Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKEX1/SHAKEX3/SHAKEX7
87
IC603 8-759-909-71 IC BA4558F
IC604 6-705-973-01 IC PCM1754DBQR
IC605 8-759-596-39 IC SN74LV4052APWR
IC606 6-710-554-01 IC PCM1808PWR
IC609 6-710-554-01 IC PCM1808PWR
IC901 6-720-187-01 IC NJM41031F1 (TE2)
IC902 6-720-234-01 IC RN5B801-0002
IC903 6-719-198-01 IC MM3411A33URE
IC913 8-759-680-48 IC TC7WH157FK
IC914 6-721-848-01 IC PCM5101
< JACK >
J601 1-843-547-11 JACK, PIN 6P
(AUDIO IN 2 L/R, AUDIO IN 1 R, PARTY CHAIN IN
L,
AUDIO OUT R, PARTY CHAIN OUT L)
J907 1-794-970-11 JACK, PIN 1P (VIDEO OUT)
< JUMPER >
JC001 1-216-295-91 SHORT CHIP 0
JC002 1-216-295-91 SHORT CHIP 0
JC003 1-216-295-91 SHORT CHIP 0
JC004 1-216-295-91 SHORT CHIP 0
JC005 1-216-295-91 SHORT CHIP 0
JC006 1-216-295-91 SHORT CHIP 0
JC007 1-216-295-91 SHORT CHIP 0
JC008 1-216-295-91 SHORT CHIP 0
< COIL >
L002 1-460-358-11 INDUCTOR 2.2uH
L003 1-400-789-21 INDUCTOR 2.2uH
L004 1-400-789-21 INDUCTOR 2.2uH
L006 1-457-439-11 INDUCTOR 4.7uH
L007 1-460-358-11 INDUCTOR 2.2uH
L008 1-400-789-21 INDUCTOR 2.2uH
L009 1-457-439-11 INDUCTOR 4.7uH
L301 1-400-793-21 INDUCTOR 47uH
L600 1-460-776-11 COIL, AM ANTENNA (SMT)
L603 1-469-187-21 INDUCTOR 68nH
L604 1-469-187-21 INDUCTOR 68nH
L605 1-414-832-11 INDUCTOR 2.2nH
< TRANSISTOR >
Q004 6-553-509-01 TR KTA1542T-RTK/P
Q005 6-553-509-01 TR KTA1542T-RTK/P
Q006 8-729-054-16 TRANSISTOR KRC402-RTK
Q007 6-553-509-01 TR KTA1542T-RTK/P
Q008 6-553-509-01 TR KTA1542T-RTK/P
Q009 8-729-054-16 TRANSISTOR KRC402-RTK
Q011 6-553-509-01 TR KTA1542T-RTK/P
Q012 8-729-054-16 TRANSISTOR KRC402-RTK
Q103 6-553-509-01 TR KTA1542T-RTK/P
Q104 8-729-054-16 TRANSISTOR KRC402-RTK
Q107 8-729-054-16 TRANSISTOR KRC402-RTK
Q108 8-729-054-16 TRANSISTOR KRC402-RTK
Q109 8-729-054-16 TRANSISTOR KRC402-RTK
Q401 6-551-120-01 TRANSISTOR 2SA2119K
Q402 6-551-120-01 TRANSISTOR 2SA2119K
Q457 6-550-987-01 TR RN1911
Q459 6-553-509-01 TR KTA1542T-RTK/P
Q461 8-729-054-16 TRANSISTOR KRC402-RTK
Q571 8-729-054-16 TRANSISTOR KRC402-RTK
Q572 6-553-509-01 TR KTA1542T-RTK/P
Q574 6-552-967-01 TR RHK005N03T146
Q575 6-552-922-01 TR LTA014EUBFS8TL
Q576 8-729-054-16 TRANSISTOR KRC402-RTK
* Q602 6-551-959-01 TR IMX25T110
Q603 6-551-039-01 TRANSISTOR RN4902 (T5RSONY, D, F)
Q604 6-550-978-01 TR RN1902
Q605 8-729-427-72 TRANSISTOR XP4501
Q606 6-552-922-01 TR LTA014EUBFS8TL
Q607 6-551-039-01 TRANSISTOR RN4902 (T5RSONY, D, F)
Q611 6-550-978-01 TR RN1902
< RESISTOR >
R002 1-208-709-11 METAL CHIP 12K 0.5% 1/16W
R003 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
R006 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R020 1-216-864-11 SHORT CHIP 0
R023 1-218-974-11 METAL CHIP 56K 5% 1/16W
R024 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
R028 1-218-965-11 METAL CHIP 10K 5% 1/16W
R029 1-216-843-11 METAL CHIP 68K 5% 1/10W
R030 1-218-843-11 METAL CHIP 680 0.5% 1/10W
R031 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R033 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R034 1-216-813-11 METAL CHIP 220 5% 1/10W
R035 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R036 1-216-864-11 SHORT CHIP 0
R037 1-218-965-11 METAL CHIP 10K 5% 1/16W
R039 1-218-965-11 METAL CHIP 10K 5% 1/16W
R040 1-216-817-11 METAL CHIP 470 5% 1/10W
R041 1-208-709-11 METAL CHIP 12K 0.5% 1/16W
R043 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R048 1-216-864-11 SHORT CHIP 0
R051 1-216-295-91 SHORT CHIP 0
R052 1-216-295-91 SHORT CHIP 0
R053 1-216-864-11 SHORT CHIP 0
R054 1-216-864-11 SHORT CHIP 0
R059 1-208-931-11 METAL CHIP 68K 0.5% 1/16W
R061 1-218-965-11 METAL CHIP 10K 5% 1/16W
R062 1-216-813-11 METAL CHIP 220 5% 1/10W
R063 1-216-864-11 SHORT CHIP 0
R064 1-216-843-11 METAL CHIP 68K 5% 1/10W
R065 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R066 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R080 1-216-864-11 SHORT CHIP 0
R086 1-216-295-91 SHORT CHIP 0
R087 1-216-295-91 SHORT CHIP 0
R100 1-218-937-11 METAL CHIP 47 5% 1/16W
R102 1-218-941-81 METAL CHIP 100 5% 1/16W
R103 1-218-965-11 METAL CHIP 10K 5% 1/16W
R104 1-218-947-11 METAL CHIP 330 5% 1/16W
(SHAKEX3)
R104 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
(SHAKEX1)
R104 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
(SHAKEX7)
R105 1-218-941-81 METAL CHIP 100 5% 1/16W
R106 1-218-965-11 METAL CHIP 10K 5% 1/16W
R107 1-218-965-11 METAL CHIP 10K 5% 1/16W
R108 1-218-965-11 METAL CHIP 10K 5% 1/16W
MOTHERBOARD
Ver. 1.3
