Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKEX1/SHAKEX3/SHAKEX7
93
JR00117 1-216-864-11 SHORT CHIP 0
JR00118 1-216-296-11 SHORT CHIP 0
JR00122 1-216-296-11 SHORT CHIP 0
JR00124 1-216-296-11 SHORT CHIP 0
JR00125 1-216-296-11 SHORT CHIP 0
JR00127 1-216-296-11 SHORT CHIP 0
JR00128 1-216-296-11 SHORT CHIP 0
JR00129 1-216-296-11 SHORT CHIP 0
JR00130 1-216-296-11 SHORT CHIP 0
JR00131 1-216-296-11 SHORT CHIP 0
JR00132 1-216-296-11 SHORT CHIP 0
JR00133 1-216-296-11 SHORT CHIP 0
JR00134 1-216-296-11 SHORT CHIP 0
JR00135 1-216-296-11 SHORT CHIP 0
JR00136 1-216-296-11 SHORT CHIP 0
JR00137 1-216-296-11 SHORT CHIP 0
JR00139 1-216-296-11 SHORT CHIP 0
JR00140 1-216-296-11 SHORT CHIP 0
JR00141 1-216-296-11 SHORT CHIP 0
JR00142 1-216-296-11 SHORT CHIP 0
JR00144 1-216-296-11 SHORT CHIP 0
JR00145 1-216-296-11 SHORT CHIP 0
JR00148 1-216-296-11 SHORT CHIP 0
JR00154 1-216-296-11 SHORT CHIP 0
JR00155 1-216-296-11 SHORT CHIP 0
JR00160 1-216-296-11 SHORT CHIP 0
JR00163 1-216-296-11 SHORT CHIP 0
JR00165 1-216-296-11 SHORT CHIP 0
JR00166 1-216-296-11 SHORT CHIP 0
JR00171 1-216-296-11 SHORT CHIP 0
JR00172 1-216-296-11 SHORT CHIP 0
JR00173 1-216-296-11 SHORT CHIP 0
JR00174 1-216-296-11 SHORT CHIP 0
< RESISTOR >
R1001 1-216-809-11 METAL CHIP 100 5% 1/10W
R1003 1-216-809-11 METAL CHIP 100 5% 1/10W
R1010 1-216-820-11 METAL CHIP 820 5% 1/10W
R1011 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1012 1-216-809-11 METAL CHIP 100 5% 1/10W
R1013 1-216-809-11 METAL CHIP 100 5% 1/10W
R1015 1-216-801-11 METAL CHIP 22 5% 1/10W
R1020 1-216-801-11 METAL CHIP 22 5% 1/10W
R1021 1-216-801-11 METAL CHIP 22 5% 1/10W
(SHAKEX3/SHAKEX7)
R1022 1-216-801-11 METAL CHIP 22 5% 1/10W
(SHAKEX3/SHAKEX7)
R1023 1-216-801-11 METAL CHIP 22 5% 1/10W
R1024 1-216-801-11 METAL CHIP 22 5% 1/10W
R1025 1-216-801-11 METAL CHIP 22 5% 1/10W
R1026 1-216-801-11 METAL CHIP 22 5% 1/10W
R1027 1-216-801-11 METAL CHIP 22 5% 1/10W
R1028 1-216-801-11 METAL CHIP 22 5% 1/10W
R1029 1-216-801-11 METAL CHIP 22 5% 1/10W
R1036 1-216-819-11 METAL CHIP 680 5% 1/10W
R1037 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1038 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1039 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1040 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1041 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1042 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1043 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1044 1-216-819-11 METAL CHIP 680 5% 1/10W
R1045 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1046 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1047 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1048 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1049 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1068 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1069 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1070 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1071 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1072 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1073 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1076 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1080 1-216-864-11 SHORT CHIP 0
< VARISTOR >
RV001 1-227-919-11 RES, VAR, CARBON 50K (MIC LEVEL MIN MAX)
< SWITCH >
S1001 1-762-875-21 SWITCH, TACTILE (DJ EFFECT DJ OFF)
S1002 1-762-875-21 SWITCH, TACTILE (VOCAL FADER)
S1003 1-762-875-21 SWITCH, TACTILE (S2
+)
S1004 1-762-875-21 SWITCH, TACTILE (S1 ―)
S1005 1-762-875-21 SWITCH, TACTILE (Z)
S1006 1-762-875-21 SWITCH, TACTILE (S4 TUNING + >)
S1007 1-762-875-21 SWITCH, TACTILE (S3 TUNING ― .)
S1008 1-762-875-21 SWITCH, TACTILE (ENTER)
S1009 1-762-875-21 SWITCH, TACTILE (SOUND FIELD)
S1014 1-762-875-21 SWITCH, TACTILE (+/1)
S1015 1-762-875-21 SWITCH, TACTILE (MIC ECHO)
S1016 1-762-875-21 SWITCH, TACTILE (REC TO USB)
S1017 1-762-875-21 SWITCH, TACTILE (BASS BAZUCA)
S1018 1-762-875-21 SWITCH, TACTILE ( PAIRING BLUETOOTH)
S1019 1-762-875-21 SWITCH, TACTILE (LIGHT MODE)
S1020 1-762-875-21 SWITCH, TACTILE (SPEAKER LIGHT)
S1021 1-762-875-21 SWITCH, TACTILE (x)
S1022 1-762-875-21 SWITCH, TACTILE (N)
S1025 1-762-875-21 SWITCH, TACTILE (PARTY CHAIN)
S1026 1-762-875-21 SWITCH, TACTILE (DJ EFFECT FLANGER)
S1027 1-762-875-21 SWITCH, TACTILE (FUNCTION)
S1028 1-762-875-21 SWITCH, TACTILE (DJ EFFECT ISOLATOR)
S1029 1-762-875-21 SWITCH, TACTILE (FOOTBALL)
S1030 1-762-875-21 SWITCH, TACTILE (DJ EFFECT SAMPLER)
*************************************************************
MISCELLANEOUS
**************
0 51 1-855-340-11 DC FAN
101 1-828-372-12 WIRE (FLAT TYPE) (21 CORE)
151 1-828-701-51 WIRE (FLAT TYPE) (10 CORE)
152 1-492-699-11 BLUETOOTH MODULE
203 1-457-369-12 CORE, FERRITE (EXCEPT LA9, TH, AR, E12)
0 204 1-474-607-11 SWITCHING REGULATOR (SHAKEX7)
0 204 1-474-608-21 REGULATOR, SWITCHING (SSN-152AD)
(SHAKEX1/SHAKEX3)
0 205 1-844-220-11 AC INLET
254 1-828-370-21 WIRE (FLAT TYPE) (21 CORE)
255 1-828-319-21 WIRE (FLAT TYPE) (11 CORE)
256 1-828-297-21 WIRE (FLAT TYPE) (7 CORE)
STR
Note: If wires (fl at type) is replaced, install it after bending it in the
same form as that before replacement.
Ver. 1.3
