Sony HCD-XB4 - LEAF SWITCH LED MAIN

– 100 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S1004 1-571-281-21 SWITCH, LEAF (A HALF)
S1005 1-571-281-21 SWITCH, LEAF (A CrO2)
S1006 1-572-248-21 SWITCH, LEAF (REC A)
S1007 1-572-248-21 SWITCH, LEAF (B HALF)
S1008 1-571-281-21 SWITCH, LEAF (REC B)
S1009 1-571-281-21 SWITCH, LEAF (B CrO2)
************************************************************
* 1-664-017-11 LED BOARD
**********
< CONNECTOR >
CN671 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D671 8-719-058-03 DIODE SEL5423E-TP15
D672 8-719-058-03 DIODE SEL5423E-TP15
D673 8-719-058-03 DIODE SEL5423E-TP15
D674 8-719-058-03 DIODE SEL5423E-TP15
< RESISTOR >
R791 1-249-412-11 CARBON 390 5% 1/4W
************************************************************
* A-4392-474-A MAIN BOARD, COMPLETE (US, CND)
* A-4392-479-A MAIN BOARD, COMPLETE (E, AR, MX)
* A-4392-709-A MAIN BOARD, COMPLETE (AUS, PX)
******************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
* 4-870-539-11 PLATE, GROUND
< CAPACITOR >
C102 1-162-282-31 CERAMIC 100PF 10% 50V
C103 1-162-282-31 CERAMIC 100PF 10% 50V
C104 1-126-962-11 ELECT 3.3uF 20% 50V
C105 1-162-600-11 CERAMIC 0.0047uF30% 16V
C106 1-162-301-11 CERAMIC 0.0015uF30% 16V
C107 1-126-956-91 ELECT 0.1uF 20% 50V
C121 1-162-286-21 CERAMIC 220PF 10% 50V
C123 1-162-306-11 CERAMIC 0.01uF 20% 16V
C152 1-162-282-31 CERAMIC 100PF 10% 50V
C153 1-162-282-31 CERAMIC 100PF 10% 50V
C154 1-126-962-11 ELECT 3.3uF 20% 50V
C155 1-162-600-11 CERAMIC 0.0047uF30% 16V
C156 1-162-301-11 CERAMIC 0.0015uF30% 16V
C157 1-126-956-91 ELECT 0.1uF 20% 50V
C171 1-162-286-21 CERAMIC 220PF 10% 50V
C173 1-162-306-11 CERAMIC 0.01uF 20% 16V
C201 1-136-169-00 FILM 0.22uF 5% 50V
C202 1-136-169-00 FILM 0.22uF 5% 50V
C203 1-130-493-00 MYLAR 0.068uF 5% 50V
C204 1-130-493-00 MYLAR 0.068uF 5% 50V
C205 1-130-486-00 MYLAR 0.018uF 10% 50V
C206 1-130-486-00 MYLAR 0.018uF 10% 50V
C207 1-130-480-00 MYLAR 0.0056uF5% 50V
C208 1-130-479-00 MYLAR 0.0047uF5% 50V
C209 1-130-474-00 MYLAR 0.0018uF5% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C211 1-126-964-11 ELECT 10uF 20% 50V
C212 1-130-481-00 MYLAR 0.0068uF5% 50V
C213 1-136-169-00 FILM 0.22uF 5% 50V
C214 1-136-169-00 FILM 0.22uF 5% 50V
C215 1-162-294-31 CERAMIC 0.001uF 10% 50V
C216 1-136-167-00 FILM 0.15uF 5% 50V
C221 1-126-967-11 ELECT 47uF 20% 10V
C222 1-126-967-11 ELECT 47uF 20% 10V
C223 1-126-964-11 ELECT 10uF 20% 50V
C224 1-162-290-31 CERAMIC 470PF 10% 50V
C226 1-126-964-11 ELECT 10uF 20% 50V
C227 1-164-159-21 CERAMIC 0.1uF 50V
C231 1-126-960-11 ELECT 1uF 20% 50V
C251 1-136-169-00 FILM 0.22uF 5% 50V
C252 1-136-169-00 FILM 0.22uF 5% 50V
C253 1-130-493-00 MYLAR 0.068uF 5% 50V
C254 1-130-493-00 MYLAR 0.068uF 5% 50V
C255 1-130-486-00 MYLAR 0.018uF 10% 50V
C256 1-130-486-00 MYLAR 0.018uF 10% 50V
C257 1-130-480-00 MYLAR 0.0056uF5% 50V
C258 1-130-479-00 MYLAR 0.0047uF5% 50V
C259 1-130-474-00 MYLAR 0.0018uF5% 50V
C260 1-126-964-11 ELECT 10uF 20% 50V
C261 1-126-964-11 ELECT 10uF 20% 50V
C262 1-130-481-00 MYLAR 0.0068uF5% 50V
C263 1-136-169-00 FILM 0.22uF 5% 50V
C264 1-136-169-00 FILM 0.22uF 5% 50V
C276 1-126-964-11 ELECT 10uF 20% 50V
C281 1-126-933-11 ELECT 100uF 20% 10V
C282 1-126-961-11 ELECT 2.2uF 20% 50V
C283 1-126-933-11 ELECT 100uF 20% 10V
C284 1-126-923-11 ELECT 220uF 20% 10V
C291 1-126-959-11 ELECT 0.47uF 20% 50V
C301 1-126-965-11 ELECT 22uF 20% 50V
C302 1-164-159-21 CERAMIC 0.1uF 50V
C303 1-136-165-00 FILM 0.1uF 5% 50V
C304 1-126-926-11 ELECT 1000uF 20% 10V
C305 1-162-306-11 CERAMIC 0.01uF 20% 16V
C309 1-102-514-11 CERAMIC 22PF 5% 50V
LEAF SWITCH LED MAIN
