Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKEX1/SHAKEX3/SHAKEX7
82
< DIODE >
D2008 6-500-400-01 DIODE BAV99-215
D2009 6-500-400-01 DIODE BAV99-215
D2010 6-503-042-01 DI DZ2J330M0L
D2015 6-503-605-01 DI UDZVTE-172.0B
< IC >
IC1003 6-722-126-01 IC LM7806L-T2Q-1
< JUMPER RESISTOR >
JR2010 1-216-296-11 SHORT CHIP 0
JR2011 1-216-296-11 SHORT CHIP 0
JR2012 1-216-296-11 SHORT CHIP 0
JR2014 1-216-296-11 SHORT CHIP 0
< FLUORESCENT INDICATOR TUBE >
ND2001 1-483-519-11 VACUUM FLUORESCENT DISPLAY
< TRANSISTOR >
Q2006 6-553-291-01 TR BC817DPN
< RESISTOR >
R2084 1-216-809-11 METAL CHIP 100 5% 1/10W
R2085 1-216-809-11 METAL CHIP 100 5% 1/10W
R2086 1-216-809-11 METAL CHIP 100 5% 1/10W
R2094 1-216-839-11 METAL CHIP 33K 5% 1/10W
R2095 1-216-797-11 METAL CHIP 10 5% 1/10W
R2096 1-216-797-11 METAL CHIP 10 5% 1/10W
R2097 1-216-843-11 METAL CHIP 68K 5% 1/10W
R2098 1-216-809-11 METAL CHIP 100 5% 1/10W
R2099 1-216-809-11 METAL CHIP 100 5% 1/10W
R2100 1-216-809-11 METAL CHIP 100 5% 1/10W
R2101 1-216-806-11 METAL CHIP 56 5% 1/10W
R2102 1-216-806-11 METAL CHIP 56 5% 1/10W
R2111 1-216-806-11 METAL CHIP 56 5% 1/10W
R2134 1-216-802-11 METAL CHIP 27 5% 1/10W
R2135 1-216-802-11 METAL CHIP 27 5% 1/10W
R2136 1-216-802-11 METAL CHIP 27 5% 1/10W
R2137 1-216-802-11 METAL CHIP 27 5% 1/10W
R2138 1-216-802-11 METAL CHIP 27 5% 1/10W
R2140 1-216-802-11 METAL CHIP 27 5% 1/10W
R2141 1-216-802-11 METAL CHIP 27 5% 1/10W
R2142 1-216-802-11 METAL CHIP 27 5% 1/10W
R2143 1-216-802-11 METAL CHIP 27 5% 1/10W
R2144 1-216-802-11 METAL CHIP 27 5% 1/10W
R2146 1-216-802-11 METAL CHIP 27 5% 1/10W
R2147 1-216-802-11 METAL CHIP 27 5% 1/10W
R2148 1-216-802-11 METAL CHIP 27 5% 1/10W
R2149 1-216-802-11 METAL CHIP 27 5% 1/10W
R2150 1-216-802-11 METAL CHIP 27 5% 1/10W
*************************************************************
IR BOARD
********
< CAPACITOR >
C001 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1802 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
< IC >
IC010 6-600-768-01 IC PNA4823M03S0
< RESISTOR >
R001 1-216-801-11 METAL CHIP 22 5% 1/10W
*************************************************************
LED BAR BOARD
*************
< CONNECTOR >
CN1004 1-779-548-21 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< DIODE >
D001 6-504-214-01 DI HL-364W650MZ-T
D002 6-504-214-01 DI HL-364W650MZ-T
D003 6-504-214-01 DI HL-364W650MZ-T
D004 6-504-214-01 DI HL-364W650MZ-T
D005 6-504-214-01 DI HL-364W650MZ-T
D006 6-504-214-01 DI HL-364W650MZ-T
D007 6-504-214-01 DI HL-364W650MZ-T
*************************************************************
MIC BOARD
*********
< CAPACITOR >
C2202 1-115-867-11 ELECT 0.1uF 20% 50V
C2203 1-126-795-11 ELECT 10uF 20% 50V
C2204 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2206 1-115-867-11 ELECT 0.1uF 20% 50V
C2207 1-124-463-00 ELECT 0.1uF 20% 50V
C2208 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C2209 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C2210 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2211 1-126-176-11 ELECT 220uF 20% 10V
C2212 1-126-176-11 ELECT 220uF 20% 10V
C2213 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2214 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2219 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C2221 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C2233 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2234 1-124-257-00 ELECT 2.2uF 20% 50V
C2235 1-124-257-00 ELECT 2.2uF 20% 50V
C2236 1-124-257-00 ELECT 2.2uF 20% 50V
C2238 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2239 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2240 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2241 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2242 1-115-872-11 ELECT 2.2uF 20% 50V
C2243 1-124-257-00 ELECT 2.2uF 20% 50V
C2244 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN1101 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D2207 6-502-961-01 DI DA2J10100L
D2216 6-500-400-01 DIODE BAV99-215
D2217 6-500-400-01 DIODE BAV99-215
IR LED BAR MICDISPLAY
Ver. 1.3
