Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKEX1/SHAKEX3/SHAKEX7
92
MOTHERBOARD MS-476 STR
R998 1-216-295-91 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB301 1-234-370-21 RES, NETWORK 22 (1005X4)
RB302 1-234-370-21 RES, NETWORK 22 (1005X4)
RB303 1-234-370-21 RES, NETWORK 22 (1005X4)
RB304 1-234-370-21 RES, NETWORK 22 (1005X4)
RB305 1-234-370-21 RES, NETWORK 22 (1005X4)
RB306 1-234-370-21 RES, NETWORK 22 (1005X4)
RB307 1-234-370-21 RES, NETWORK 22 (1005X4)
RB308 1-234-370-21 RES, NETWORK 22 (1005X4)
RB309 1-234-370-21 RES, NETWORK 22 (1005X4)
< THERMISTOR >
TH571 1-804-949-11 THERMISTOR, NTC (SMD)
< VIBRATOR >
X101 1-814-273-11 QUARTZ CRYSTAL UNITS (32.768 kHz)
X102 1-814-767-11 QUARTZ CRYSTAL UNITS (13.333MHz)
X103 1-814-466-11 QUARTZ CRYSTAL UNITS (12.288MHz)
X104 1-814-356-11 QUARTZ CRYSTAL UNIT (48MHz)
X301 1-814-023-11 QUARTS CRYSTAL UNIT (27MHz)
X451 1-814-365-11 QUARTZ CRYSTAL UNITS (12MHz)
X600 1-814-365-11 QUARTZ CRYSTAL UNITS (12MHz)
*************************************************************
MS-476 BOARD
************
When the MS-476 board is defective, exchange the entire LOADING ASSY (T).
*************************************************************
STR BOARD
**********
< CAPACITOR >
C1003 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1004 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1007 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1008 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKEX3/SHAKEX7)
C1011 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKEX3/SHAKEX7)
C1014 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
* C1016 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C1017 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1022 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
* C1024 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C1025 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1028 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1030 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1031 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1032 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1033 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1034 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1035 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1036 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1037 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1038 1-100-055-21 CERAMIC CHIP 22uF 20% 16V
C1039 1-100-055-21 CERAMIC CHIP 22uF 20% 16V
< CONNECTOR >
CN1001 1-819-866-11 USB CONNECTOR (A) (
2 5V 1A REC/PLAY)
CN1002 1-819-866-11 USB CONNECTOR (A) ( 1 5V 1A PLAY)
CN1008 1-779-544-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN1011 1-779-548-21 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
* CN1222 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN2103 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
< DIODE >
D015 6-502-970-01 DI DZ2J068M0L
D016 6-502-970-01 DI DZ2J068M0L
D018 6-500-400-01 DIODE BAV99-215
D019 6-500-400-01 DIODE BAV99-215
D020 6-500-400-01 DIODE BAV99-215
D1001 6-504-215-01 DI HL-364V620MZ-T
D1006 6-504-213-01 DI HL-364B460MZ-T
D2007 6-502-970-01 DI DZ2J068M0L
D2011 6-500-400-01 DIODE BAV99-215
D2012 6-500-400-01 DIODE BAV99-215
D2013 6-500-400-01 DIODE BAV99-215
D2014 6-502-970-01 DI DZ2J068M0L
D2208 6-502-970-01 DI DZ2J068M0L
D2209 6-502-970-01 DI DZ2J068M0L
D2210 6-504-214-01 DI HL-364W650MZ-T (SHAKEX3/SHAKEX7)
D2211 6-504-214-01 DI HL-364W650MZ-T (SHAKEX3/SHAKEX7)
D2212 6-504-214-01 DI HL-364W650MZ-T (SHAKEX3/SHAKEX7)
D2213 6-504-214-01 DI HL-364W650MZ-T (SHAKEX3/SHAKEX7)
< ROTARY ENCODER >
EN001 1-493-008-11 ENCODER, ROTARY (VOLUME/MULTI CONTROL)
< IC >
IC1001 6-719-142-01 IC TC62D723FNG
< JUMPER >
JC001 1-216-295-91 SHORT CHIP 0
JC002 1-216-295-91 SHORT CHIP 0
JC003 1-216-295-91 SHORT CHIP 0
JC004 1-216-295-91 SHORT CHIP 0
JC005 1-216-295-91 SHORT CHIP 0
JC006 1-216-295-91 SHORT CHIP 0
< JUMPER RESISTOR >
JR0011 1-216-296-11 SHORT CHIP 0
JR0012 1-216-296-11 SHORT CHIP 0
JR0013 1-216-296-11 SHORT CHIP 0
JR0014 1-216-296-11 SHORT CHIP 0
JR0015 1-216-296-11 SHORT CHIP 0
JR0016 1-216-296-11 SHORT CHIP 0
JR0017 1-216-296-11 SHORT CHIP 0
JR0018 1-216-296-11 SHORT CHIP 0
JR00110 1-216-296-11 SHORT CHIP 0
JR00111 1-216-296-11 SHORT CHIP 0
JR00112 1-216-296-11 SHORT CHIP 0
JR00113 1-216-296-11 SHORT CHIP 0
JR00114 1-216-296-11 SHORT CHIP 0
JR00115 1-216-296-11 SHORT CHIP 0
JR00116 1-216-296-11 SHORT CHIP 0
