— 107 —
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
0印の部品，または0印付きの点線で囲まれた部品は，
安全性を維持するために重要な部品です。
従って交換時は，必ず指定の部品を使用して下さい。
< VIBRATOR >
XF300 1-760-014-11 VIBRATOR, CERAMIC (20MHz)
******************************************************************
* A-4591-309-A PSW BOARD, COMPLETE
********************
1-533-233-11 HOLDER, FUSE
< CAPACITOR >
! C901 1-117-703-11 CERAMIC 0.0047uF 99% 250V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
< FUSE >
! F901 1-532-463-51 FUSE (1A/250V) (AEP,E)
! F901 1-576-100-11 FUSE (1A/250V) (J,US,CND)
< SWITCH >
! S901 1-572-267-21 SWITCH, PUSH (AC POWER) (1 KEY)
******************************************************************
* A-4591-311-A SIRCS BOARD, COMPLETE
*********************
< CAPACITOR >
C751 1-124-589-11 ELECT 47uF 20% 16V
< CONNECTOR >
* CN750 1-566-970-11 HOUSING, CONNECTOR (PC BOARD) 8P
< DIODE >
D750 8-719-108-12 DIODE RD9.1E-W
D751 8-719-108-12 DIODE RD9.1E-W
D752 8-719-108-12 DIODE RD9.1E-W
< FERRITE BEAD >
FB751 1-410-397-21 FERRITE BEAD INDUCTOR
< IC >
IC750 8-749-011-22 IC GP1U27X
< JACK >
J750 1-815-139-11 CONNECTOR, ROUND TYPE 6P (KEYBOARD)
< RESISTOR >
R750 1-247-807-31 CARBON 100 5% 1/4W
R751 1-249-401-11 CARBON 47 5% 1/4W F
R752 1-247-807-31 CARBON 100 5% 1/4W
R753 1-247-807-31 CARBON 100 5% 1/4W
R754 1-249-421-11 CARBON 2.2K 5% 1/4W F
< SWITCH >
S750 1-771-122-11 SWITCH, SLIDE (COAX/UNBAL/BAL)
******************************************************************
MISCELLANEOUS
**************
24 1-757-252-11 WIRE, FLAT TYPE (23 CORE)
59 1-757-254-11 WIRE, FLAT TYPE (27 CORE)
60 1-757-253-11 WIRE, FLAT TYPE (23 CORE)
! 63 1-751-275-11 CORD, POWER (AEP,E)
! 63 1-783-531-41 CORD, POWER (US,CND)
! 63 1-790-345-21 CORD, POWER (J)
! F901 1-532-463-51 FUSE (1A/250V) (AEP,E)
! F901 1-576-100-11 FUSE (1A/250V) (J,US,CND)
! PT1 1-435-758-11 TRANSFORMER, POWER
******************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-476-335-11 REMOTE COMMANDER (RM-DR1J) (J)
1-476-336-11 REMOTE COMMANDER (RM-DR1E)
(US,CND,AEP,E)
! 1-569-008-21 ADAPTOR, CONVERSION 2P (AEP,E)
1-791-953-11 CORD, CONNECTION
2-347-256-03 MANUAL, INSTRUCTION (JAPANESE)
2-347-256-11 MANUAL, INSTRUCTION (US,CND,AEP,E)
**************
HARDWARE LIST
**************
#1 7-685-870-09 SCREW +BVTT 3X5 (S)
#2 7-685-872-09 SCREW +BVTT 3X8 (S)
#3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
#4 7-682-546-04 SCREW +PTT 3X5 (S)
#5 7-685-133-19 SCREW (DIA. 2.6) (IT3B)
MAIN PSW SIRCS
