4-7. SCREW LEGEND
P/N DISCRIPTION REMARKS TOTAL
KLV-32L400
A
2-580-640-01 SCREW, +BVTP2 4X16
RC-14 TOP(L)-1 TOP(R)-1 BOTOM BRKT-2 UNDER COVER-2 LCD-2 22
7-685-648-79 SCREW +BVTP 3X12 TYPE2 TT(B)
SIDE JACK-1 UM-2 G1-3 HL5-2 RC-2 10
2-580-608-01 SCREW, +PSW M5X16
VESA-2 RC-2 STAND/UC-3 7
2-580-607-01 SCREW, +PSW M5X12
(none) 0
2-580-606-01 SCREW, +PSW M5X8
STAND ASSY-5 5
2-580-644-01 SCREW, +KTP2 3X8
STAND ASSY-9 9
2-580-600-01 SCREW, +PSW M4X8
TOP(L)-2 TOP(R)-2 BOTOM BRKT-4 8
2-580-629-01 SCREW, +BVST 3X8
BG2A-6 RF BRACKET-2 LVDS-1 9
2-674-965-31 SCREW, +PSW 3SG
G1-3 3
2-580-591-01 SCREW, +PSW M3X5
BOTTOM SHIELD-4 4
2-580-654-01 SCREW, +PWTP2 4X16
LCD-1 1
2-580-626-01 SCREW, SP 4-4O UNC
TERMINAL-2 2
KLV-37L400
A
2-580-640-01 SCREW, +BVTP2 4X16
RC-16 TOP(L)-1 TOP(R)-1 BOTOM BRKT-2 UNDER COVER-2 22
7-685-648-79 SCREW +BVTP 3X12 TYPE2 TT(B)
SIDE JACK-1 UM-2 G5-2 HL5-2 RC-2 9
2-580-608-01 SCREW, +PSW M5X16
FRAME BRKT-2 RC-2 STAND/UC-4 8
2-580-607-01 SCREW, +PSW M5X12
STAND ASSY-10 10
2-580-606-01 SCREW, +PSW M5X8
TOP(L)-1 TOP(R)-1 FRAME BRKT-2 4
2-580-644-01 SCREW, +KTP2 3X8
STAND ASSY-9 9
2-580-600-01 SCREW, +PSW M4X8
TOP(L)-1 TOP(R)-1 SIDE(L)-2 SIDE(R)-2 BOTOM BRKT-2 FRAME BRKT-4 12
2-580-629-01 SCREW, +BVST 3X8
BG2A-6 RF BRACKET-2 8
2-674-965-31 SCREW, +PSW 3SG
G5-3 3
2-580-591-01 SCREW, +PSW M3X5
BOTTOM SHIELD-4 LVDS-1 G5-2 7
2-580-654-01 SCREW, +PWTP2 4X16
(none) 0
2-580-626-01 SCREW, SP 4-4O UNC
TERMINAL-2 2
