Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE33/SHAKE77
105
C2222 1-124-584-00 ELECT 100uF 20% 6.3V
(SHAKE77)
C2224 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE77)
C2225 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
(SHAKE77)
* C2229 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
(SHAKE77)
C2231 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE77)
C2233 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
(SHAKE77)
C2234 1-124-257-00 ELECT 2.2uF 20% 50V
(SHAKE77)
C2236 1-124-257-00 ELECT 2.2uF 20% 50V
(SHAKE77)
C2239 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
(SHAKE77)
C2240 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
(SHAKE77)
C2241 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
(SHAKE77)
C2242 1-115-872-11 ELECT 2.2uF 20% 50V
(SHAKE77)
C2243 1-124-257-00 ELECT 2.2uF 20% 50V
(SHAKE77)
C2244 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(SHAKE77)
< CONNECTOR >
CN2203 1-822-423-11 CONNECTOR, USB (A) (
A PLAY) (SHAKE33)
CN2204 1-822-423-11 CONNECTOR, USB (A) ( B REC/PLAY)
CN2205 1-822-423-11 CONNECTOR, USB (A) (
A PLAY) (SHAKE77)
CN2207 1-227-452-11 RES, VAR, CARBON 50K
(MIC LEVEL MIN MAX) (SHAKE77)
< DIODE >
D2201 6-502-970-01 DI DZ2J068M0L
D2202 6-502-970-01 DI DZ2J068M0L
D2203 6-502-970-01 DI DZ2J068M0L
D2204 6-502-970-01 DI DZ2J068M0L
D2205 6-502-970-01 DI DZ2J068M0L
D2206 6-502-970-01 DI DZ2J068M0L
D2207 6-502-961-01 DI DA2J10100L (SHAKE77)
D2208 6-500-400-01 DIODE BAV99-215 (SHAKE33)
D2209 6-500-400-01 DIODE BAV99-215 (SHAKE77)
D2210 6-500-400-01 DIODE BAV99-215 (SHAKE33)
D2211 6-500-400-01 DIODE BAV99-215
D2212 6-500-400-01 DIODE BAV99-215
D2213 6-500-400-01 DIODE BAV99-215
D2214 6-500-400-01 DIODE BAV99-215
D2215 6-500-400-01 DIODE BAV99-215 (SHAKE77)
D2216 6-500-400-01 DIODE BAV99-215 (SHAKE77)
D2217 6-500-400-01 DIODE BAV99-215 (SHAKE77)
< IC >
IC2201 8-759-909-71 IC BA4558F (SHAKE77)
< JACK >
J2201 1-822-757-11 JACK (LARGE TYPE) (MIC) (SHAKE77)
< JUMPER >
JC011 1-216-295-91 SHORT CHIP 0 (SHAKE77)
JC012 1-216-295-91 SHORT CHIP 0 (SHAKE77)
JC013 1-216-295-91 SHORT CHIP 0 (SHAKE77)
JC014 1-216-295-91 SHORT CHIP 0 (SHAKE77)
JC015 1-216-295-91 SHORT CHIP 0 (SHAKE77)
JC016 1-216-295-91 SHORT CHIP 0 (SHAKE77)
JC017 1-216-295-91 SHORT CHIP 0 (SHAKE77)
JC018 1-216-295-91 SHORT CHIP 0 (SHAKE77)
< JUMPER RESISTOR >
JR2201 1-216-864-11 SHORT CHIP 0
JR2202 1-216-864-11 SHORT CHIP 0
JR2204 1-216-864-11 SHORT CHIP 0
JR2205 1-216-864-11 SHORT CHIP 0
JR2207 1-216-864-11 SHORT CHIP 0 (SHAKE77)
JR2208 1-216-864-11 SHORT CHIP 0 (SHAKE77)
JR2250 1-216-296-11 SHORT CHIP 0 (SHAKE33)
JR2251 1-216-864-11 SHORT CHIP 0 (SHAKE33)
JR2252 1-216-296-11 SHORT CHIP 0 (SHAKE33)
JR2253 1-216-864-11 SHORT CHIP 0 (SHAKE33)
JR2254 1-216-296-11 SHORT CHIP 0 (SHAKE33)
JR2255 1-216-864-11 SHORT CHIP 0 (SHAKE33)
JR2256 1-216-296-11 SHORT CHIP 0 (SHAKE33)
JR2257 1-216-864-11 SHORT CHIP 0 (SHAKE33)
JR2258 1-216-296-11 SHORT CHIP 0 (SHAKE33)
JR2259 1-216-296-11 SHORT CHIP 0 (SHAKE33)
JR2261 1-216-296-11 SHORT CHIP 0 (SHAKE33)
JR2262 1-216-864-11 SHORT CHIP 0 (SHAKE33)
< TRANSISTOR >
Q2201 6-552-891-01 TR LSAR523UBFS8TL (SHAKE77)
Q2202 6-552-967-01 TR RHK005N03T146 (SHAKE77)
< RESISTOR >
R2201 1-216-857-11 METAL CHIP 1M 5% 1/10W
(SHAKE77)
R2202 1-216-857-11 METAL CHIP 1M 5% 1/10W
(SHAKE77)
R2203 1-216-817-11 METAL CHIP 470 5% 1/10W
(SHAKE77)
R2204 1-216-849-11 METAL CHIP 220K 5% 1/10W
(SHAKE77)
R2205 1-216-845-11 METAL CHIP 100K 5% 1/10W
(SHAKE77)
R2206 1-216-809-11 METAL CHIP 100 5% 1/10W
(SHAKE77)
R2207 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(SHAKE77)
R2208 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SHAKE77)
R2209 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SHAKE77)
R2210 1-216-845-11 METAL CHIP 100K 5% 1/10W
(SHAKE77)
R2211 1-216-845-11 METAL CHIP 100K 5% 1/10W
(SHAKE77)
R2212 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SHAKE77)
R2213 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SHAKE77)
MIC
