Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
69
R155 1-216-025-91 RES,CHIP 100 5% 1/10W
R156 1-216-025-91 RES,CHIP 100 5% 1/10W
R157 1-216-025-91 RES,CHIP 100 5% 1/10W
R158 1-216-111-00 METAL CHIP 390K 5% 1/10W
R159 1-216-089-91 RES,CHIP 47K 5% 1/10W
R161 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-025-91 RES,CHIP 100 5% 1/10W
R172 1-216-025-91 RES,CHIP 100 5% 1/10W
R173 1-216-025-91 RES,CHIP 100 5% 1/10W
R175 1-216-025-91 RES,CHIP 100 5% 1/10W
R203 1-216-025-91 RES,CHIP 100 5% 1/10W
R204 1-216-025-91 RES,CHIP 100 5% 1/10W
R205 1-216-025-91 RES,CHIP 100 5% 1/10W
R206 1-216-295-91 SHORT 0
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
************************************************************
1-672-968-11 CD SW BOARD
***********
< DIODE >
D751 8-719-056-13 DIODE SML79423C-TP15(DISK1)
D752 8-719-056-13 DIODE SML79423C-TP15(DISK2)
D753 8-719-056-13 DIODE SML79423C-TP15(DISK3)
D754 8-719-063-93 DIODE SLR325VC-N-T32(POWER)
< TRANSISTOR >
Q751 8-729-904-39 TRANSISTOR BA1A4Z-TP
Q752 8-729-904-39 TRANSISTOR BA1A4Z-TP
Q753 8-729-904-39 TRANSISTOR BA1A4Z-TP
< RESISTOR >
R751 1-249-418-11 CARBON 1.2K 5% 1/4W F
R752 1-249-420-11 CARBON 1.8K 5% 1/4W F
R753 1-249-422-11 CARBON 2.7K 5% 1/4W F
R754 1-247-843-11 CARBON 3.3K 5% 1/4W
R755 1-249-425-11 CARBON 4.7K 5% 1/4W F
R756 1-249-427-11 CARBON 6.8K 5% 1/4W F
R757 1-249-429-11 CARBON 10K 5% 1/4W
R758 1-247-804-11 CARBON 75 5% 1/4W
R759 1-247-804-11 CARBON 75 5% 1/4W
R760 1-247-804-11 CARBON 75 5% 1/4W
R761 1-247-804-11 CARBON 75 5% 1/4W
R762 1-247-804-11 CARBON 75 5% 1/4W
R763 1-247-804-11 CARBON 75 5% 1/4W
R764 1-249-407-11 CARBON 150 5% 1/4W F
< SWITCH >
S751 1-762-196-21 SWITCH, TACT(POWER)
S752 1-762-196-21 SWITCH, TACT(STANDBY/DEMO)
S753 1-762-196-21 SWITCH, TACT(DISK1)
S754 1-762-196-21 SWITCH, TACT(DISK2)
S755 1-762-196-21 SWITCH, TACT(DISK3)
S756 1-762-196-21 SWITCH, TACT(DISK SKIP EX-CHANGE)
S757 1-762-196-21 SWITCH, TACT(EJECT)
************************************************************
* 1-658-575-11 CONNECTOR BOARD
****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN702 1-785-550-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR BA1A4M-TP
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
************************************************************
* A-2007-732-A LEAF SW BOARD, COMPLETE (EXCEPT IA)
***********************
A-2007-800-A LEAF SW BOARD, COMPLETE (IA)
***********************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-11 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
< IC >
IC1001 8-749-014-38 PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA-TP
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-856-00 CARBON 11K 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K (TAPE SPEED/HIGH)
RV1002 1-241-785-11 RES, ADJ, CARBON 10K (TAPE SPEED/NOMAL)
BD CD SW LEAF SWCONNECTOR
