Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKEX1/SHAKEX3/SHAKEX7
83
< IC >
IC2201 8-759-909-71 IC BA4558F
< JACK >
J2201 1-822-967-12 JACK (MIC 2)
J2202 1-822-967-12 JACK (MIC 1)
< JUMPER >
JC013
1-216-295-91 SHORT CHIP 0
< JUMPER RESISTOR >
JR2200 1-216-296-11 SHORT CHIP 0
JR2201 1-216-296-11 SHORT CHIP 0
JR2202 1-216-296-11 SHORT CHIP 0
JR2203 1-216-296-11 SHORT CHIP 0
JR2204 1-216-296-11 SHORT CHIP 0
< TRANSISTOR >
Q2201 6-552-891-01 TR LSAR523UBFS8TL
Q2202 6-552-967-01 TR RHK005N03T146
< RESISTOR >
R2201 1-216-857-11 METAL CHIP 1M 5% 1/10W
R2202 1-216-857-11 METAL CHIP 1M 5% 1/10W
R2203 1-216-817-11 METAL CHIP 470 5% 1/10W
R2204 1-216-849-11 METAL CHIP 220K 5% 1/10W
R2205 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2206 1-216-809-11 METAL CHIP 100 5% 1/10W
R2207 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R2208 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2209 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2210 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2211 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2212 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2213 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2214 1-216-839-11 METAL CHIP 33K 5% 1/10W
R2215 1-216-839-11 METAL CHIP 33K 5% 1/10W
R2216 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2217 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2218 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2219 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2220 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2501 1-469-670-21 FERRITE, EMI (SMD) (2012)
R2502 1-469-670-21 FERRITE, EMI (SMD) (2012)
*************************************************************
A-2074-163-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX7: AR, LA9)
A-2074-164-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX7: MY, TH)
A-2074-165-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX7: E4, EA)
A-2074-166-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX3: AR, LA9)
A-2074-168-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX3: AEP, UK)
A-2074-169-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX3: RU)
A-2074-170-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX3: MY, TH)
A-2074-171-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX3: E4, EA)
A-2077-950-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX1: AEP, UK)
A-2077-951-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX1: RU)
A-2077-952-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX1: AUS)
A-2077-953-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX1: MY, TH)
A-2077-954-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX1: E4, EA)
A-2077-955-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX7: E12)
A-2077-957-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX1: AR, LA9)
A-2084-481-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (SHAKEX3: AUS)
**************
< CAPACITOR >
* C003 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C004 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C005 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C006 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C010 1-118-358-11 CERAMIC CHIP 100PF 1% 50V
C011 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C013 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C014 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C017 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C018 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C019 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C021 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C024 1-112-797-11 ELECT CHIP 470uF 20% 25V
C030 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C032 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C034 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C035 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C036 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C039 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C040 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C049 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C050 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C051 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
* C052 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C053 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C057 1-117-681-11 ELECT CHIP 100uF 20% 16V
C062 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C064 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
* C065 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C066 1-165-492-21 ELECT CHIP 100uF 20% 10V
C067 1-165-492-21 ELECT CHIP 100uF 20% 10V
* C068 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C071 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C072 1-165-492-21 ELECT CHIP 100uF 20% 10V
C073 1-165-492-21 ELECT CHIP 100uF 20% 10V
C074 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C075 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C076 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C077 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C078 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
MIC MOTHERBOARD
Ver. 1.3
