Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE33/SHAKE77
104
R2067 1-216-814-11 METAL CHIP 270 5% 1/10W
(SHAKE77)
R2068 1-216-815-11 METAL CHIP 330 5% 1/10W
(SHAKE77)
R2069 1-216-801-11 METAL CHIP 22 5% 1/10W
(SHAKE77)
R2070 1-216-806-11 METAL CHIP 56 5% 1/10W
(SHAKE77)
R2071 1-216-803-11 METAL CHIP 33 5% 1/10W
(SHAKE77)
R2072 1-216-801-11 METAL CHIP 22 5% 1/10W
(SHAKE77)
R2073 1-216-815-11 METAL CHIP 330 5% 1/10W
(SHAKE77)
R2074 1-216-801-11 METAL CHIP 22 5% 1/10W
(SHAKE77)
R2077 1-216-809-11 METAL CHIP 100 5% 1/10W
(SHAKE77)
R2078 1-216-809-11 METAL CHIP 100 5% 1/10W
(SHAKE77)
R2079 1-216-809-11 METAL CHIP 100 5% 1/10W
(SHAKE77)
R2080 1-216-809-11 METAL CHIP 100 5% 1/10W
(SHAKE77)
R2081 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
(SHAKE77)
R2082 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(SHAKE77)
R2083 1-218-446-11 METAL CHIP 1 5% 1/10W
(SHAKE77)
R2084 1-216-815-11 METAL CHIP 330 5% 1/10W
(SHAKE77)
R2085 1-216-815-11 METAL CHIP 330 5% 1/10W
(SHAKE77)
R2086 1-216-815-11 METAL CHIP 330 5% 1/10W
(SHAKE77)
R2087 1-216-815-11 METAL CHIP 330 5% 1/10W
(SHAKE77)
R2095 1-216-815-11 METAL CHIP 330 5% 1/10W
(SHAKE77)
< SWITCH >
S2000 1-762-875-21 SWITCH, TACTILE (
Z
OPEN/CLOSE) (SHAKE77)
S2001 1-762-875-21 SWITCH, TACTILE
(
Z
OPEN/CLOSE) (SHAKE33) / (LED PATTERN)
(SHAKE77)
S2002 1-762-875-21 SWITCH, TACTILE (LED PATTERN) (SHAKE33) /
(LED COLOR) (SHAKE77)
S2003 1-762-875-21 SWITCH, TACTILE
(LED COLOR) (SHAKE33) / (OPTIONS) (SHAKE77)
S2004 1-762-875-21 SWITCH, TACTILE
(OPTIONS) (SHAKE33) / (
+
) (SHAKE77)
S2005 1-762-875-21 SWITCH, TACTILE (
+
) (SHAKE33) /
(TUNING+
M>
) (SHAKE77)
S2006 1-762-875-21 SWITCH, TACTILE
(TUNING+
M>
) (SHAKE33) /
(
Š
) (SHAKE77)
S2007 1-762-875-21 SWITCH, TACTILE
(
Š
) (SHAKE33) / (CD) (SHAKE77)
S2008 1-762-875-21 SWITCH, TACTILE
(CD) (SHAKE33) / (USB/USB SELECT) (SHAKE77)
S2009 1-762-875-21 SWITCH, TACTILE
(USB/USB SELECT) (SHAKE33) /
(TUNER/BAND) (SHAKE77)
S2010 1-762-875-21 SWITCH, TACTILE (TUNER/BAND) (SHAKE33) /
(AUDIO IN) (SHAKE77)
S2011 1-762-875-21 SWITCH, TACTILE (AUDIO IN) (SHAKE33)
< TRANSFORMER >
T2000 1-697-233-11 DC-DC CONVERTER TRANSFORMER
(SHAKE77)
T2001 1-697-233-11 DC-DC CONVERTER TRANSFORMER
(SHAKE33)
*************************************************************
MIC BOARD
**********
< CAPACITOR >
C2201 1-124-584-00 ELECT 100uF 20% 6.3V
(SHAKE33)
C2202 1-115-867-11 ELECT 0.1uF 20% 50V
(SHAKE77)
C2203 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
(SHAKE33)
C2203 1-126-795-11 ELECT 10uF 20% 50V
(SHAKE77)
C2204 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
(SHAKE77)
*
C2205 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
(SHAKE33)
C2206 1-115-867-11 ELECT 0.1uF 20% 50V
(SHAKE77)
C2206 1-124-584-00 ELECT 100uF 20% 6.3V
(SHAKE33)
C2207 1-124-463-00 ELECT 0.1uF 20% 50V
(SHAKE77)
C2208 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
(SHAKE77)
C2208 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE33)
C2209 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
(SHAKE33)
C2209 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
(SHAKE77)
C2210 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
(SHAKE77)
C2211 1-126-176-11 ELECT 220uF 20% 10V
(SHAKE77)
*
C2212 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
(SHAKE33)
C2212 1-126-176-11 ELECT 220uF 20% 10V
(SHAKE77)
C2213 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
(SHAKE77)
C2213 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE33)
C2214 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
(SHAKE77)
C2215 1-124-584-00 ELECT 100uF 20% 6.3V
(SHAKE77)
C2217 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
(SHAKE77)
C2219 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(SHAKE77)
*
C2220 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
(SHAKE77)
C2221 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
(SHAKE77)
FL
MIC
