KLV-32L400A/37L400A
KLV-32L400A/37L400A
75
REF. NO.ART NO. DESCRIPTION VALUES
REF. NO.ART NO. DESCRIPTION VALUES
TRANSFORMER
T6000 1-443-984-21 CONVERTER TRANSFORMER (SBT)
VARISTOR
VD6000 1-804-996-21 VARISTOR
VD6001 1-804-996-21 VARISTOR
HL1
* A-1540-623-A HL1 BOARD, MOUNTED
CONNECTOR
CN101 1-821-980-11 HEADER ASSEMBL FOR PWB
RESISTOR
R101 1-218-827-11 METAL CHIP 150 0.50% 1/10W
R102 1-218-831-11 METAL CHIP 220 0.50% 1/10W
R103 1-218-835-11 METAL CHIP 330 0.50% 1/10W
R104 1-218-841-11 METAL CHIP 560 0.50% 1/10W
R105 1-218-848-11 METAL CHIP 1.1K 0.50% 1/10W
R107 1-216-864-11 SHORT CHIP
SWITCH
S101 1-572-595-11 SWITCH, TACTILE (REFLOW TYPE)
S102 1-572-595-11 SWITCH, TACTILE (REFLOW TYPE)
S103 1-572-595-11 SWITCH, TACTILE (REFLOW TYPE)
S104 1-572-595-11 SWITCH, TACTILE (REFLOW TYPE)
S105 1-572-595-11 SWITCH, TACTILE (REFLOW TYPE)
S106 1-572-595-11 SWITCH, TACTILE (REFLOW TYPE)
S107 1-572-595-11 SWITCH, TACTILE (REFLOW TYPE)
HL5
* A-1540-624-A HL5 BOARD, MOUNTED
CAPACITOR
C320 1-112-781-11 CERAMIC CHIP 1μF 10% 10V
C322 1-107-826-11 CERAMIC CHIP 0.1μF 10% 16V
C323 1-126-205-11 ELECT CHIP 47μF 20% 6.3V
C401 1-162-960-11 CERAMIC CHIP 220pF 10% 50V
C402 1-100-909-11 CERAMIC CHIP 10μF 10% 6.3V
CONNECTOR
CN101 1-821-980-11 HEADER ASSEMBL FOR PWB
* CN301 1-820-287-11 HEADER ASSEMBLY (PRINT PWB)
DIODE
D305 8-719-085-26 DIODE CL-165HR/SYG-D-T
D308 8-719-053-07 DIODE SML-310MTT86
D321 6-500-817-01 DIODE (LED) SML-512UWT86
D322 8-719-036-94 DIODE RD5.6SB-T1
IC
IC401 6-600-681-01 IC RS-770N
TRANSISTOR
Q303 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q304 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q305 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q320 6-551-699-01 TRANSISTOR ISA1602AM1TP-1EF
Q321 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q322 8-729-028-96 TRANSISTOR DTC114EUA-T106
RESISTOR
R303 1-216-815-11 METAL CHIP 330 5% 1/10W
R304 1-216-819-11 METAL CHIP 680 5% 1/10W
R305 1-216-815-11 METAL CHIP 330 5% 1/10W
R321 1-216-839-11 METAL CHIP 33K 5% 1/10W
R322 1-216-821-11 METAL CHIP 1K 5% 1/10W
R323 1-216-833-11 METAL CHIP 10K 5% 1/10W
R325 1-216-864-11 SHORT CHIP
R326 1-216-847-11 METAL CHIP 150K 5% 1/10W
R328 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R329 1-216-819-11 METAL CHIP 680 5% 1/10W
R330 1-216-821-11 METAL CHIP 1K 5% 1/10W
R401 1-216-817-11 METAL CHIP 470 5% 1/10W
R402 1-216-805-11 METAL CHIP 47 5% 1/10W
UM
A-1268-473-A UM BOARD, MOUNTED
CAPACITOR
C203 1-216-864-11 SHORT CHIP
C206 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C209 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C215 1-162-964-11 CERAMIC CHIP 0.001μF 10% 50V
CONNECTOR
* CN201 1-819-928-11 HEADER ASSEMBLY 20P
CN202 1-695-915-11 TAB (CONTACT)
G5M
HL5HL1
