62
HCD-SR1/SR2/SR3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< FERRITE BEAD >
FB005 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB807 1-414-813-11 FERRITE, EMI (SMD) (2012)
< FLUORESCENT INDICATOR >
FL801 1-519-759-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 8-759-826-33 IC NJL73H400A (
)
IC803 6-705-899-01 IC ML9208-03MBZ03B
< TRANSISTOR >
Q810 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
< RESISTOR >
R828 1-216-864-11 SHORT CHIP 0
R840 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R843 1-216-833-11 METAL CHIP 10K 5% 1/10W
R844 1-216-809-11 METAL CHIP 100 5% 1/10W
R849 1-216-833-11 METAL CHIP 10K 5% 1/10W
R851 1-216-809-11 METAL CHIP 100 5% 1/10W
R852 1-216-805-11 METAL CHIP 47 5% 1/10W
R853 1-216-809-11 METAL CHIP 100 5% 1/10W
R877 1-216-821-11 METAL CHIP 1K 5% 1/10W
R878 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R879 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R880 1-216-821-11 METAL CHIP 1K 5% 1/10W
R881 1-216-821-11 METAL CHIP 1K 5% 1/10W
R882 1-216-821-11 METAL CHIP 1K 5% 1/10W
************************************************************
HP BOARD
*********
< CAPACITOR >
C800 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C801 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C802 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C803 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C804 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C806 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C853 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C854 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
< CONNECTOR >
* CN811 1-566-002-11 PIN, CONNECTOR (PC BOARD) 5P
< DIODE >
D800 8-719-988-61 DIODE 1SS355TE-17
D801 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB800 1-500-284-21 INDUCTOR, FERRITE BEAD
FB802 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB803 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB805 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB810 1-469-324-21 FERRITE, EMI (SMD) (2012)
< JACK >
J800 1-794-453-11 JACK (PHONES)
< COIL >
L800 1-410-387-11 INDUCTOR 33uH
L801 1-410-387-11 INDUCTOR 33uH
L802 1-469-144-21 FERRITE, EMI (SMD) (2012)
L803 1-469-144-21 FERRITE, EMI (SMD) (2012)
< TRANSISTOR >
Q800 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q801 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q803 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q804 8-729-920-31 TRANSISTOR DTC343TK-T-146
< RESISTOR >
R800 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R801 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R802 1-216-809-11 METAL CHIP 100 5% 1/10W
R803 1-216-809-11 METAL CHIP 100 5% 1/10W
R805 1-216-809-11 METAL CHIP 100 5% 1/10W
R807 1-216-809-11 METAL CHIP 100 5% 1/10W
************************************************************
A-1056-478-A IO BOARD, COMPLETE (SR1/SR3)
A-1058-191-A IO BOARD, COMPLETE (SR2)
***********************
< CAPACITOR >
C101 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C102 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C103 1-126-934-11 ELECT 220uF 20% 16V
C105 1-115-156-11 CERAMIC CHIP 1uF 10V
C106 1-115-156-11 CERAMIC CHIP 1uF 10V
C107 1-104-662-91 ELECT 22uF 20% 25V
C108 1-104-662-91 ELECT 22uF 20% 25V
C109 1-104-509-11 CERAMIC CHIP 0.018uF 10% 16V
(EXCEPT HK, SP)
C109 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(HK, SP)
C110 1-104-509-11 CERAMIC CHIP 0.018uF 10% 16V
(EXCEPT HK, SP)
C110 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(HK, SP)
C111 1-104-662-91 ELECT 22uF 20% 25V
C112 1-104-662-91 ELECT 22uF 20% 25V
C113 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(AEP, UK, RU)
C114 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
(AEP, UK, RU)
C115 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
(AEP, UK, RU)
C116 1-126-964-11 ELECT 10uF 20% 50V
(AEP, UK, RU)
C117 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
(AEP, UK, RU)
C118 1-164-380-11 CERAMIC CHIP 51PF 5% 50V
(AEP, UK, RU)
C119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(AEP, UK, RU)
FL HP IO
Ver 1.3
