HDC-HS9E-S,EB-S,EG-S,EE-S,EP-S,GC-S,GN-S,GK-S,SG-S,P-S,PC-S,PL-S voL.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
B46 XQN16+BJ5FJK SCREW 1
1 VYQ4213 LENS HOOD UNIT 1 B47 VHD1919 SCREW 1
2 VKM7395 R COVER 1 B48 XQN16+BJ4FN SCREW 1
3 VYK2J60 SIDE CASE (L) UNIT 1 B49 XQN16+BJ4FN SCREW 1
13 VYQ4211 MIC NET UNIT 1 B50 XQN16+BJ4FN SCREW 1
14 VSC6035 FRONT EARTH PLATE (R4060/ 1 B51 XQN16+BJ4FN SCREW 1
15 N9ZZ00000326 BARRIER MOTOR UNIT 1 B52 XQN16+BJ4FN SCREW 1
16 VML3925-1 BARRIER SELECT KNOB 1 B53 XQN16+BJ4FN SCREW 1
17 VDW1233-2 FRONT FRAME 1 B54 XQN16+BJ4FN SCREW 1
18 VMG1705 LENS DAMPER RUBBER 1 B55 XQN16+BJ4FN SCREW 1
19 VKM7388 FRONT CASE 1 B56 XQN16+BJ4FN SCREW 1
20 VGQ9846 SHEET 1 B57 XQN16+BJ4FN SCREW 1
21 VMG1107 DUMPER RUBBER 1 B58 VHD1411 SCREW 1
22 VMP9013 HINGI ANGLE 1 B58 XQN16+BJ4FN SCREW 1
26 N9ZZ00000387 ELECTRONIC COMPONENTS, NO 1 B59 VHD1411 SCREW 1
27 VMP9010 MIC ANGLE 1 B60 VHD2012 SCREW 1
28 VWJ2019 MIC FPC 1 B61 VHD2012 SCREW 1
29 VEP24191A MIC P.C.B. 1 (RTL)E.S.D.
30 VGQ9862 SHEET 1
31 VMP9009 TOP FRAME 1
32 L0AA02A00075 SPEAKER UNIT 1
33 VGQ9752 BOUON SHEET 1
34 VGL1269 LENS 1
35 VKA0397 SET LEG CUSHION 1
36 VKW3378 SENSOR WINDOW 1
37 VEP29200A SIDE (R) P.C.B. 1 (RTL)E.S.D.
38 VGU0C22 OPERATION BUTTON 1
39 VGU0B50 SR SWITCH KNOB 1
40 VSC6034 SR EARTH BOARD 1
41 VKF4324 JACK COVER 1
42 VMG1822 LCD UKEGOMU(A) 1
43 VKM7452 SIDE CASE R 1
44 VGQ9735 CROSS KEY 1
45 VGQ9753 JOY CUSHION 1
46 VWJ2020 SIDE_R FPC 1
47 VEP04930B ECM FPC 1
48 VMT1784 MIC DUMPER 1
49 VQL1R55 CAUTION LABEL 1 P
49 VQL1R56 CAUTION LABEL 1 PC
49 VQL1R57 CAUTION LABEL 1 E,EB,EG,EE,EP,GC,GN,SG,PL
70 N3CZBSH00001 HDD UNIT 1
71 VKM7384 TOP PIECE 1
72 VKM7383 TOP COVER 1
73 VYK2L07 HDD SHIELD FRAME UNIT 1
74 LSMG0196 CUSHION 1
75 LSMG0196 CUSHION 1
76 VEP79198A HDD FPC 1 E.S.D.
77 VSC6032 HDD SHIELD CASE 1
78 VKM7382 TOP CASE 1
80 VGQ9886 FPC FIXER 1
B1 XQN16+B4FN SCREW 1
B2 XQN16+B4FN SCREW 1
B3 XQN16+B4FN SCREW 1
B4 XQN16+B4FJK SCREW 1
B5 XQN16+B4FJK SCREW 1
B6 XQN16+BJ5FJK SCREW 1
B7 XQN16+BJ4FJK SCREW 1
B8 XQN16+BJ4FJK SCREW 1
B11 XQN16+B4FJK SCREW 1
B12 XQN16+B4FJK SCREW 1
B13 XQN16+B5FJK SCREW 1
B16 XQN16+B5FN SCREW 1
B17 XQN16+B5FN SCREW 1
B18 XQN16+B5FN SCREW 1
B19 XQN16+B5FN SCREW 1
B20 XQN16+B5FN SCREW 1
B21 XQN16+B5FN SCREW 1
B22 XQN16+B4FJK SCREW 1
B23 XQN16+B4FJK SCREW 1
B24 XQN16+B4FJK SCREW 1
B25 XQN16+B4FJK SCREW 1
B26 VHD1919 SCREW 1
B27 VHD1919 SCREW 1
B40 XQN16+BJ6FN SCREW 1
B41 XQN16+BJ6FN SCREW 1
B42 XQN16+BJ6FN SCREW 1
S-22
