Sony KLV-32L400A - Page 69

KLV-32L400A/37L400A
KLV-32L400A/37L400A
69
REF. NO.ART NO. DESCRIPTION VALUES
REF. NO.ART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
C6206 1-112-835-11 ELECT 3300μF 20% 25V
C6208 1-107-826-11 CERAMIC CHIP 0.1μF 10% 16V
C6210 1-127-573-11 CERAMIC CHIP 1μF 10% 16V
C6212 1-100-597-91 CERAMIC CHIP 0.1μF 10% 25V
C6251 1-112-208-21 ELECT 470μF 20% 6.3V
C6252 1-112-242-21 ELECT 1500μF 20% 25V
C6254 1-117-699-11 CERAMIC 0.001μF 20% 250V
C6255 1-137-198-81 FILM 1μF 5% 50V
C6256 1-100-591-91 CERAMIC CHIP 1μF 10% 25V
C6258 1-100-591-91 CERAMIC CHIP 1μF 10% 25V
CONNECTOR
CN6101 1-695-915-11 TAB (CONTACT)
CN6102 1-580-843-11 PIN, CONNECTOR (POWER)
* CN6201 1-785-708-11 PIN, CONNECTOR (PC BOARD) 12P
* CN6202 1-793-236-11 PIN, CONNECTOR (PC BOARD) 14P
DIODE
D6101 8-719-510-53 DIODE D4SB60L
D6102 8-719-081-97 DIODE MMDL914T1
D6103 6-500-567-01 DIODE 10ERB20-TA1B2
D6104 6-500-567-01 DIODE 10ERB20-TA1B2
D6105 8-719-081-97 DIODE MMDL914T1
D6106 8-719-081-97 DIODE MMDL914T1
D6107 8-719-027-76 DIODE 1SS357-TPH3
D6108 8-719-081-97 DIODE MMDL914T1
D6109 8-719-054-59 DIODE FSF05A60
D6110 8-719-976-99 DIODE DTZ5.1B
D6111 8-719-081-97 DIODE MMDL914T1
D6112 6-500-335-01 DIODE MC2838-T112-1
D6113 8-719-081-97 DIODE MMDL914T1
D6114 8-719-081-97 DIODE MMDL914T1
D6115 8-719-081-97 DIODE MMDL914T1
!
D6116 6-501-906-01 DIODE 11EQS03LN-TB5
D6119 8-719-027-76 DIODE 1SS357-TPH3
D6120 6-500-448-11 DIODE D1NF60-TA
!
D6121 6-501-906-01 DIODE 11EQS03LN-TB5
D6122 8-719-082-03 DIODE MM3Z15VT1
D6127 8-719-056-83 DIODE UDZ-TE-17-6.8B
D6128 8-719-081-97 DIODE MMDL914T1
D6129 6-501-297-11 DIODE 1F6G-TA26
D6132 8-719-081-97 DIODE MMDL914T1
D6133 6-501-450-11 DIODE 11EFS4-TB5
D6134 6-501-822-11 DIODE 10ERB60-TB5
D6135 6-500-600-01 DIODE MM3Z3V3T1
!
D6136 8-719-931-47 DIODE HZS27NTD
D6137 6-500-021-01 DIODE MM3Z4V7ST1
D6138 8-719-081-97 DIODE MMDL914T1
D6139 6-500-567-21 DIODE 10ERB20-TB5
D6140 6-500-021-01 DIODE MM3Z4V7ST1
D6141 8-719-081-97 DIODE MMDL914T1
D6201 8-719-200-31 DIODE 21DQ05
D6202 6-501-505-01 DIODE FCH08U10
D6203 6-501-505-01 DIODE FCH08U10
D6205 6-501-319-01 DIODE FCQ10A06
D6206 6-500-555-01 DIODE MM3Z27VT1
D6209 8-719-081-97 DIODE MMDL914T1
D6210 8-719-082-03 DIODE MM3Z15VT1
D6211 6-501-319-01 DIODE FCQ10A06
IC
IC6101 6-709-192-01 IC FA5501AN-D1-TE1
!
IC6104 6-707-749-01 IC CXD9841P
!
IC6105 6-708-801-01 IC MIP2H2
IC6201 6-709-155-01 IC TS3431BILT
PHOTO COUPLER
PH6101 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
PH6102 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
PH6103 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
PH6104 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
PH6105 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
IC LINK
!
PS6203 1-533-596-21 IC LINK 4A 90V
TRANSISTOR
Q6102 8-729-141-48 TRANSISTOR 2SB624-BV345
!
Q6103 6-551-303-01 TRANSISTOR 2SK3683-01MR-F111
Q6104 8-729-045-62 TRANSISTOR 2SK2158-T2B
Q6105 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q6106 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q6107 8-729-920-79 TRANSISTOR 2SB1132-T100-QR
Q6108 8-729-027-43 TRANSISTOR DTC114EKA-T146
!
Q6109 6-551-302-01 TRANSISTOR 2SK3561(LBS1SONY,Q
!
Q6110 6-551-302-01 TRANSISTOR 2SK3561(LBS1SONY,Q
Q6111 8-729-045-62 TRANSISTOR 2SK2158-T2B
Q6112 8-729-045-62 TRANSISTOR 2SK2158-T2B
Q6201 8-729-045-62 TRANSISTOR 2SK2158-T2B
G1M
