Sony HCD-XB4 - PANEL

– 108 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D638 8-719-057-09 DIODE LNJ801LPDJA (r REC)
< RESISTOR >
R715 1-249-421-11 CARBON 2.2K 5% 1/4W
R716 1-247-843-11 CARBON 3.3K 5% 1/4W
R717 1-249-425-11 CARBON 4.7K 5% 1/4W
R718 1-249-427-11 CARBON 6.8K 5% 1/4W
R719 1-249-429-11 CARBON 10K 5% 1/4W
R720 1-249-432-11 CARBON 18K 5% 1/4W
R721 1-249-436-11 CARBON 39K 5% 1/4W
R722 1-247-881-00 CARBON 120K 5% 1/4W
R724 1-247-807-31 CARBON 100 5% 1/4W
R725 1-247-807-31 CARBON 100 5% 1/4W
R727 1-247-807-31 CARBON 100 5% 1/4W
R728 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S651 1-554-303-21 SWITCH, TACTILE (·)
S652 1-554-303-21 SWITCH, TACTILE (ª)
S653 1-554-303-21 SWITCH, TACTILE ())
S654 1-554-303-21 SWITCH, TACTILE (0)
S655 1-554-303-21 SWITCH, TACTILE (p)
S656 1-554-303-21 SWITCH, TACTILE (P)
S657 1-554-303-21 SWITCH, TACTILE (r REC)
S658 1-554-303-21 SWITCH, TACTILE (H.SPEED DUBB)
S659 1-554-303-21 SWITCH, TACTILE (CD SYNC)
************************************************************
* A-4303-510-A TCB BOARD,COMPLETE (US, CND)
* A-4303-512-A TCB BOARD,COMPLETE (EXCEPT US, CND)
*******************
< CAPACITOR >
C1 1-162-294-31 CERAMIC 0.001uF 10% 50V
C2 1-126-967-11 ELECT 47uF 20% 16V
C3 1-164-159-21 CAP, CERAMIC 0.1uF 50V
C5 1-162-306-11 CERAMIC 0.01uF 20% 16V
C6 1-162-306-11 CERAMIC 0.01uF 20% 16V
C7 1-101-004-00 CERAMIC 0.01uF 50V
C8 1-162-306-11 CERAMIC 0.01uF 20% 16V
C9 1-162-306-11 CERAMIC 0.01uF 20% 16V
C11 1-164-159-21 CAP, CERAMIC 0.1uF 50V
C12 1-162-198-31 CERAMIC 8.2PF 10% 50V
C14 1-162-306-11 CERAMIC 0.01uF 20% 16V
C21 1-102-514-11 CERAMIC 22PF 5% 50V
C22 1-164-159-21 CAP, CERAMIC 0.1uF 50V
C23 1-162-306-11 CERAMIC 0.01uF 20% 16V
C24 1-126-967-11 ELECT 47uF 20% 16V
C25 1-162-306-11 CERAMIC 0.01uF 20% 16V
* 1-659-058-13 TABLE SENSOR BOARD
*******************
* 4-980-385-01 HOLDER (SW)
< IC >
IC202 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R207 1-249-416-11 CARBON 820 5% 1/4W
************************************************************
* 1-664-012-11 TC-A SW BOARD
**************
< CONNECTOR >
* CN612 1-568-943-11 PIN, CONNECTOR 5P
< DIODE >
D631 8-719-057-10 DIODE LNJ301MPUJA (·)
D632 8-719-057-10 DIODE LNJ301MPUJA (ª)
< RESISTOR >
R705 1-249-413-11 CARBON 470 5% 1/4W
R706 1-249-415-11 CARBON 680 5% 1/4W
R707 1-249-416-11 CARBON 820 5% 1/4W
R708 1-249-418-11 CARBON 1.2K 5% 1/4W
R709 1-249-419-11 CARBON 1.5K 5% 1/4W
R710 1-249-421-11 CARBON 2.2K 5% 1/4W
R711 1-247-807-31 CARBON 100 5% 1/4W
R714 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S641 1-554-303-21 SWITCH, TACTILE (·)
S642 1-554-303-21 SWITCH, TACTILE (ª)
S643 1-554-303-21 SWITCH, TACTILE (p)
S644 1-554-303-21 SWITCH, TACTILE (0)
S645 1-554-303-21 SWITCH, TACTILE ())
S646 1-554-303-21 SWITCH, TACTILE (DOLBY NR)
S647 1-554-303-21 SWITCH, TACTILE (DIRECTION)
************************************************************
* 1-664-013-11 TC-B SW BOARD
**************
< DIODE >
D635 8-719-057-10 DIODE LNJ301MPUJA (ª)
D636 8-719-057-10 DIODE LNJ301MPUJA (·)
D637 8-719-058-17 DIODE LNJ401NPYJA (P)
TCBTC-A SW TC-B SW
TABLE SENSOR
