Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKEX1/SHAKEX3/SHAKEX7
81
R1165 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1166 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1167 1-216-837-11 METAL CHIP 22K 5% 1/10W
(SHAKEX7)
R1168 1-218-973-11 METAL CHIP 47K 5% 1/16W
R1169 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1170 1-216-791-11 METAL CHIP 3.3 5% 1/10W
(SHAKEX7)
R1171 1-218-446-11 METAL CHIP 1 5% 1/10W
(SHAKEX7)
R1172 1-216-791-11 METAL CHIP 3.3 5% 1/10W
(SHAKEX7)
R1173 1-218-446-11 METAL CHIP 1 5% 1/10W
(SHAKEX7)
R1174 1-218-446-11 METAL CHIP 1 5% 1/10W
R1175 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1176 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1177 1-218-446-11 METAL CHIP 1 5% 1/10W
R1178 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1179 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1180 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1181 1-216-839-11 METAL CHIP 33K 5% 1/10W
(SHAKEX7)
R1181 1-216-847-11 METAL CHIP 150K 5% 1/10W
(SHAKEX1/SHAKEX3)
R1182 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1185 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1186 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1187 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SHAKEX7)
R1188 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(SHAKEX7)
R1189 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(SHAKEX7)
R1190 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(SHAKEX7)
R1193 1-216-864-11 SHORT CHIP 0
R1194 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R1195 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
(SHAKEX7)
R1197 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1198 1-216-857-11 METAL CHIP 1M 5% 1/10W
(SHAKEX7)
R1199 1-216-857-11 METAL CHIP 1M 5% 1/10W
(SHAKEX7)
R1200 1-216-857-11 METAL CHIP 1M 5% 1/10W
R1201 1-216-857-11 METAL CHIP 1M 5% 1/10W
R1206 1-216-809-11 METAL CHIP 100 5% 1/10W
(SHAKEX7)
R1207 1-216-809-11 METAL CHIP 100 5% 1/10W
R1213 1-216-864-11 SHORT CHIP 0
R1215 1-216-864-11 SHORT CHIP 0 (SHAKEX7)
R1221 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1222 1-216-295-91 SHORT CHIP 0
R1225 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1242 1-216-864-11 SHORT CHIP 0 (SHAKEX7)
R1244 1-216-864-11 SHORT CHIP 0 (SHAKEX1/SHAKEX3)
R1246 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R1247 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R1248 1-216-845-11 METAL CHIP 100K 5% 1/10W
(SHAKEX7)
R1248 1-216-864-11 SHORT CHIP 0 (SHAKEX1/SHAKEX3)
R1251 1-218-827-11 METAL CHIP 150 0.5% 1/10W
(SHAKEX7)
R1252 1-218-827-11 METAL CHIP 150 0.5% 1/10W
(SHAKEX7)
R1253 1-216-845-11 METAL CHIP 100K 5% 1/10W
(SHAKEX7)
R1255 1-216-864-11 SHORT CHIP 0 (SHAKEX7)
R1256 1-216-864-11 SHORT CHIP 0 (SHAKEX7)
R1257 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
(SHAKEX7)
R1258 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
(SHAKEX7)
R1259 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
(SHAKEX1/SHAKEX3)
R1265 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
(SHAKEX7)
R1266 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R1267 1-216-864-11 SHORT CHIP 0
< TERMINAL >
TB1000 1-854-077-11 SPEAKER TERMINAL JACK
(RIGHT SPEAKER IMPEDANCE USE 8 Ω)
(SHAKEX7)
TB1002 1-854-001-21 TERMINAL BOARD (SPEAKER)
(SPEAKERS R/L IMPEDANCE USE 4Ω)
(SHAKEX1/SHAKEX3)
TB1003 1-854-077-11 SPEAKER TERMINAL JACK
(LEFT SPEAKER IMPEDANCE USE 8 Ω)
(SHAKEX7)
< THERMISTOR >
0 TH1001 1-812-124-11 THERMISTOR, POSITIVE (SHAKEX7)
0 TH1002 1-812-124-11 THERMISTOR, POSITIVE
*************************************************************
A-2061-685-A DISPLAY BOARD, COMPLETE
***********************
< CAPACITOR >
C2066 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C2068 1-116-078-11 CERAMIC CHIP 1uF 10% 50V
C2069 1-116-078-11 CERAMIC CHIP 1uF 10% 50V
C2070 1-116-078-11 CERAMIC CHIP 1uF 10% 50V
C2073 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C2074 1-116-078-11 CERAMIC CHIP 1uF 10% 50V
C2075 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2076 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2077 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2078 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2104 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C2105 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2108 1-114-814-11 CERAMIC CHIP 0.33uF 10% 25V
C2109 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2111 1-126-791-11 ELECT 10uF 20% 35V
C2122 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C2125 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2126 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2127 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN1006 1-779-544-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
4CH DAMP DISPLAY
Ver. 1.1
