57
4-7. LASER POWER ADJUSTMENT
Check the IOP value of the optical pick-up before adjustments.
(Refer to 4-5. Recording and Displaying IOP Information)
Connection :
Adjusting Procedure :
1. Load the laser power meter into the disc inlet and set it on the
objective lens of the optical pick-up.
Connect the digital voltmeter to CN105 pin 1 (I+3V) and
CN105 pin 2 (IOP) on the BD board.
2. Turn the l AMS L knob to display LDPWR ADJUS
(C04).
3. Press the YES button once to display LD 0.9 mW $ .
4. Turn the l AMS L knob so that the reading of the laser
power meter becomes 0.85 to 0.91 mW. Press the YES button
after setting the range knob of the laser power meter, and save
the adjustment results in the non-volatile memory. (LD SAVE
$ will be displayed for a moment)
5. Then LD 7.0 mW $ will be displayed.
6. Turn the l AMS L knob so that the reading of the laser
power meter becomes 6.9 to 7.1 mW, press the YES button to
save it. (LD SAVE $
will be displayed for a moment)
Note: Do not perform the emission with 7.0 mW more than 15 seconds
continuously.
7. Then, turn the l AMS L knob to display LDPWR
CHECK (C13).
8. Press the YES button once to display LD 0.9 mW $ .
Check that the reading of the laser power meter become 0.85
to 0.91 mW.
9. Press the YES button once more to display LD 7.0 mW $
. Check that the reading the laser power meter and digital
voltmeter satisfy the specified value.
Note down the digital voltmeter reading value.
Specified Value:
Laser power meter reading : 7.0 ± 0.2 mW
Digital voltmeter reading : Value on the optical pick-up label
±10%
10. Press the MENU/NO button to display LDPWR CHECK
and stop the laser emission.
(The MENU/NO button is effective at all times to stop the
laser emission.)
11. Turn the l AMS L knob to display Iop Write(C05).
Optical pick-up
objective lens
Laser
power mete
r
+
BD board
Digital voltmete
r
CN105 pin 1 (I +3V)
CN105 pin 2 (IOP)
KMS-260B
27X40
B0825
lOP = 82.5 mA in this case
lOP (mA) = Digital voltmeter reading (mV)/1 (
)
(Optical pick-up label)
12. Press the YES button. When the display becomes
Ref=@@@.@ (@ is an arbitrary number), press the YES
button to display Measu=@@@.@ (@ is an arbitrary
number).
13. The numbers which can be changed will blink. Input the Iop
value noted down at step 9.
To select the number : Turn the l AMS L knob.
To select the digit : Press the l AMS L knob.
14. When the YES button is pressed, Complete! will be
displayed momentarily. The value will be recorded in the non-
volatile memory and the display will become Iop Write.
Note: After step 4, each time the YES button is pressed, the display will
be switched LD 0.7 mW $ , LD 6.2 mW $ , and LD Wp
$ . Nothing needs to be performed here.
4-8. Iop NV Save
Write the reference value in the non-volatile memory for Iop
Comparer. Do not perform this operation other than when
performing the laser power adjustment while replacing the OP, etc.
and when replacing IC102 as the reference value is rewritten.
Otherwise, deterioration judgment of the OP is wrong.
Note: Perform this operation when the temperature of the optical pick-up
is almost same as the room temperature.
Operation Procedure:
1. Turn the l AMS L knob to display Iop NV Save
(C06).
2. Press the YES button to display Iop [stop].
3. After the display changes to Iop=xxsave?, press the YES
button.
4. Complete! is displayed momentarily and the display changes
to Iop 7.0mW.
5. After the display changes to Iop=yysave?, press the YES
button.
6. The Complete! message indicates that the operation has
ended.
