Sony HD 3CCD - Specifications; Input;Output Connectors; Supplied Accessories

Appendix
Specifications
72
Specifications
System
Video signal 1080/59.94i, 1080/50i (switched with
the BOTTOM switch)
Synchronization
Internal/external synchronization,
automatically switched
Image device 1/3 type (6 mm), 3CCD Interline
transfer type
Total picture elements: Approx.
1,120,000 pixels
Effective picture elements: Approx.
1,020,000 pixels
Lens Carl Zeiss Vario-SonnarT
*
12× (optical), 4× (digital)
Filter diameter: 72 mm (Wide and
tele conversion lenses cannot be
attached.)
f = 4.5 – 54 mm, F1.6 – F2.8
F = 32.5 mm – 390 mm (equivalent
to the focal length of a 35-mm
camera)
Minimum object distance
800 mm (11
7
/
8
inches) (TELE end)
Minimum illumination
6 lux (F1.6) with 50 IRE (WIDE end)
Shutter speed 1/59.94 (1/50) to 1/10,000 sec.
Video S/N 50 dB
Pan/tilt action Horizontal: ±170 degrees
Maximum panning speed: 60
degrees/sec.
Minimum panning speed: 0.25
degrees/sec.
Vertical: +90 degrees, -30 degrees
Maximum tilting speed: 60 degrees/
sec.
Minimum tilting speed: 0.25
degrees/sec.
Input/output connectors
Video output
D-sub 15-pin
RGB: 0.7Vp-p (no sync, at 75-ohm
termination)
1Vp-p (±0.3V, tri-level sync,
at 75-ohm termination)
Component :
Y: 1Vp-p (±0.3V, tri-level sync,
at 75-ohm termination)
Pb/Pr: ±350 mVp-p, 75-ohm
terminated
HD/VD Sync: 1Vp-p, 75-ohm
terminated
Tri-level Sync: ±300 mVp-p, 75-
ohm terminated
External sync input
EXT SYNC IN: BNC type
Control input/output
VISCA RS-232C IN: Mini DIN 8-pin
type
VISCA RS-232C OUT: Mini DIN 8-
pin type
VISCA RS-422: 9-pin type
Control signal format
9600 bps/38400 bps
Data: 8 bit
Stop bit: 1
Power connector
JEITA type4 (DC IN 12V)
General
Input voltage 12 V DC (10.8 to 13.2 V DC)
Current consumption
2.0 A max. (at 12 V DC), 24 W without
optional interface board
Operating temperature
0ºC to 40ºC (32ºF to 104ºF)
Storage temperature
–20ºC to +60ºC (-4ºF to 140ºF)
Dimensions Video camera: ø207 × 315.8 mm
(ø8
1
/
4
× 12
1
/
2
inches) (diameter/h)
(excluding protruding parts)
Remote Commander: 56 × 26 × 210
mm (2
1
/
4
× 1
1
/
16
× 8
3
/
8
inches) (w/
h/d)
Mass Video camera: Approx. 4.5 kg (9 lb 15
oz)
Remote Commander: 110 g (3.9 oz)
Installation angle
Less than ±15 degrees to the horizontal
surface
Supplied accessories
AC power adaptor MPA-AC1 (Sony) (100 V AC, 50/60
Hz) (1)
AC power cord (1)
Remote Commander (1)
Ceiling bracket (A) (1)
Ceiling bracket (B) (1)
Wire rope (1)
Screws (3M3 × 8) (7)
Screw (3M4 × 8) (1)
RS-422 connector plug (1)
Operating Instructions (1)
Design and specifications are subject to change without
notice.
