Sony HCD-XB4 - CD-B2 SW DOOR SW HEADPHONE-MIC LEAF SWITCH

– 99 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* 1-664-011-11 CD-B2 SW BOARD
***************
< RESISTOR >
R752 1-249-427-11 CARBON 6.8K 5% 1/4W
R753 1-249-429-11 CARBON 10K 5% 1/4W
R754 1-249-432-11 CARBON 18K 5% 1/4W
R755 1-249-436-11 CARBON 39K 5% 1/4W
R756 1-247-881-00 CARBON 120K 5% 1/4W
< SWITCH >
S681 1-554-303-21 SWITCH, TACTILE (‚)
S682 1-554-303-21 SWITCH, TACTILE (REPEAT)
S683 1-554-303-21 SWITCH, TACTILE (PLAY MODE)
S684 1-554-303-21 SWITCH, TACTILE (1/ALL DISCS)
S685 1-554-303-21 SWITCH, TACTILE (EDIT)
S686 1-554-303-21 SWITCH, TACTILE (º)
S711 1-467-968-11 ENCODER, ROTARY (≠ AMS ±)
************************************************************
* 1-664-016-11 DOOR SW BOARD
***************
< CAPACITOR >
C691 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN661 1-506-481-11 PIN, CONNECTOR 2P
< SWITCH >
S691 1-771-057-11 SWITCH (6 OPEN)
************************************************************
* A-4392-452-A HEADPONE-MIC BOARD, COMPLETE
******************************
< CAPACITOR >
C760 1-162-306-11 CERAMIC 0.01uF 20% 16V
C761 1-126-961-11 ELECT 2.2uF 20% 50V
C764 1-162-294-31 CERAMIC 0.001uF 10% 50V
C765 1-162-215-31 CERAMIC 47PF 5% 50V
C766 1-162-290-31 CERAMIC 470PF 10% 50V
C767 1-162-215-31 CERAMIC 47PF 5% 50V
C769 1-162-282-31 CERAMIC 100PF 10% 50V
C770 1-126-961-11 ELECT 2.2uF 20% 50V
C771 1-126-959-11 ELECT 0.47uF 20% 50V
C773 1-126-964-11 ELECT 10uF 20% 50V
C774 1-126-964-11 ELECT 10uF 20% 50V
C775 1-162-294-31 CERAMIC 0.001uF 10% 50V
C776 1-162-294-31 CERAMIC 0.001uF 10% 50V
C794 1-164-159-21 CERAMIC 0.1uF 50V
C795 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN701 1-568-935-11 PIN, CONNECTOR 8P
< IC >
IC760 8-759-634-51 IC M5218AP
< JACK >
J760 1-770-226-11 JACK (LARGE TYPE) (PHONES)
J761 1-770-226-11 JACK (LARGE TYPE) (MIC)
< RESISTOR >
R760 1-249-429-11 CARBON 10K 5% 1/4W
R761 1-249-417-11 CARBON 1K 5% 1/4W
R764 1-249-441-11 CARBON 100K 5% 1/4W
R765 1-249-417-11 CARBON 1K 5% 1/4W
R766 1-247-863-91 CARBON 22K 5% 1/4W
R767 1-249-429-11 CARBON 10K 5% 1/4W
R769 1-247-885-00 CARBON 180K 5% 1/4W
R770 1-247-807-31 CARBON 100 5% 1/4W
< VARIABLE RESISTOR >
RV760 1-225-366-11 RES, VAR, CARBON 50K
************************************************************
* 1-650-669-11 LEAF SWITCH BOARD
******************
< CONNECTOR >
* CN1001 1-568-854-11 SOCKET, CONNECTOR 11P
< TRANSISTOR >
Q1001 8-749-010-90 TRANSISTOR PHOTO REFLECTOR NJL5165KA-H
Q1002 8-749-010-90 TRANSISTOR PHOTO REFLECTOR NJL5165KA-H
< RESISTOR >
R1001 1-247-818-11 CARBON 300 5% 1/4W
R1002 1-247-820-11 CARBON 360 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
< SWITCH >
S1001 1-692-832-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-692-832-11 SWITCH, PUSH (1 KEY) (B PLAY)
LEAF SWITCHHEADPHONE-MICDOOR SWCD-B2 SW
