Sony HDC-HS9P - Page 68

HDC-HS9E-S,EB-S,EG-S,EE-S,EP-S,GC-S,GN-S,GK-S,SG-S,P-S,PC-S,PL-S voL.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
4 VSC5761 CCD HEAT SINK PLATE 1
5 VGQ9574 CCD RADIATION SHEET 1
6 VGQ9834 GASKET 1
7 VMP9094 PLATE 1
8 VEP03H43B MAIN P.C.B. 1 P,PC,PL (RTL)E.S.D.
8 VEP03H43C MAIN P.C.B. 1 E,EG (RTL)E.S.D.
8 VEP03H43N MAIN P.C.B. 1 EB (RTL)E.S.D.
8 VEP03H43E MAIN P.C.B. 1 EE (RTL)E.S.D.
8 VEP03H43P MAIN P.C.B. 1 EP (RTL)E.S.D.
8 VEP03H43D MAIN P.C.B. 1 GC,SG (RTL)E.S.D.
8 VEP03H43R MAIN P.C.B. 1 GN (RTL)E.S.D.
8 VEP03H43F MAIN P.C.B. 1 GK (RTL)E.S.D.
9 VYK2J52 MAIN FRAME UNIT 1
10 VEP21298A MAIN-SUB FPC 1 E.S.D.
11 VEP01A02B SUB P.C.B. 1 (RTL)E.S.D.
12 VYK2J49 BOTTOM FRAME UNIT 1
23 VSC6031 CCD SHIELD CASE 1
24 VMP9005 REAR FRAME 1
25 VEP21297A POWER FPC 1 E.S.D.
50 VEP26312A FLASH P.C.B. 1 (RTL)E.S.D.
51 VYK2J51 LENS PLATE UNIT 1
52 EFN-MVY55ZC FLASH 1
53 VGQ9726 CONDENSOR COVER 1
55 VYK2J56 SD DOOR UNIT 1
56 VKM7381 BATTERY CASE 1
57 VGQ9767 BATT RELEASE HOLDER 1
58 VGQ9728 BATTERY RELEASE KNOB 1
59 VMB4179 BATTERY RELEASE SPRING 1
60 VKF4293 HDMI COVER 1
79 VGQ9887 CUSHION 1
81 VGQ9888 CUSHION 1
82 VSC6036 REAR EARTH ANGLE 1
B9 XQN16+B6FJK SCREW 1
B10 XQN16+B6FJK SCREW 1
B14 XQN16+B5FJK SCREW 1
B15 XQN16+B5FJK SCREW 1
B28 XQN16+B3FJK SCREW 1
B29 XQN16+B4FJK SCREW 1
B30 XQN16+BJ5FJK SCREW 1
B31 VHD1353 SCREW 1
B32 XQN16+BJ4FN SCREW 1
B33 VHD1907 SCREW 1
B34 VHD1907 SCREW 1
B35 VHD1907 SCREW 1
B36 VHD1907 SCREW 1
B37 VHD1907 SCREW 1
B38 VHD1907 SCREW 1
B39 XQN16+BJ4FN SCREW 1
B43 XQN16+BJ4FN SCREW 1
B44 VHD1907 SCREW 1
B45 XQN16+B4FJK SCREW 1
B62 XQN16+BJ4FN SCREW 1
B63 XQN16+BJ4FN SCREW 1
S-23
