4-4. CONNECTORS (KLV-37L400A ONLY)
121
129
127
128
124
126
125
123
122
SP
UM
SP
INV
G5M
T-CON
HL5
BG2A
3008
4001
1400
4003 4002
4500
CN2000
CN6203 CN6202 CN6201
CN101
CN301
HL1
(KLV-37L400A)
121 1-835-686-11 LEAD WIRE WITH CONNECTOR (LVDS)
122 1-910-045-03 CONN ASSEMBLY, 20P MM CRIMP 210
123 1-910-045-05 WIRE ASSEMBLY, FASTON TERMINAL
124 1-910-044-94 CONN ASSEMBLY, 4P SPEAKER FASTON
124 1-910-044-92 CONN ASSEMBLY, 4P SPEAKER FASTON
! 125 1-832-159-13 CORD, POWER (WITH CONNECTOR)
126 1-910-038-34 CONN ASSEMBLY, 13P MM CRIMP 340
127 1-910-044-77 CONN ASSEMBLY, 11P MM CRIMP 890
128 1-910-047-30 CONN ASSEMBLY, 6P MM CRIMP 430
129 1-910-047-29 CONN ASSEMBLY, 14P MM CRIMP 700
2-580-591-01 SCREW, +PSW M3X5
