18
SECTION 7
DIAGRAMS
7-1. CIRCUIT BOARD LOCATION
AC SEC board
CD SW board
ST-BY board
PANEL board
MAIN board
TUNER UNI
T
VIDEO board
SENSOR board
MOTOR (TURN) board
MOTOR (SLIDE) boar
d
BD board
LEAF SW board
AUDIO board
CONNECTOR board
