Sony HCD-XB4 - MAIN

– 101 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C310 1-102-514-11 CERAMIC 22PF 5% 50V
C311 1-164-159-21 CERAMIC 0.1uF 50V
C315 1-126-933-11 ELECT 100uF 20% 10V
C390 1-126-933-11 ELECT 100uF 20% 10V
C393 1-126-925-11 ELECT 470uF 20% 10V
C394 1-164-159-21 CERAMIC 0.1uF 50V
C396 1-126-961-11 ELECT 2.2uF 20% 50V
C398 1-126-961-11 ELECT 2.2uF 20% 50V
C903 1-136-165-00 FILM 0.1uF 5% 50V
C904 1-126-937-11 ELECT 4700uF 20% 16V
C906 1-126-933-11 ELECT 100uF 20% 10V
C909 1-126-964-11 ELECT 10uF 20% 50V
C910 1-126-933-11 ELECT 100uF 20% 10V
C911 1-126-964-11 ELECT 10uF 20% 50V
C912 1-126-916-11 ELECT 1000uF 20% 6.3V
C913 1-126-943-11 ELECT 2200uF 20% 25V
C914 1-126-952-11 ELECT 1000uF 20% 16V
C915 1-126-967-11 ELECT 47uF 20% 16V
C916 1-164-159-21 CERAMIC 0.1uF 50V
C917 1-126-968-11 ELECT 100uF 20% 50V
C918 1-126-968-11 ELECT 100uF 20% 50V
C919 1-126-964-11 ELECT 10uF 20% 50V
C920 1-126-947-11 ELECT 47uF 20% 35V
C953 1-136-165-00 FILM 0.1uF 5% 50V
C954 1-126-768-11 ELECT 2200uF 20% 16V
C956 1-126-933-11 ELECT 100uF 20% 10V
C1501 1-130-479-00 MYLAR 0.0047uF5% 50V
C1502 1-162-290-31 CERAMIC 470PF 10% 50V
C1503 1-164-159-21 CERAMIC 0.1uF 50V
C1504 1-126-960-11 ELECT 1uF 20% 50V
C1505 1-126-964-11 ELECT 10uF 20% 50V
C1506 1-126-964-11 ELECT 10uF 20% 50V
C1507 1-126-960-11 ELECT 1uF 20% 50V
C1508 1-126-933-11 ELECT 100uF 20% 10V
C1521 1-126-964-11 ELECT 10uF 20% 50V
C1522 1-126-964-11 ELECT 10uF 20% 50V
C1523 1-126-933-11 ELECT 100uF 20% 16V
C1531 1-164-159-21 CERAMIC 0.1uF 50V
C1532 1-164-159-21 CERAMIC 0.1uF 50V
C1533 1-164-159-21 CERAMIC 0.1uF 50V
C1534 1-126-935-11 ELECT 470uF 20% 16V
C1551 1-130-479-00 MYLAR 0.0047uF5% 50V
C1552 1-162-290-31 CERAMIC 470PF 10% 50V
C1553 1-164-159-21 CERAMIC 0.1uF 50V
C1554 1-126-960-11 ELECT 1uF 20% 50V
C1555 1-126-964-11 ELECT 10uF 20% 50V
C1556 1-126-964-11 ELECT 10uF 20% 50V
C1557 1-126-960-11 ELECT 1uF 20% 50V
C1558 1-126-933-11 ELECT 100uF 20% 10V
< CONNECTOR >
CN101 1-778-982-11 CONNECTOR, BOARD TO BOARD 13P
* CN102 1-568-836-11 SOCKET, CONNECTOR 17P
* CN201 1-568-832-11 SOCKET, CONNECTOR 13P
CN202 1-568-802-11 SOCKET, CONNECTOR 19P
* CN203 1-568-936-11 PIN, CONNECTOR 9P
CN205 1-568-838-11 SOCKET, CONNECTOR 21P
* CN206 1-568-830-11 SOCKET, CONNECTOR 11P
* CN207 1-568-449-11 HOUSING, CONNECTOR(PC BOARD)3P
< DIODE >
D141 8-719-987-63 DIODE 1N4148M
D281 8-719-815-85 DIODE 1S1585 (US, CND)
D281 8-719-987-63 DIODE 1N4148M (EXCEPT US, CND)
D291 8-719-987-63 DIODE 1N4148M
D301 8-719-200-82 DIODE 11ES2
D302 8-719-200-82 DIODE 11ES2
D303 8-719-987-63 DIODE 1N4148M
D304 8-719-987-63 DIODE 1N4148M
D305 8-719-987-63 DIODE 1N4148M
D306 8-719-987-63 DIODE 1N4148M
D307 8-719-987-63 DIODE 1N4148M
D309 8-719-987-63 DIODE 1N4148M
D902 8-719-200-82 DIODE 11ES2
D903 8-719-200-82 DIODE 11ES2
D904 8-719-200-82 DIODE 11ES2
D905 8-719-200-82 DIODE 11ES2
D906 8-719-200-82 DIODE 11ES2
D907 8-719-200-82 DIODE 11ES2
D908 8-719-200-82 DIODE 11ES2
D909 8-719-200-82 DIODE 11ES2
D910 8-719-002-60 DIODE UZL-33L-TA
D911 8-719-011-47 DIODE UZ-3.3BSB-TA
D912 8-719-987-63 DIODE 1N4148M
D913 8-719-200-82 DIODE 11ES2
D914 8-719-200-82 DIODE 11ES2
D915 8-719-001-43 DIODE UZL-11M1-TA
D951 8-719-987-63 DIODE 1N4148M
D952 8-719-987-63 DIODE 1N4148M
< FERRITE BEAD >
FB302 1-412-473-21 INDUCTOR (SMALL)
< IC >
IC101 8-759-634-50 IC M5218AL
IC102 8-759-000-48 IC MC14052BCP
IC201 8-759-331-39 IC M62427FP
IC231 8-759-634-50 IC M5218AL
MAIN
