70
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR80
PA
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
PANEL FL
R833 1-247-856-00 CARBON 11K 5% 1/4W
R834 1-249-429-11 CARBON 10K 5% 1/4W
R835 1-249-437-11 CARBON 47K 5% 1/4W
R836 1-249-417-11 CARBON 1K 5% 1/4W F
R837 1-249-435-11 CARBON 33K 5% 1/4W
R838 1-249-435-11 CARBON 33K 5% 1/4W
R839 1-249-441-11 CARBON 100K 5% 1/4W
R840 1-249-402-11 CARBON 56 5% 1/4W F
R841 1-249-437-11 CARBON 47K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-411-11 CARBON 330 5% 1/4W F
0R855 1-215-891-11 METAL OXIDE 680 5% 2W
0R857 1-212-881-11 FUSIBLE 100 5% 1/4W
0R858 1-220-893-11 METAL 0.22 10% 5W
R859 1-260-076-11 CARBON 10 5% 1/2W
R860 1-249-437-11 CARBON 47K 5% 1/4W
R861 1-249-417-11 CARBON 1K 5% 1/4W F
R862 1-249-431-11 CARBON 15K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
R864 1-249-425-11 CARBON 4.7K 5% 1/4W F
R865 1-249-433-11 CARBON 22K 5% 1/4W
R866 1-249-429-11 CARBON 10K 5% 1/4W
R867 1-249-421-11 CARBON 2.2K 5% 1/4W F
R868 1-249-409-11 CARBON 220 5% 1/4W F
R880 1-249-402-11 CARBON 56 5% 1/4W F
0R888 1-220-893-11 METAL 0.22 10% 5W
R889 1-249-441-11 CARBON 100K 5% 1/4W
0R898 1-220-893-11 METAL 0.22 10% 5W
R901 1-249-429-11 CARBON 10K 5% 1/4W
R902 1-249-441-11 CARBON 100K 5% 1/4W
R903 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R905 1-249-429-11 CARBON 10K 5% 1/4W
R906 1-247-807-31 CARBON 100 5% 1/4W
R907 1-247-807-31 CARBON 100 5% 1/4W
R915 1-247-791-91 CARBON 22 5% 1/4W
0R916 1-215-890-11 METAL OXIDE 470 5% 2W
< RELAY >
RY401 1-515-920-11 RELAY
RY402 1-515-920-11 RELAY
< THEMISTOR >
TH831 1-807-796-11 THERMISTOR
< TERMINAL >
TM401 1-537-925-61 TERMINAL BOARD 4P (FRONT SPEAKER)
TM402 1-694-091-11 TERMINAL BOARD 4P (SURROUND SPEAKER)
******************************************************
A-4727-623-A PANEL FL BOARD, COMPLETE
**********************
4-225-511-01 HOLDER FL TUBE
* 4-949-935-81 CUSHION (FL)
< CAPACITOR >
C601 1-162-294-31 CERAMIC 0.001uF 10% 50V
C602 1-126-947-11 ELECT 47uF 20% 16V
C603 1-162-306-11 CERAMIC 0.01uF 30% 16V
C604 1-126-947-11 ELECT 47uF 20% 16V
C605 1-162-306-11 CERAMIC 0.01uF 30% 16V
C606 1-126-963-11 ELECT 4.7uF 20% 50V
C607 1-164-159-21 CERAMIC 0.1uF 50V
C612 1-164-159-21 CERAMIC 0.1uF 50V
C614 1-126-947-11 ELECT 47uF 20% 16V
C615 1-126-964-11 ELECT 10uF 20% 50V
C616 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C617 1-126-157-11 ELECT 10uF 20% 16V
C618 1-126-157-11 ELECT 10uF 20% 16V
C619 1-162-306-11 CERAMIC 0.01uF 30% 16V
C625 1-126-964-11 ELECT 10uF 20% 50V
C627 1-126-960-11 ELECT 1uF 20% 50V
C628 1-126-960-11 ELECT 1uF 20% 50V
< CONNECTOR >
* CN601 1-568-865-11 SOCKET, CONNECTOR 23P
CN602 1-784-780-11 CONNECTOR, FFC 19P
< DIODE >
D601 8-719-991-33 DIODE 1SS133T-77
D602 8-719-058-04 DIODE SEL5223S-TP15 ([/1)
D603 8-719-071-42 DIODE SEL5723C-TP15 (SALSA)
D604 8-719-071-42 DIODE SEL5723C-TP15 (REGGAE)
D605 8-719-071-42 DIODE SEL5723C-TP15 (TANGO)
D606 8-719-071-42 DIODE SEL5723C-TP15 (SAMBA)
D607 8-719-071-42 DIODE SEL5723C-TP15 (MOVIE)
D608 8-719-058-03 DIODE SEL5423E-TP15 (GAME MIXING)
D609 8-719-071-42 DIODE SEL5723C-TP15 (GUITAR)
D610 8-719-071-42 DIODE SEL5723C-TP15 (ROCK)
D611 8-719-071-42 DIODE SEL5723C-TP15 (JAZZ)
D612 8-719-071-42 DIODE SEL5723C-TP15 (DANCE)
D613 8-719-071-42 DIODE SEL5723C-TP15 (GAME)
< FERRITE BEAD >
FB601 1-412-473-21 INDUCTOR 0UH
< FLUORESCENT INDICATOR TUBE >
FL601 1-518-794-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 6-801-052-01 IC MB90M407APF-G-112-BND
IC602 8-759-083-77 IC BA3830F
IC603 8-759-826-34 IC NJL74H400A
< COIL >
L603 1-410-517-11 INDUCTOR 47uH
L604 1-410-517-11 INDUCTOR 47uH
L605 1-410-517-11 INDUCTOR 47uH
L901 1-410-517-11 INDUCTOR 47uH
L902 1-410-517-11 INDUCTOR 47uH
< TRANSISTOR >
Q601 8-729-029-86 TRANSISTOR DTC124ESA
Q602 8-729-620-05 TRANSISTOR 2SC2603-EF
Q603 8-729-140-04 TRANSISTOR 2SB1116A-L
Q604 8-729-620-05 TRANSISTOR 2SC2603-EF
Q605 8-729-140-04 TRANSISTOR 2SB1116A-L
To Next Page
