KLV-32L400A/37L400A
KLV-32L400A/37L400A
72
REF. NO.ART NO. DESCRIPTION VALUES
REF. NO.ART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
C6080 1-112-254-21 ELECT 1000μF 20% 35V
C6083 1-112-242-21 ELECT 1500μF 20% 25V
C6084 1-112-242-21 ELECT 1500μF 20% 25V
C6093 1-100-597-91 CERAMIC CHIP 0.1μF 10% 25V
C6094 1-127-573-11 CERAMIC CHIP 1μF 10% 16V
CONNECTOR
CN6000 1-695-915-11 TAB (CONTACT)
CN6007 1-695-915-11 TAB (CONTACT)
CN6102 1-580-843-11 PIN, CONNECTOR (POWER)
* CN6201 1-793-235-11 PIN, CONNECTOR (PC BOARD) 13P
* CN6202 1-785-703-11 PIN, CONNECTOR (PC BOARD) 6P
CN6203 1-785-705-11 PIN, CONNECTOR (PC BOARD) 9P
CN6204 1-695-915-11 TAB (CONTACT)
DIODE
D6000 6-501-817-01 DIODE MA2J1110GLS0
D6001 6-501-817-01 DIODE MA2J1110GLS0
D6002 6-501-817-01 DIODE MA2J1110GLS0
D6003 8-719-054-89 DIODE D15XB60
D6005 6-500-020-01 DIODE MM3Z4V3ST1
D6006 6-501-817-01 DIODE MA2J1110GLS0
D6007 6-501-817-01 DIODE MA2J1110GLS0
D6008 6-501-817-01 DIODE MA2J1110GLS0
D6014 6-500-137-01 DIODE BAT54HT1
!
D6015 8-719-055-38 DIODE SF5L60
D6016 6-500-108-01 DIODE EP05FA20
D6017 6-500-108-01 DIODE EP05FA20
!
D6019 6-501-817-01 DIODE MA2J1110GLS0
D6020 6-501-817-01 DIODE MA2J1110GLS0
D6021 6-501-817-01 DIODE MA2J1110GLS0
!
D6022 6-501-817-01 DIODE MA2J1110GLS0
!
D6023 8-719-081-67 DIODE M1FM3
D6024 6-501-818-01 DIODE MA2J1130GLS0
D6025 6-501-297-11 DIODE 1F6G-TA26
D6026 6-500-567-31 DIODE 10ERB20-TB3
D6027 6-500-567-31 DIODE 10ERB20-TB3
D6028 6-500-567-31 DIODE 10ERB20-TB3
D6030 6-501-817-01 DIODE MA2J1110GLS0
D6031 8-719-510-02 DIODE D1NS4
D6033 6-500-137-01 DIODE BAT54HT1
!
D6034 8-719-081-67 DIODE M1FM3
!
D6035 8-719-979-64 DIODE UF4005/23
D6036 6-501-817-01 DIODE MA2J1110GLS0
D6042 6-501-917-01 DIODE SG10SC9F5-5009F23
!
D6043 6-501-917-01 DIODE SG10SC9F5-5009F23
D6044 6-501-545-01 DIODE SG10SC6-F5
D6045 6-500-555-01 DIODE MM3Z27VT1
D6046 6-501-817-01 DIODE MA2J1110GLS0
D6047 6-501-545-01 DIODE SG10SC6-F5
D6048 6-501-545-01 DIODE SG10SC6-F5
D6050 6-500-555-01 DIODE MM3Z27VT1
D6051 8-719-082-03 DIODE MM3Z15VT1
D6052 8-719-081-97 DIODE MMDL914T1
FUSE
!
F6000 1-576-233-51 FUSE 6.3A 250V
FERRITE BEAD
FB6001 1-412-911-11 FERRITE 0μH
FB6002 1-412-911-11 FERRITE 0μH
IC
!
IC6000 6-709-192-01 IC FA5501AN-D1-TE1
!
IC6001 6-708-801-01 IC MIP2H2
!
IC6002 6-707-749-01 IC CXD9841P
IC6003 8-759-682-42 IC MM1431ATT
IC6004 6-709-442-01 IC MM1530ATT
IC6005 6-709-368-01 IC MM1431ATT (CN)
!
IC6006 6-709-368-01 IC MM1431ATT (CN)
CHIP CONDUCTOR
JR6000 1-216-295-91 SHORT CHIP
JR6001 1-216-296-11 SHORT CHIP
JR6002 1-216-296-11 SHORT CHIP
JR6003 1-216-295-91 SHORT CHIP
JR6004 1-216-296-11 SHORT CHIP
JR6005 1-216-296-11 SHORT CHIP
JR6006 1-216-296-11 SHORT CHIP
JR6007 1-216-296-11 SHORT CHIP
JR6008 1-216-296-11 SHORT CHIP
JR6009 1-216-296-11 SHORT CHIP
JR6010 1-216-296-11 SHORT CHIP
JR6011 1-216-296-11 SHORT CHIP
JR6012 1-216-296-11 SHORT CHIP
JR6013 1-216-295-91 SHORT CHIP
JR6014 1-216-296-11 SHORT CHIP
JR6015 1-216-296-11 SHORT CHIP
JR6020 1-216-295-91 SHORT CHIP
JR6021 1-216-295-91 SHORT CHIP
G5M
