Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKEX1/SHAKEX3/SHAKEX7
86
* C665 1-116-727-11 CERAMIC CHIP 2.2uF 10% 16V
C666 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C667 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C669 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C670 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C672 1-124-779-00 ELECT CHIP 10uF 20% 16V
C673 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C674 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C678 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C679 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C689 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C691 1-124-779-00 ELECT CHIP 10uF 20% 16V
C692 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C694 1-216-864-11 SHORT CHIP 0
C695 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C696 1-124-779-00 ELECT CHIP 10uF 20% 16V
C699 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C706 1-216-864-11 SHORT CHIP 0
C726 1-128-392-11 ELECT CHIP 470uF 20% 6.3V
C766 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C767 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C904 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C905 1-165-492-21 ELECT CHIP 100uF 20% 10V
C906 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C917 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C922 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C928 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
C930 1-164-870-11 CERAMIC CHIP 68PF 5% 50V
C931 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C932 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
C933 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C934 1-118-399-11 CERAMIC CHIP 0.0022uF 10% 50V
C935 1-164-840-11 CERAMIC CHIP 1PF 0.25PF 50V
C936 1-118-399-11 CERAMIC CHIP 0.0022uF 10% 50V
C937 1-164-840-11 CERAMIC CHIP 1PF 0.25PF 50V
* C938 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C941 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
* C943 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C966 1-116-744-11 CERAMIC CHIP 0.22uF 10% 10V
C980 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C986 1-124-779-00 ELECT CHIP 10uF 20% 16V
C987 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C988 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C989 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C990 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C991 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C994 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C995 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C996 1-116-732-11 CERAMIC CHIP 2.2uF 20% 6.3V
C997 1-116-732-11 CERAMIC CHIP 2.2uF 20% 6.3V
C998 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1000 1-124-779-00 ELECT CHIP 10uF 20% 16V
C1001 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C1002 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1003 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN001 1-816-296-21 PIN, CONNECTOR (PC BOARD) 9P
CN101 1-844-158-11 PIN, CONNECTOR (PC BOARD) 5P
(FOR SER
VICE USE)
CN102 1-820-825-81 CONNECTOR, FFC/FPC (LIF) 10P
CN105 1-844-279-11 FFC ST CONNECTOR (NON-ZIF) 6P
CN109 1-820-119-51 CONNECTOR, FFC/FPC 21P
CN116 1-820-119-51 CONNECTOR, FFC/FPC 21P
CN302 1-844-191-11 FFC ST CONNECTOR (NON-ZIF) 24P
CN303 1-794-362-51 CONNECTOR, FFC/FPC 5P
CN401 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN501 1-843-881-11 PIN, CONNECTOR (PC BOARD) 4P
(LED SPEAKER R)
CN502 1-843-881-11 PIN, CONNECTOR (PC BOARD) 4P
(LED SPEAKER L)
CN601 1-843-888-11 PIN, CONNECTOR (PC BOARD) 4P
CN2001 1-774-730-21 PIN, CONNECTOR (PC BOARD) 3P
(ANTENNA FM/AM)
< DIODE >
D102 6-502-961-01 DI DA2J10100L
D401 8-719-069-29 DIODE RB520S-30FJTE61
D402 8-719-069-29 DIODE RB520S-30FJTE61
D571 6-502-961-01 DI DA2J10100L
D572 6-502-961-01 DI DA2J10100L
D600 6-500-400-01 DIODE BAV99-215
D601 6-500-400-01 DIODE BAV99-215
D602 6-500-400-01 DIODE BAV99-215
< FERRITE BEAD >
FB101 1-481-515-11 BEAD, FERRITE (1608)
FB115 1-400-851-11 EMI, FERRITE (SMD) (1005)
FB117 1-400-851-11 EMI, FERRITE (SMD) (1005)
FB320 1-481-348-21 EMI FERRITE (SMD) (1608)
FB321 1-481-348-21 EMI FERRITE (SMD) (1608)
FB453 1-481-348-21 EMI FERRITE (SMD) (1608)
FB455 1-481-348-21 EMI FERRITE (SMD) (1608)
< FILTER >
FL301 1-234-494-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC002 (Not supplied) IC TPS542941PWPR
IC004 6-721-872-01 IC 78D09AG-TN3-R
IC006 6-721-766-01 IC 78D05AG-TN3-R
IC008 6-719-198-01 IC MM3411A33URE
IC009 6-721-148-01 IC TPS54394 PWPR
IC101 (Not supplied) IC R7S7200032CFP-A
IC102 6-707-866-01 IC TC74VHC126FT (EK)
IC103 6-719-856-01 IC BU4229F-TR
IC105 (Not supplied) IC MFI337S3959
IC106 (Not supplied) IC MX25L3235EM2I-10G
IC301 (Not supplied) IC CXD9990R
IC302 (Not supplied) IC MX25L3235EM2I-10G
IC303 (Not supplied) IC BD00IC0WHFV-GTR
IC304 6-714-351-01 IC R1EX24016ASAS0A
IC305 6-717-694-01 IC BU33TD3WG-TR
IC306 6-720-220-01 IC M12L64164A-7TG2Y
IC401 6-720-195-01 IC AM5890S
* IC451 6-721-151-01 IC GL850G-OGY33
IC452 6-721-822-01 IC NJM2903CV (TE1)
IC453 6-721-811-01 IC TC7USB40FT
IC502 6-719-142-01 IC TC62D723FNG
IC601 8-759-909-71 IC BA4558F
IC602 8-759-596-39 IC SN74LV4052APWR
MOTHERBOARD
Note: IC002, IC101, IC105, IC106, IC301, IC302 and IC303 on
the MOTHERBOARD board cannot exchange with single.
When these parts on the MOTHERBOARD board are
damaged, exchange the entire mounted board.
Ver. 1.3
