KLV-32L400A/37L400A
KLV-32L400A/37L400A
54
*
Items marked with an asterisk are not stocked since they
are seldom required for routine service. Expect some delay
when ordering these components.
RESISTORS
• All resistors are in ohms
• F : nonfl ammable
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
REF. NO.ART NO. DESCRIPTION VALUES
When ordering parts by reference
number, please include the board name.
REF. NO.ART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: The components identifi ed by a red outline and a mark
contain confi dential information. Specifi c instructions must be
adhered to whenever these components are repaired and/or
replaced.
See Appendix A: Encryption Key Components in the back of this
manual.
BG2A
SECTION 5: ELECTRICAL PARTS LIST
BG2A
A-1556-837-A BG2A BOARD, MOUNTED
(KLV-32L400A ONLY)
A-1556-847-A BG2A BOARD, MOUNTED
(KLV-37L400A ONLY)
1-835-447-11 P-FCABLE
2-586-175-11 SHEET B, RADIATION
CAPACITOR
C1004 1-112-781-11 CERAMIC CHIP 1μF 10% 10V
C1006 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C1007 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C1013 1-112-777-11 CERAMIC CHIP 0.01μF 10% 25V
C1014 1-112-777-11 CERAMIC CHIP 0.01μF 10% 25V
C1015 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1016 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1020 1-112-777-11 CERAMIC CHIP 0.01μF 10% 25V
C1104 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C1105 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C1106 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C1107 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C1108 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1109 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1110 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1111 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1702 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C1703 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C1712 1-162-964-11 CERAMIC CHIP 0.001μF 10% 50V
C1713 1-162-964-11 CERAMIC CHIP 0.001μF 10% 50V
C1714 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1715 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1722 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C1723 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C1724 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1725 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1729 1-112-777-11 CERAMIC CHIP 0.01μF 10% 25V
C2013 1-135-366-11 ELECT CHIP 100μF 20% 16V
C2014 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C2016 1-114-331-11 CERAMIC CHIP 4.7μF 10% 10V
C2017 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C2019 1-100-911-11 CERAMIC CHIP 4.7μF 10% 25V
C2022 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C2025 1-114-331-11 CERAMIC CHIP 4.7μF 10% 10V
C2027 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C2029 1-164-849-11 CERAMIC CHIP 9pF 0.50pF 50V
C2030 1-164-849-11 CERAMIC CHIP 9pF 0.50pF 50V
C2033 1-114-325-11 CERAMIC CHIP 0.1μF 10% 25V
C2039 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C2041 1-100-911-11 CERAMIC CHIP 4.7μF 10% 25V
C2042 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C2045 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C2051 1-114-331-11 CERAMIC CHIP 4.7μF 10% 10V
C2052 1-162-959-11 CERAMIC CHIP 330pF 5% 50V
C2053 1-162-959-11 CERAMIC CHIP 330pF 5% 50V
C2054 1-100-911-11 CERAMIC CHIP 4.7μF 10% 25V
C2055 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C2058 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C2059 1-100-911-11 CERAMIC CHIP 4.7μF 10% 25V
C2060 1-135-366-11 ELECT CHIP 100μF 20% 16V
C2061 1-114-325-11 CERAMIC CHIP 0.1μF 10% 25V
C2062 1-114-325-11 CERAMIC CHIP 0.1μF 10% 25V
C2063 1-114-325-11 CERAMIC CHIP 0.1μF 10% 25V
C2064 1-112-781-11 CERAMIC CHIP 1μF 10% 10V
C2065 1-112-781-11 CERAMIC CHIP 1μF 10% 10V
C2067 1-100-911-11 CERAMIC CHIP 4.7μF 10% 25V
C2068 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C2069 1-112-064-11 CERAMIC CHIP 2.2μF 10% 10V
C2070 1-112-064-11 CERAMIC CHIP 2.2μF 10% 10V
C2073 1-114-330-11 CERAMIC CHIP 2.2μF 10% 16V
