Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
75
< RELAY >
RY401 1-515-920-11 RELAY (24V)
< TERMINAL >
TM401 1-537-240-31 TERMINAL BOARD (CHECKER PIN)(SPEAKER)
< VIBRATOR >
X601 1-567-098-41 VIBRATOR, CRYSTAL 32.768kHz
X613 1-781-107-21 VIBRATOR, SERAMIC 16.0MHz
************************************************************
* 1-658-578-11 MOTOR(SLIDE) BOARD
******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 30% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-921-48 DIODE MTZJ-T-72-5.6C (EXCEPT IA)
D804 8-719-911-19 DIODE 1N4148M-TP
D805 8-719-911-19 DIODE 1N4148M-TP
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY
************************************************************
* 1-658-577-11 MOTOR(TURN) BOARD
******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN703 1-785-550-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-983-66 DIODE MTZJ-T-72-3.6B (EXCEPT IA)
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W F
************************************************************
A-4419-652-A PANEL BOARD, COMPLETE (EA,E,JE,MY,SP,TW)
**********************
A-4426-187-A PANEL BOARD, COMPLETE (IA)
**********************
A-4426-195-A PANEL BOARD, COMPLETE (TH)
**********************
* 4-949-935-21 CUSHION (FL)
* 4-996-796-01 HOLDER, FL TUBE
< CAPACITOR >
C601 1-162-306-11 CERAMIC 0.01uF 30% 16V
C603 1-162-306-11 CERAMIC 0.01uF 30% 16V
C604 1-126-163-11 ELECT 4.7uF 20% 50V
C606 1-126-160-11 ELECT 1uF 20% 50V
C625 1-162-294-31 CERAMIC 0.001uF 10% 50V
C626 1-124-589-11 ELECT 47uF 20% 16V
C627 1-162-306-11 CERAMIC 0.01uF 30% 16V
C628 1-162-306-11 CERAMIC 0.01uF 30% 16V
C629 1-162-306-11 CERAMIC 0.01uF 30% 16V
C630 1-162-306-11 CERAMIC 0.01uF 30% 16V
C631 1-126-157-11 ELECT 10uF 20% 16V
C632 1-126-157-11 ELECT 10uF 20% 16V
C633 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C634 1-126-157-11 ELECT 10uF 20% 16V
C635 1-126-163-11 ELECT 4.7uF 20% 50V
C640 1-124-589-11 ELECT 47uF 20% 16V
C644 1-162-306-11 CERAMIC 0.01uF 30% 16V
C645 1-162-306-11 CERAMIC 0.01uF 30% 16V
C646 1-162-306-11 CERAMIC 0.01uF 30% 16V
C647 1-162-306-11 CERAMIC 0.01uF 30% 16V
C648 1-162-306-11 CERAMIC 0.01uF 30% 16V
C649 1-124-589-11 ELECT 47uF 20% 16V
C703 1-164-159-11 CERAMIC 0.1uF 50V
C711 1-162-294-31 CERAMIC 0.001uF 10% 50V
C712 1-162-305-11 CERAMIC 0.0068uF 20% 16V
C713 1-126-160-11 ELECT 1uF 20% 50V
C714 1-136-495-11 FILM 0.068uF 5% 50V
C715 1-124-465-00 ELECT 0.47uF 20% 50V
C716 1-124-465-00 ELECT 0.47uF 20% 50V
C717 1-136-167-00 FILM 0.15uF 5% 50V
C718 1-162-294-31 CERAMIC 0.001uF 10% 50V
C719 1-126-160-11 ELECT 1uF 20% 50V
C720 1-161-494-00 CERAMIC 0.022uF 25V
C721 1-162-305-11 CERAMIC 0.0068uF 20% 16V
C722 1-136-495-11 FILM 0.068uF 5% 50V
C723 1-126-153-11 ELECT 22uF 20% 6.3V
C724 1-164-159-11 CERAMIC 0.1uF 50V
C725 1-126-153-11 ELECT 22uF 20% 6.3V
C731 1-162-306-11 CERAMIC 0.01uF 30% 16V
C732 1-124-257-00 ELECT 2.2uF 20% 50V
C733 1-162-294-31 CERAMIC 0.001uF 10% 50V
C734 1-162-215-31 CERAMIC 47PF 5% 50V
C735 1-124-261-00 ELECT 10uF 20% 50V
C736 1-162-290-31 CERAMIC 470PF 10% 50V
C737 1-124-463-00 ELECT 0.1uF 20% 50V
C738 1-124-257-00 ELECT 2.2uF 20% 50V
C739 1-162-215-31 CERAMIC 47PF 5% 50V
C741 1-124-261-00 ELECT 10uF 20% 50V
C742 1-162-282-31 CERAMIC 100PF 10% 50V
C743 1-124-257-00 ELECT 2.2uF 20% 50V
MAIN MOTOR(SLIDE) MOTOR(TURN) PANEL
