Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR80
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
< SWITCH >
S810 1-762-875-21 SWITCH, KEYBOARD (G)
S811 1-762-875-21 SWITCH, KEYBOARD (g)
S812 1-762-875-21 SWITCH, KEYBOARD (x)
S813 1-762-875-21 SWITCH, KEYBOARD (.m)
S814 1-762-875-21 SWITCH, KEYBOARD (M>)
S815 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
******************************************************
1-683-449-11 TC-B BOARD
*********
< DIODE >
D801 8-719-058-03 DIODE SEL5423E-TP15 (g)
D802 8-719-058-03 DIODE SEL5423E-TP15 (G)
D803 8-719-057-97 DIODE SEL5923A-TP15 (X)
D804 8-719-058-04 DIODE SEL5223S-TP15 (z REC)
< RESISTOR >
R801 1-247-843-11 CARBON 3.3K 5% 1/4W
R802 1-249-425-11 CARBON 4.7K 5% 1/4W F
R803 1-249-427-11 CARBON 6.8K 5% 1/4W F
R804 1-249-429-11 CARBON 10K 5% 1/4W
R805 1-249-431-11 CARBON 15K 5% 1/4W
R806 1-249-433-11 CARBON 22K 5% 1/4W
R807 1-249-435-11 CARBON 33K 5% 1/4W
R808 1-249-439-11 CARBON 68K 5% 1/4W
R809 1-247-791-91 CARBON 22 5% 1/4W
R810 1-247-791-91 CARBON 22 5% 1/4W
R811 1-247-791-91 CARBON 22 5% 1/4W
R812 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (g)
S802 1-762-875-21 SWITCH, KEYBOARD (G)
S803 1-762-875-21 SWITCH, KEYBOARD (x)
S804 1-762-875-21 SWITCH, KEYBOARD (.m)
S805 1-762-875-21 SWITCH, KEYBOARD (M>)
S806 1-762-875-21 SWITCH, KEYBOARD (z REC)
S807 1-762-875-21 SWITCH, KEYBOARD (X)
S808 1-762-875-21 SWITCH, KEYBOARD (H SPEED DUB)
S809 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
******************************************************
1-683-444-11 TRANS BOARD
***********
7-685-646-79 SCREW +BVTP3X8 TYPE2 N-S
< CAPACITOR >
C834 1-137-749-11 MYLAR 0.1uF 100V
C893 1-137-749-11 MYLAR 0.1uF 100V
C961 1-162-306-11 CERAMIC 0.01uF 30% 16V
C963 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
* CN951 1-564-214-11 PIN, CONNECTOR (B3PS-VH) 3P
* CN952 1-564-526-11 PLUG, CONNECTOR 11P
< DIODE >
D832 8-719-066-42 DIODE RBV1306
< FUSE HOLDER >
FH951 1-533-217-31 HOLDER, FUSE (AR,E,E51)
FH952 1-533-217-31 HOLDER, FUSE (AR,E,E51)
FH961 1-533-217-31 HOLDER, FUSE
FH962 1-533-217-31 HOLDER, FUSE
FH963 1-533-217-31 HOLDER, FUSE
FH964 1-533-217-31 HOLDER, FUSE
FH965 1-533-217-31 HOLDER, FUSE
FH966 1-533-217-31 HOLDER, FUSE
FH967 1-533-217-31 HOLDER, FUSE
FH968 1-533-217-31 HOLDER, FUSE
< RESISTOR >
0R951 1-219-121-11 FUSIBLE 0.22 5% 1/4W
0R952 1-219-121-11 FUSIBLE 0.22 5% 1/4W
0R953 1-219-591-11 FUSIBLE 0.1 5% 1/2W
*******************************************************
MISCELLANEOUS
*************
0 1-569-008-21 ADAPTOR, CONVERSION (E51)
4 1-693-572-11 TUNER (FM/AM) (AR,MX)
4 1-693-574-11 TUNER (FM/AM) (E,E51)
5 1-769-945-11 WIRE (FLAT TYPE) (11 CORE)
7 1-535-706-21 PLUG, JUMPER (MX)
60 1-796-333-11 DECK, MECHANICAL
61 1-773-021-11 WIRE (FLAT TYPE) (15 CORE)
113 1-773-118-11 WIRE (FLAT TYPE) (19 CORE)
115 1-773-178-11 WIRE (FLAT TYPE) (23 CORE)
151 1-823-750-11 WIRE (FLAT TYPE) (21 CORE)
0156 1-575-653-11 CORD, POWER (MX)
0156 1-777-071-82 CORD, POWER (E51)
0156 1-783-941-12 CORD, POWER (AR)
0156 1-791-901-11 CORD, POWER (E)
555 1-757-710-11 WIRE (FLAT TYPE) (16 CORE)
556 A-4735-188-A BU-30 (60) ASSY
0F951 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8.0AL 250V)
(AR,E,E51)
0F961 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8.0AL 250V)
0F962 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8.0AL 250V)
0F963 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8.0AL 250V)
0F964 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8.0AL 250V)
M201 A-4660-977-A MOTOR ASSY
M901 1-763-072-11 FAN, DC
0T951 1-437-593-11 TRANSFORMER, POWER
*******************************************************
ACCESSORIES
***********
1-477-078-11 REMOTE CONTROL (RM-SR6)
1-501-374-11 ANTENNA, LOOP (AM)
1-501-659-41 ANTENNA (FM)
4-228-953-01 COVER, BATTERY (For RM-SR6)
4-238-809-11 MANUAL, INSTRUCTION (ENGLISH)
4-238-809-21 MANUAL, INSTRUCTION (FRENCH) (E)
4-238-809-31 MANUAL, INSTRUCTION (SPANISH)
TC-B TRANSTC-A
