7-2. FRONT PANEL SECTION-1
Ref. No. Part No. Description Remarks
Ref. No. Part No. Description Remarks
54
53
54
54
54
54
54
63
64
63
65
54
62
60
61
55
56
57
58
54
59
52
51
not supplied
not supplied
Front panel section-2
#1
not supplied
54
51 4-237-635-01 KNOB (MIC)
52 A-4727-633-A MIC/GUITAR BOARD, COMPLETE
53 1-683-448-11 TC-A BOARD
54 4-951-620-01 SCREW (2.6X8), +BVTP
55 4-237-648-01 COVER (EJECT)
56 4-237-645-01 LEVER (EJECT-A)
57 4-237-647-01 LEVER (EJECT-C)
58 4-237-646-01 LEVER (EJECT-B)
59 4-237-659-01 SPRING (LEVER)
60 1-796-333-11 DECK, MECHANICAL
61 1-773-021-11 WIRE (FLAT TYPE) (15 CORE)
62 1-683-449-11 TC-B BOARD
63 3-354-963-01 DAMPER
64 1-683-450-11 HEADPHONE BOARD
65 1-684-683-11 D-SW BOARD
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
