Sony HCD-XB4 - TCB TRANS

– 109 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C26 1-126-964-11 ELECT 10uF 20% 50V
C27 1-164-159-21 CAP, CERAMIC 0.1uF 50V
C28 1-126-961-11 ELECT 2.2uF 20% 50V
C29 1-102-518-11 CERAMIC 33PF 5% 50V
C30 1-162-294-31 CERAMIC 0.001uF 10% 50V
C31 1-162-306-11 CERAMIC 0.01uF 20% 16V
C41 1-126-933-11 ELECT 100uF 20% 10V
C42 1-162-306-11 CERAMIC 0.01uF 20% 16V
C43 1-126-962-11 ELECT 3.3uF 20% 50V
C44 1-162-306-11 CERAMIC 0.01uF 20% 16V
C45 1-124-589-11 ELECT 47uF 20% 16V
C46 1-162-600-11 CERAMIC 4700PF 30% 16V
C47 1-162-294-31 CERAMIC 0.001uF 10% 50V
C48 1-126-160-11 ELECT 1uF 20% 50V
C49 1-136-159-00 METALIZED FILM 0.033uF 5% 50V
(EXCEPT US,CND)
C49 1-136-162-00 METALIZED FILM 0.056uF 5% 50V
(US, CND)
C50 1-136-159-00 METALIZED FILM 0.033uF 5% 50V
(EXCEPT US,CND)
C50 1-136-162-00 METALIZED FILM 0.056uF 5% 50V
(US, CND)
C51 1-162-600-11 CERAMIC 4700PF 30% 16V
C52 1-162-600-11 CERAMIC 4700PF 30% 16V
C53 1-126-964-11 ELECT 10uF 20% 50V
C54 1-126-157-11 ELECT 10uF 20% 16V
C55 1-126-964-11 ELECT 10uF 20% 50V
C56 1-126-964-11 ELECT 10uF 20% 50V
C57 1-164-159-21 CAP, CERAMIC 0.1uF 50V
C58 1-162-306-11 CERAMIC 0.01uF 20% 16V
C59 1-164-159-21 CAP, CERAMIC 0.1uF 50V
C61 1-164-159-21 CAP, CERAMIC 0.1uF 50V
C62 1-126-967-11 ELECT 47uF 20% 16V
C63 1-164-159-21 CAP, CERAMIC 0.1uF 50V
C64 1-126-959-11 ELECT 0.47uF 20% 50V
C65 1-126-960-11 ELECT 1.0uF 20% 50V
C66 1-126-960-11 ELECT 1.0uF 20% 50V
C67 1-126-964-11 ELECT 10uF 20% 50V
C68 1-162-306-11 CERAMIC 0.01uF 20% 16V
C69 1-162-306-11 CERAMIC 0.01uF 20% 16V
C70 1-162-306-11 CERAMIC 0.01uF 20% 16V
C71 1-162-306-11 CERAMIC 0.01uF 20% 16V
C73 1-162-306-11 CERAMIC 0.01uF 20% 16V
C74 1-126-964-11 ELECT 10uF 20% 50V
< FILTER >
CF1 1-567-389-11 FILTER, CERAMIC
CF2 1-567-389-11 FILTER, CERAMIC
< CONNECTOR >
* CN1 1-568-832-11 SOCKET, CONNECTOR 13P
< DIODE >
D1 8-719-933-33 DIODE UZL-6L1-TA
D2 8-719-987-63 DIODE 1N4148M-TA
< FRONT END >
FE1 1-233-533-11 ENCAPSULATED COMPONENT
FE2 1-239-260-11 ENCAPSULATED COMPONENT
< IC >
IC1 8-759-288-54 IC LC72130
IC2 8-759-176-03 IC LA1835
< IFT >
IFT41 1-409-636-11 TRANSFORMER, IF (CERAMIC FILTER)
< COIL >
L41 1-410-119-11 MICRO INDUCTOR (EL TYPE) 1mH
< FILTER >
LPF41 1-239-845-11 FILTER, LOW PASS
LPF42 1-239-845-11 FILTER, LOW PASS
< TRANSISTOR >
Q1 8-729-230-99 TRANSISTOR 2SC2669OY-TPE4
Q2 8-729-230-99 TRANSISTOR 2SC2669OY-TPE4
Q3 8-729-230-99 TRANSISTOR 2SC2669OY-TPE4
Q4 8-729-230-99 TRANSISTOR 2SC2669OY-TPE4
Q5 8-729-422-57 TRANSISTOR BN1A4M-TP
< RESISTOR >
R1 1-249-401-11 CARBON 47 5% 1/4W
R2 1-249-411-11 CARBON 330 5% 1/4W
R3 1-249-411-11 CARBON 330 5% 1/4W
R5 1-249-411-11 CARBON 330 5% 1/4W
R6 1-247-863-91 CARBON (SMALL) 22K 5% 1/4W
R7 1-249-411-11 CARBON 330 5% 1/4W
R8 1-249-411-11 CARBON 330 5% 1/4W
R9 1-247-863-91 CARBON (SMALL) 22K 5% 1/4W
R10 1-249-411-11 CARBON 330 5% 1/4W
R11 1-247-863-91 CARBON (SMALL) 22K 5% 1/4W
R12 1-249-411-11 CARBON 330 5% 1/4W
R13 1-249-411-11 CARBON 330 5% 1/4W
R14 1-247-863-91 CARBON (SMALL) 22K 5% 1/4W
R15 1-249-429-11 CARBON 10K 5% 1/4W
R16 1-249-437-11 CARBON 47K 5% 1/4W
R19 1-249-399-11 CARBON 33 5% 1/4W
R21 1-247-807-31 CARBON (SMALL) 100 5% 1/4W
R22 1-249-425-11 CARBON 4.7K 5% 1/4W
R23 1-249-425-11 CARBON 4.7K 5% 1/4W
R24 1-249-425-11 CARBON 4.7K 5% 1/4W
TCB
