HDC-HS9E-S,EB-S,EG-S,EE-S,EP-S,GC-S,GN-S,GK-S,SG-S,P-S,PC-S,PL-S voL.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
S6503 K0H1BA000436 SWITCH 1
S6504 K0H1BA000436 SWITCH 1 FP901 K1MN23AA0035 CONNECTOR 23P 1
S6505 EVQPQ6B55 SWITCH 1 FP902 K1MN20BA0262 CONNECTOR 20P 1
S6506 VSS0533 SWITCH 1
S6507 K0MG55000004 SWITCH 1 L901 G1C101KA0055 CHIP INDUCTOR 100UH 1
S6508 K0H1BA000436 SWITCH 1
Q901 2SC6054J0L TRANSISTOR 1 E.S.D.
VA6505 D4ED18R00003 VARISTORS 1 Q902 2SC6054J0L TRANSISTOR 1 E.S.D.
VA6506 D4ED18R00003 VARISTORS 1 Q903 2SC6054J0L TRANSISTOR 1 E.S.D.
Q905 2SA2174J0L TRANSISTOR 1 E.S.D.
Q910 2SA2174J0L TRANSISTOR 1 E.S.D.
## VEP24191A MIC P.C.B. (RTL)E.S.D. R901 ERJ2RKD220 M.RESISTOR CH 1/16W 22 1
R902 ERJ2RKD220 M.RESISTOR CH 1/16W 22 1
C4801 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1 R903 ERJ2RKD220 M.RESISTOR CH 1/16W 22 1
C4802 ECJ0EC1H220J C.CAPACITOR CH 50V 22P 1 R904 D0YAR0000007 M.RESISTOR CH 1/16W 0 1
C4803 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1 R905 D0YAR0000007 M.RESISTOR CH 1/16W 0 1
C4804 ECJ0EC1H220J C.CAPACITOR CH 50V 22P 1 R906 D0YAR0000007 M.RESISTOR CH 1/16W 0 1
C4805 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1 R910 ERJ2GEJ104 M.RESISTOR CH 1/16W 100K 1
C4806 ECJ0EC1H220J C.CAPACITOR CH 50V 22P 1 R913 ERJ2RHD273 M.RESISTOR CH 1/16W 27K 1
C4807 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1 R914 ERJ2RHD103 M.RESISTOR CH 1/16W 10K 1
C4808 ECJ0EC1H220J C.CAPACITOR CH 50V 22P 1 R915 ERJ2GEJ152 M.RESISTOR CH 1/16W 1.5K 1
C4809 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1
C4810 ECJ0EC1H220J C.CAPACITOR CH 50V 22P 1
C4811 ECJ0EC1H101J C.CAPACITOR CH 50V 100P 1
C4812 ECJ0EC1H101J C.CAPACITOR CH 50V 100P 1
C4813 ECJ0EC1H101J C.CAPACITOR CH 50V 100P 1
C4814 ECJ0EC1H101J C.CAPACITOR CH 50V 100P 1
C4815 ECJ0EC1H101J C.CAPACITOR CH 50V 100P 1
C4816 F3E0J106A009 E.CAPACITOR CH 6.3V 22U 1
C4817 F3F0J226A032 T.CAPACITOR CH 6.3V 22U 1
C4818 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
FP4801 K1MN08BA0197 CONNECTOR 8P 1
FP4802 K1MN10BA0197 CONNECTOR 10P 1
IC4801 C0ABBB000369 IC 1 E.S.D.
IC4802 C0ABBB000369 IC 1 E.S.D.
IC4803 C0ABBB000369 IC 1 E.S.D.
Q4801 2SD2216J0L TRANSISTOR 1 E.S.D.
R4801 VRE0071E392 M.RESISTOR CH 1/10W 3.9K 1
R4802 VRE0071E392 M.RESISTOR CH 1/10W 3.9K 1
R4803 VRE0071E392 M.RESISTOR CH 1/10W 3.9K 1
R4804 VRE0071E392 M.RESISTOR CH 1/10W 3.9K 1
R4805 VRE0071E392 M.RESISTOR CH 1/10W 3.9K 1
R4806 ERJ2GEJ183 M.RESISTOR CH 1/16W 18K 1
R4807 ERJ2GEJ154 M.RESISTOR CH 1/16W 150K 1
R4808 ERJ2GEJ183 M.RESISTOR CH 1/16W 18K 1
R4809 ERJ2GEJ154 M.RESISTOR CH 1/16W 150K 1
R4810 ERJ2GEJ183 M.RESISTOR CH 1/16W 18K 1
R4811 ERJ2GEJ154 M.RESISTOR CH 1/16W 150K 1
R4812 ERJ2GEJ183 M.RESISTOR CH 1/16W 18K 1
R4813 ERJ2GEJ154 M.RESISTOR CH 1/16W 150K 1
R4814 ERJ2GEJ183 M.RESISTOR CH 1/16W 18K 1
R4815 ERJ2GEJ154 M.RESISTOR CH 1/16W 150K 1
R4816 ERJ2GEJ472 M.RESISTOR CH 1/16W 4.7K 1
R4817 ERJ2GEJ223 M.RESISTOR CH 1/16W 22K 1
R4818 ERJ2GEJ333 M.RESISTOR CH 1/16W 33K 1
## VEP26301A MONITOR P.C.B. (RTL)E.S.D.
C901 F1J1A475A023 C.CAPACITOR CH 10V 4.7U 1
C907 F1H0J225A002 C.CAPACITOR CH 6.3V 2.2U 1
C908 F1J1A2250007 C.CAPACITOR CH 10V 2.2U 1
C909 F1H0J475A010 C.CAPACITOR CH 6.3V 4.7U 1
C910 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C912 F1H0J475A010 C.CAPACITOR CH 6.3V 4.7U 1
D901 B3AFB0000200 LED 1 E.S.D.
D902 B3AFB0000200 LED 1 E.S.D.
D903 B3AFB0000200 LED 1 E.S.D.
D905 MAZ80470HL DIODE 1 E.S.D.
D909 MAZ80620ML DIODE 1 E.S.D.
