HDC-HS9E-S,EB-S,EG-S,EE-S,EP-S,GC-S,GN-S,GK-S,SG-S,P-S,PC-S,PL-S voL.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
R6410 ERJ2GEJ105 M.RESISTOR CH 1/16W 1M 1
## VEP03H43B MAIN P.C.B. 1 (RTL)E.S.D. P,PC,PL R7001 ERJ2GEJ473Y M.RESISTOR CH 1/16W 47K 1
R7003 ERJ2GEJ470 M.RESISTOR CH 1/16W 47 1
## VEP03H43C MAIN P.C.B. 1 (RTL)E.S.D. E,EG R7004 ERJ8GEYJ105V M.RESISTOR CH 1/8W 1M 1
R7005 ERJ2GEJ334 M.RESISTOR CH 1/16W 330K 1
## VEP03H43N MAIN P.C.B. 1 (RTL)E.S.D. EB R7006 ERJ2GEJ564 M.RESISTOR CH 1/16W 560K 1
R7007 ERJ3GEYJ104 M.RESISTOR CH 1/10W 100K 1
## VEP03H43E MAIN P.C.B. 1 (RTL)E.S.D. EE R7008 ERJ2GEJ101 M.RESISTOR CH 1/16W 100 1
R7009 ERJ2GEJ222 M.RESISTOR CH 1/16W 2.2K 1
## VEP03H43P MAIN P.C.B. 1 (RTL)E.S.D. EP R7010 ERJ2GEJ222 M.RESISTOR CH 1/16W 2.2K 1
R7011 ERJ2GEJ104 M.RESISTOR CH 1/16W 100K 1
## VEP03H43D MAIN P.C.B. 1 (RTL)E.S.D. GC,SG R7013 ERJ2GEJ822 M.RESISTOR CH 1/16W 8.2K 1
R7014 ERJ2GEJ223 M.RESISTOR CH 1/16W 22K 1
## VEP03H43R MAIN P.C.B. 1 (RTL)E.S.D. GN R7015 ERJ2GEJ560 M.RESISTOR CH 1/16W 56 1
R7022 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1
## VEP03H43F MAIN P.C.B. 1 (RTL)E.S.D. GK
T7001 G5DYA0000084 SWITCHING TRANSFORMER 1
## VEP01A02B SUB P.C.B. 1 (RTL)E.S.D. T7002 G5F1A0000021 TRIGGER COIL 1
## VEP26312A FLASH P.C.B. 1 (RTL)E.S.D. ZB6401 K3ZZ00500014 CONNECTOR 1
## VEP29200A SIDE (R) P.C.B. 1 (RTL)E.S.D.
## VEP24191A MIC P.C.B. 1 (RTL)E.S.D. ## VEP29200A SIDE (R) P.C.B. (RTL)E.S.D.
## VEP26301A MONITOR P.C.B. 1 (RTL)E.S.D. C601 F3F0G4760003 E.CAPACITOR CH 4V 47U 1
C604 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C605 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C606 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
## VEP26312A FLASH P.C.B. (RTL)E.S.D. C607 F1H0J225A002 C.CAPACITOR CH 6.3V 2.2U 1
C608 F1H0J225A002 C.CAPACITOR CH 6.3V 2.2U 1
B6401 ML-614S/ZT BATTERY 1 E.S.D.(BMI) C609 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C613 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C6401 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C614 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C6402 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1 C615 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C6403 F3F0J226A032 T.CAPACITOR CH 6.3V 22U 1 C616 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1
C6404 F3F0J476A032 E.CAPACITOR CH 6.3V 47U 1 C6501 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1
C7001 ECJ1VB1C105K C.CAPACITOR CH 16V 1U 1 C6502 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1
C7004 F2AZZ5600001 CAPACITOR 1 C6503 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1
C7005 F1K2E4730005 SURFACE MOUNTING MULTILAY 1 C6504 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1
C7006 F1G1A104A012 C.CAPACITOR CH 10V 0.1U 1 C6505 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C7007 ECJ1VB1H103K C.CAPACITOR CH 50V 0.01U 1 C6506 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C7010 F1K2E223A004 C.CAPACITOR 250V 0.022U 1 C6508 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1
C7099 F1J1C335A121 C.CAPACITOR CH 16V 3.3U 1 C6509 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C6511 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1
D7001 MA2S11100L DIODE 1 E.S.D. C6512 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1
D7002 B0ECGP000006 DIODE 1 E.S.D. C6513 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
D7003 MA2YF8000L DIODE 1 E.S.D.
D7004 B0BC30000001 DIODE 1 E.S.D. FP601 K1MN25BA0199 CONNECTOR 25P 1
D7006 B0JCDD000002 DIODE 1 E.S.D. FP6502 K1MN29BA0259 CONNECTOR 29P 1
FP6401 K1MN10BA0197 CONNECTOR 10P 1 IC601 C1AB00002388 IC 1 (RTL)E.S.D.
FP6402 K1MN16BA0197 CONNECTOR 16P 1 IC604 C0DBGGC00011 IC 1 (RTL)E.S.D.
IC6401 L2ES00000017 GYROSCOPE 1 R603 ERJ2RHD511 M.RESISTOR CH 1/16W 510 1
R604 ERJ2RHD102 M.RESISTOR CH 1/16W 1K 1
L6401 G1C100KA0115 CHIP INDUCTOR 10UH 1 R605 D0YAR0000007 M.RESISTOR CH 1/16W 0 1
L7001 G1C560MA0024 CHIP INDUCTOR 56UH 1 R606 D0YAR0000007 M.RESISTOR CH 1/16W 0 1
R6501 ERJ2GEJ183 M.RESISTOR CH 1/16W 18K 1
P6401 K1KA02BA0014 CONNECTOR 2P 1 R6502 ERJ2GEJ302 M.RESISTOR CH 1/16W 3K 1
R6503 ERJ2RHD682X M.RESISTOR CH 1/16W 6.8K 1
PS6401 K1KA30B00077 CONNECTOR 30P 1 R6504 D0YAR0000007 M.RESISTOR CH 1/16W 0 1
R6506 ERJ2GEJ101 M.RESISTOR CH 1/16W 100 1
Q7001 2SC6054J0L TRANSISTOR 1 E.S.D. R6507 ERJ2GEJ473Y M.RESISTOR CH 1/16W 47K 1
Q7002 B1ABPF000009 TRANSISTOR 1 E.S.D. R6508 D0YAR0000007 M.RESISTOR CH 1/16W 0 1
Q7003 2SC6054J0L TRANSISTOR 1 E.S.D. R6509 ERJ2GEJ473Y M.RESISTOR CH 1/16W 47K 1
Q7004 XP0460100L TRANSISTOR 1 E.S.D. R6510 ERJ2GEJ392 M.RESISTOR CH 1/16W 3.9K 1
Q7005 B1JBLP000014 TRANSISTOR 1 E.S.D. R6511 D0YAR0000007 M.RESISTOR CH 1/16W 0 1
R6512 ERJ2GEJ302 M.RESISTOR CH 1/16W 3K 1
QR6402 UNR91A5J0L TRANSISTOR 1 E.S.D. R6513 ERJ2GEJ392 M.RESISTOR CH 1/16W 3.9K 1
QR6403 UNR91A5J0L TRANSISTOR 1 E.S.D. R6514 ERJ2RHD682X M.RESISTOR CH 1/16W 6.8K 1
QR7001 UNR92A4J0L TRANSISTOR 1 E.S.D. R6515 ERJ2GEJ183 M.RESISTOR CH 1/16W 18K 1
QR7008 UNR92A4J0L TRANSISTOR 1 E.S.D. R6516 ERJ2GEJ103 M.RESISTOR CH 1/16W 10K 1
R6517 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1
R6401 ERJ6GEYJ222V M.RESISTOR CH 1/10W 2.2K 1
R6407 ERJ2GEJ331 M.RESISTOR CH 1/16W 330 1 S6501 K0H1BA000436 SWITCH 1
R6408 ERJ2GEJ470 M.RESISTOR CH 1/16W 47 1 S6502 K0H1BA000436 SWITCH 1
S-20
To Next Page
