73
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR80
SUB TRANS TC-A
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
SUB AMP
< RESISTOR >
R207 1-249-416-11 CARBON 820 5% 1/4W F
******************************************************
A-4727-659-A SUB AMP BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-126-960-11 ELECT 1uF 20% 50V
C102 1-162-286-21 CERAMIC 220PF 10% 50V
C103 1-162-286-21 CERAMIC 220PF 10% 50V
C104 1-126-965-91 ELECT 22uF 20% 50V
C105 1-136-165-00 MYLAR 0.1uF 5% 50V
C106 1-136-165-00 MYLAR 0.1uF 5% 50V
C107 1-128-560-11 ELECT 22uF 20% 100V
C108 1-136-495-11 FILM 0.068uF 5% 50V
C109 1-136-495-11 FILM 0.068uF 5% 50V
C113 1-162-306-11 CERAMIC 0.01uF 30% 16V
C114 1-162-294-31 CERAMIC 0.001uF 10% 50V
C151 1-126-960-11 ELECT 1uF 20% 50V
C152 1-162-286-21 CERAMIC 220PF 10% 50V
C153 1-162-286-21 CERAMIC 220PF 10% 50V
C154 1-126-965-91 ELECT 22uF 20% 50V
C157 1-128-560-11 ELECT 22uF 20% 100V
C158 1-136-495-11 FILM 0.068uF 5% 50V
C159 1-136-495-11 FILM 0.068uF 5% 50V
< CONNECTOR >
CN101 1-691-772-11 PLUG (MICRO CONNECTOR) 10P
CN102 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< DIODE >
D101 8-719-991-33 DIODE 1SS133T-77
D102 8-719-110-39 DIODE RD15ESB1
D103 8-719-110-39 DIODE RD15ESB1
D151 8-719-991-33 DIODE 1SS133T-77
< IC >
IC101 8-749-017-05 IC STK412-040
< TRANSISTOR >
Q101 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q151 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR>
R101 1-249-417-11 CARBON 1K 5% 1/4W F
R102 1-249-441-11 CARBON 100K 5% 1/4W
R103 1-249-415-11 CARBON 680 5% 1/4W F
R105 1-216-436-00 METAL OXIDE 3.9K 5% 1W
R106 1-216-436-00 METAL OXIDE 3.9K 5% 1W
0R107 1-212-881-11 FUSIBLE 100 5% 1/4W
0R108 1-220-893-11 METAL 0.22 10% 5W
R109 1-260-076-11 CARBON 10 5% 1/2W
R110 1-249-441-11 CARBON 100K 5% 1/4W
R111 1-249-417-11 CARBON 1K 5% 1/4W F
R112 1-249-431-11 CARBON 15K 5% 1/4W
R113 1-249-441-11 CARBON 100K 5% 1/4W
0R120 1-217-637-00 FUSIBLE 1 5% 1/4W
0R128 1-220-893-11 METAL 0.22 10% 5W
R130 1-249-435-11 CARBON 33K 5% 1/4W
0R138 1-220-893-11 METAL 0.22 10% 5W
R151 1-249-417-11 CARBON 1K 5% 1/4W F
R152 1-249-441-11 CARBON 100K 5% 1/4W
R153 1-249-415-11 CARBON 680 5% 1/4W F
0R157 1-212-881-11 FUSIBLE 100 5% 1/4W
0R158 1-220-893-11 METAL 0.22 10% 5W
R159 1-260-076-11 CARBON 10 5% 1/2W
R160 1-249-441-11 CARBON 100K 5% 1/4W
R161 1-249-417-11 CARBON 1K 5% 1/4W F
R162 1-249-431-11 CARBON 15K 5% 1/4W
R163 1-249-441-11 CARBON 100K 5% 1/4W
******************************************************
1-683-445-11 SUB TRANS BOARD
***************
< CAPACITOR >
0C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
* CN902 1-564-321-21 PIN, CONNECTOR 2P (MX)
CN902 1-568-106-11 PIN, CONNECTOR 4P (AR,E,E51)
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
< RELAY >
0RY901 1-755-276-11 RELAY, POWER
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(AR,E,E51)
< TRANSFORMER >
0T901 1-437-331-11 TRANSFORMER, POWER
******************************************************
1-683-448-11 TC-A BOARD
*********
< DIODE >
D805 8-719-058-03 DIODE SEL5423E-TP15 (G)
D806 8-719-058-03 DIODE SEL5423E-TP15 (g)
< RESISTOR >
R813 1-247-843-11 CARBON 3.3K 5% 1/4W
R814 1-249-425-11 CARBON 4.7K 5% 1/4W F
R815 1-249-427-11 CARBON 6.8K 5% 1/4W F
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-431-11 CARBON 15K 5% 1/4W
R819 1-247-791-91 CARBON 22 5% 1/4W
R820 1-247-791-91 CARBON 22 5% 1/4W
< VARIABLE RESISTOR >
RV801 1-225-739-11 RES, VAR CARBON 50K (GUITAR LEVEL)
RV802 1-225-739-11 RES, VAR CARBON 50K (MIC LEVEL)
To Next Page
