Sony HCD-XB4 - POWER AMP

– 107 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C851 1-128-582-11 ELECT 10uF 20% 100V
(US, CND)
C851 1-126-963-11 ELECT 4.7uF 20% 50V
(EXCEPT US, CND)
C852 1-162-286-21 CERAMIC 220PF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-126-967-11 ELECT 47uF 20% 50V
C856 1-126-967-11 ELECT 47uF 20% 50V
C857 1-128-560-11 ELECT 22uF 20% 100V
C861 1-130-493-00 MYLAR 0.068uF 5% 50V
C862 1-130-493-00 MYLAR 0.068uF 5% 50V
C901 1-104-482-11 ELECT 4700uF 20% 63V
(US, CND)
C901 1-126-974-11 ELECT 3300uF 20% 50V
(EXCEPT US, CND)
C902 1-130-777-00 FILM 0.1uF 10% 100V
(US, CND)
C902 1-136-165-00 FILM 0.1uF 5% 50V
(EXCEPT US, CND)
C951 1-104-482-11 ELECT 4700uF 20% 63V
(US, CND)
C951 1-126-974-11 ELECT 3300uF 20% 50V
(EXCEPT US, CND)
C952 1-130-777-00 FILM 0.1uF 10% 100V
(US, CND)
C952 1-136-165-00 FILM 0.1uF 5% 50V
(EXCEPT US, CND)
< CONNECTOR >
CN801 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D801 8-719-815-85 DIODE 1S1585
D841 8-719-987-63 DIODE 1N4148M
D842 8-719-987-63 DIODE 1N4148M
D851 8-719-815-85 DIODE 1S1585
D901 8-719-510-68 DIODE D5SBA20F01
< IC >
IC801 8-749-921-68 IC STK-4231MK2 (US, CND)
IC801 8-749-900-34 IC STK-4182MK2 (EXCEPT US, CND)
< TRANSISTOR >
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-413-11 CARBON 470 5% 1/4W
R804 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-260-107-11 CARBON 4.7K 5% 1/2W
(US, CND)
R805 1-260-105-11 CARBON 3.3K 5% 1/2W
(EXCEPT US, CND)
R806 1-260-107-11 CARBON 4.7K 5% 1/2W
(US, CND)
R806 1-260-105-11 CARBON 3.3K 5% 1/2W
(EXCEPT US, CND)
! R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R808 1-208-601-11 WIREWOUND 0.1 10% 2W F
R809 1-260-076-11 CARBON 10 5% 1/2W
R811 1-249-417-11 CARBON 1K 5% 1/4W
R812 1-247-863-91 CARBON 22K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-260-105-11 CARBON 3.3K 5% 1/2W
(US, CND)
R814 1-260-099-11 CARBON 1K 5% 1/2W
(EXCEPT US, CND)
R816 1-260-105-11 CARBON 3.3K 5% 1/2W
(US, CND)
R816 1-260-099-11 CARBON 1K 5% 1/2W
(EXCEPT US, CND)
! R820 1-202-972-61 FUSIBLE 1 5% 1/4W F
R841 1-249-429-11 CARBON 10K 5% 1/4W
R842 1-247-885-00 CARBON 180K 5% 1/4W
(US, CND)
R842 1-247-881-00 CARBON 120K 5% 1/4W
(EXCEPT US, CND)
R843 1-247-843-11 CARBON 3.3K 5% 1/4W
(US, CND)
R843 1-249-421-11 CARBON 2.2K 5% 1/4W
(EXCEPT US, CND)
R844 1-249-429-11 CARBON 10K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-413-11 CARBON 470 5% 1/4W
R854 1-249-437-11 CARBON 47K 5% 1/4W
R855 1-260-107-11 CARBON 4.7K 5% 1/2W
(US, CND)
R855 1-260-105-11 CARBON 3.3K 5% 1/2W
(EXCEPT US, CND)
R856 1-260-107-11 CARBON 4.7K 5% 1/2W
(US, CND)
R856 1-260-105-11 CARBON 3.3K 5% 1/2W
(EXCEPT US, CND)
! R857 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R858 1-208-601-11 WIREWOUND 0.1 10% 2W F
R859 1-260-076-11 CARBON 10 5% 1/2W
R861 1-249-417-11 CARBON 1K 5% 1/4W
R862 1-247-863-91 CARBON 22K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
************************************************************
POWER AMP
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
