72
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR80
SENSOR
< VIBRATOR >
X601 1-577-358-21 VIBRATOR, CERAMIC (4MHz)
******************************************************
A-4727-624-A PANEL VR BOARD, COMPLETE
**********************
< CAPACITOR >
C701 1-162-294-31 CERAMIC 0.001uF 10% 50V
C702 1-162-294-31 CERAMIC 0.001uF 10% 50V
C703 1-162-294-31 CERAMIC 0.001uF 10% 50V
C704 1-126-947-11 ELECT 47uF 20% 16V
C705 1-162-306-11 CERAMIC 0.01uF 30% 16V
C706 1-164-159-21 CERAMIC 0.1uF 50V
C707 1-162-306-11 CERAMIC 0.01uF 30% 16V
C708 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
* CN701 1-568-865-11 SOCKET, CONNECTOR 23P
< DIODE >
D701 8-719-058-64 DIODE SEL5823A-TP15 (VU 1)
D702 8-719-058-64 DIODE SEL5823A-TP15 (VU 2)
D703 8-719-058-64 DIODE SEL5823A-TP15 (VU 3)
D704 8-719-058-64 DIODE SEL5823A-TP15 (VU 4)
D705 8-719-058-64 DIODE SEL5823A-TP15 (VU 5)
D706 8-719-058-64 DIODE SEL5823A-TP15 (VU 6)
D707 8-719-058-64 DIODE SEL5823A-TP15 (VU 7)
D708 8-719-058-64 DIODE SEL5823A-TP15 (VU 8)
D709 8-719-058-64 DIODE SEL5823A-TP15 (VU 9)
D710 8-719-058-04 DIODE SEL5223S-TP15 (VU 10)
D711 8-719-058-04 DIODE SEL5223S-TP15 (VU 11)
D712 8-719-058-04 DIODE SEL5223S-TP15 (VU 12)
D713 8-719-058-04 DIODE SEL5223S-TP15 (GROOVE)
D714 8-719-058-04 DIODE SEL5223S-TP15 (SUPER WOOFER)
D715 8-719-058-04 DIODE SEL5223S-TP15 (SURROUND)
D716 8-719-058-04 DIODE SEL5223S-TP15 (ENTER)
D717 8-719-058-04 DIODE SEL5223S-TP15 (GUITAR DISTORSION)
D719 8-719-058-03 DIODE SEL5423E-TP15 (TUNER/BAND)
D720 8-719-058-04 DIODE SEL5223S-TP15 (TUNER ENTER)
< IC >
IC701 8-759-373-50 IC NJU3719L
< COIL >
L701 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R703 1-247-807-31 CARBON 100 5% 1/4W
R704 1-247-807-31 CARBON 100 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
R706 1-249-417-11 CARBON 1K 5% 1/4W F
R707 1-249-417-11 CARBON 1K 5% 1/4W F
R708 1-249-419-11 CARBON 1.5K 5% 1/4W F
R709 1-249-419-11 CARBON 1.5K 5% 1/4W F
R710 1-249-421-11 CARBON 2.2K 5% 1/4W F
R711 1-247-843-11 CARBON 3.3K 5% 1/4W
R712 1-249-425-11 CARBON 4.7K 5% 1/4W F
R713 1-249-427-11 CARBON 6.8K 5% 1/4W F
R714 1-249-429-11 CARBON 10K 5% 1/4W
R715 1-249-431-11 CARBON 15K 5% 1/4W
R716 1-249-433-11 CARBON 22K 5% 1/4W
R718 1-249-415-11 CARBON 680 5% 1/4W F
R719 1-249-417-11 CARBON 1K 5% 1/4W F
R720 1-249-419-11 CARBON 1.5K 5% 1/4W F
R721 1-249-419-11 CARBON 1.5K 5% 1/4W F
R722 1-249-421-11 CARBON 2.2K 5% 1/4W F
R723 1-247-843-11 CARBON 3.3K 5% 1/4W
R724 1-249-425-11 CARBON 4.7K 5% 1/4W F
R725 1-249-427-11 CARBON 6.8K 5% 1/4W F
R726 1-249-429-11 CARBON 10K 5% 1/4W
R731 1-247-791-91 CARBON 22 5% 1/4W
R732 1-247-791-91 CARBON 22 5% 1/4W
R733 1-247-791-91 CARBON 22 5% 1/4W
R734 1-247-791-91 CARBON 22 5% 1/4W
R735 1-247-791-91 CARBON 22 5% 1/4W
R736 1-247-791-91 CARBON 22 5% 1/4W
R737 1-247-791-91 CARBON 22 5% 1/4W
R738 1-247-791-91 CARBON 22 5% 1/4W
R739 1-247-791-91 CARBON 22 5% 1/4W
R740 1-249-401-11 CARBON 47 5% 1/4W F
R741 1-249-401-11 CARBON 47 5% 1/4W F
R742 1-249-401-11 CARBON 47 5% 1/4W F
R743 1-247-807-31 CARBON 100 5% 1/4W
R744 1-247-807-31 CARBON 100 5% 1/4W
R745 1-247-807-31 CARBON 100 5% 1/4W
R746 1-247-807-31 CARBON 100 5% 1/4W
R747 1-247-807-31 CARBON 100 5% 1/4W
R749 1-247-791-91 CARBON 22 5% 1/4W
R750 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S700 1-473-392-11 ENCODER, ROTARY (VOLUME)
S701 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S702 1-762-875-21 SWITCH, KEYBOARD (SURROUND)
S703 1-762-875-21 SWITCH, KEYBOARD (EFFECT ON/OFF)
S704 1-762-875-21 SWITCH, KEYBOARD (P FILE)
S705 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S706 1-762-875-21 SWITCH, KEYBOARD ( R )
S707 1-762-875-21 SWITCH, KEYBOARD ( r )
S708 1-762-875-21 SWITCH, KEYBOARD (t)
S709 1-762-875-21 SWITCH, KEYBOARD (T)
S710 1-762-875-21 SWITCH, KEYBOARD (MIX GUITAR/KARAOKE)
S711 1-762-875-21 SWITCH, KEYBOARD (GUITAR DISTORSION)
S713 1-762-875-21 SWITCH, KEYBOARD (SUPER WOOFER)
S714 1-762-875-21 SWITCH, KEYBOARD (SUPER WOOFER MODE)
S715 1-762-875-21 SWITCH, KEYBOARD (X-GROOVE)
S716 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S717 1-762-875-21 SWITCH, KEYBOARD (TUNING –)
S718 1-762-875-21 SWITCH, KEYBOARD (TUNING +)
S719 1-762-875-21 SWITCH, KEYBOARD (FM MODE)
S720 1-762-875-21 SWITCH, KEYBOARD (TUNER ENTER)
S721 1-762-875-21 SWITCH, KEYBOARD (TUNER MEMORY)
S722 1-762-875-21 SWITCH, KEYBOARD (TUNING MODE)
******************************************************
* 1-659-058-13 SENSOR BOARD
************
< IC >
IC202 8-749-924-18 PHOTO INTERRUPTER RPI-1391
PANEL VR
