input (L: without music, H: with music)
73 DISPLAY-KEY I Display key signal input (active L)
74 POWER-KEY I Power key signal input (active L)
75, 76 NO-USE I Not used in this set. (Fixed at L.)
77 BIAS O Bias ON/OFF select signal output (L: OFF, H: ON)
78 AMS MUTE O AMS mute select signal output
79 TC-RELAY O Tape REC/PB control signal output (H: REC, L: PB (other))
80 PB-MUTE O PB mute select signal output (L: ON, H: OFF)
81 REC-MUTE O REC mute select signal output (L: ON, H: OFF) Not used in this set. (Open)
82 NO-USE I Not used in this set. (Fixed at L.)
83 LINEOUT-MUTE O MD (VIDEO) mute ON/OFF select signal output (L: ON, H: OFF)
84 LINE-MUTE O TA line mute ON/OFF select signal output (L: ON, H: OFF)
85 STK-MUTE O STK mute ON/OFF select signal output (L: ON, H: OFF)
86 PROTECT I Protect ON/OFF select signal input (L: ON, H: OFF)
87 STB-RELAY O Standby relay ON/OFF select signal output (L: OFF, H: ON)
88 FRONT-RELAY O Front speaker relay ON/OFF select signal output (L: OFF, H: ON)
89 REAR-RELAY O Rear/center/sub woofer speaker relay ON/OFF select signal output (L: OFF, H: ON)
90 VACS-IN2 I VACS in 2 signal input (thermal VACS)
91 VACS-IN1 ILLUMI-IN I VACS & Illumi in 1 signal input (A/D)
92 FAN CONT O Fan motor control signal output (L: OFF, H: 300 msec)
93 FAN ON/OFF O Fan motor ON/OFF select signal output (L: ON, H: OFF)
94 MODEL-IN I Model in signal input (A/D)
95 SPEC-IN I Destination in signal input (A/D)
96 AVSS — Analog ground pin
97 NO-USE I Not used in this set. (Fixed at L.)
98 V.REF — AV reference voltage pin (+3.3 V)
99 AVCC — Power supply pin (+3.3 V)
100 S-IN I Serial in signal input
