63
HCD-SR1/SR2/SR3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C120 1-126-933-11 ELECT 100uF 20% 16V
(AEP, UK, RU)
C202 1-126-933-11 ELECT 100uF 20% 16V
(AEP, UK, RU)
C212 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C216 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT AEP, UK, RU)
C217 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT AEP, UK, RU)
C218 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C221 1-115-156-11 CERAMIC CHIP 1uF 10V
C222 1-115-156-11 CERAMIC CHIP 1uF 10V
C223 1-115-156-11 CERAMIC CHIP 1uF 10V
C224 1-126-933-11 ELECT 100uF 20% 16V
C225 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C227 1-104-662-91 ELECT 22uF 20% 25V
C229 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C234 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT AEP, UK, RU)
C235 1-126-916-11 ELECT 1000uF 20% 6.3V
C238 1-126-916-11 ELECT 1000uF 20% 6.3V
(EXCEPT AEP, UK, RU)
C239 1-126-916-11 ELECT 1000uF 20% 6.3V
C240 1-126-916-11 ELECT 1000uF 20% 6.3V
C241 1-126-916-11 ELECT 1000uF 20% 6.3V
C278 1-126-964-11 ELECT 10uF 20% 50V
C603 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C604 1-126-933-11 ELECT 100uF 20% 16V
C605 1-104-662-91 ELECT 22uF 20% 25V
C606 1-104-662-91 ELECT 22uF 20% 25V
C607 1-104-662-91 ELECT 22uF 20% 25V
C608 1-104-662-91 ELECT 22uF 20% 25V
C609 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C610 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C611 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C612 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C613 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(AEP, UK, RU)
C614 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(AEP, UK, RU)
C615 1-104-662-91 ELECT 22uF 20% 25V
(AEP, UK, RU)
C616 1-104-662-91 ELECT 22uF 20% 25V
(AEP, UK, RU)
C623 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(AEP, UK, RU)
C624 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT AEP, UK, RU)
C625 1-104-662-91 ELECT 22uF 20% 25V
C626 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C627 1-104-662-91 ELECT 22uF 20% 25V
C628 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C629 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C631 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C632 1-126-933-11 ELECT 100uF 20% 16V
C633 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C634 1-104-662-91 ELECT 22uF 20% 25V
C635 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C636 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C637 1-104-662-91 ELECT 22uF 20% 25V
C638 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C639 1-126-933-11 ELECT 100uF 20% 16V
C643 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(AEP, UK, RU)
C645 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C646 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN102 1-816-955-11 CONNECTOR, FFC/FPC 11P
CN201 1-784-213-11 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
* CN205 1-506-992-11 PIN, CONNECTOR (PC BOARD) 10P
(AEP, UK, RU)
CN601 1-779-297-11 CONNECTOR, FFC (LIF (NON-ZIF)) 29P
< DIODE >
D101 8-719-069-54 DIODE UDZSTE-175.1B (AEP, UK, RU)
D201 8-719-988-61 DIODE 1SS355TE-17 (AEP, UK, RU)
D206 8-719-988-61 DIODE 1SS355TE-17 (AEP, UK, RU)
< IC >
IC101 8-759-557-36 IC BU1924F-E2 (AEP, UK, RU)
IC201 6-705-602-01 IC MM1623BFBE
IC602 8-759-385-76 IC MC14052 BDR2
IC603 6-600-014-01 IC TORX141L (OPTICAL DIGITAL IN)
IC605 6-706-078-01 IC M62429FP-TP
IC606 6-705-720-01 IC RC4580IDR
< JACK >
J201 1-817-449-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
(EXCEPT AEP, UK, RU)
J202 1-694-920-11 TERMINAL BOARD (S TERMINAL+1P)
(MONITOR OUT) (EXCEPT AEP, UK, RU)
J601 1-816-918-11 JACK, PIN 4P (VIDEO/SAT)
J602 1-774-785-11 JACK, PIN 1P (SURROUND BACK)
< COIL >
L101 1-469-525-91 INDUCTOR 10uH
L209 1-469-525-91 INDUCTOR 10uH
L214 1-216-864-11 SHORT CHIP 0 (EXCEPT AEP, UK, RU)
L601 1-469-525-91 INDUCTOR 10uH
L602 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q101 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q102 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q103 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
(AEP, UK, RU)
Q201 8-729-027-43 TRANSISTOR DTC114EKA-T146
(AEP, UK, RU)
Q202 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
(AEP, UK, RU)
Q203 8-729-027-23 TRANSISTOR DTA114EKA-T146
(AEP, UK, RU)
Q204 8-729-027-43 TRANSISTOR DTC114EKA-T146
(AEP, UK, RU)
Q205 8-729-027-23 TRANSISTOR DTA114EKA-T146
(AEP, UK, RU)
Q206 8-729-027-43 TRANSISTOR DTC114EKA-T146
(AEP, UK, RU)
Q604 8-729-901-00 TRANSISTOR DTC124EKA-T146
