2-10. SMPS BOARD
2-11. CHASSIS
2 three screws
(+PWH 3 x 8 (SUMITITE))
1 six screws
(+PWH 3 x 8 (SUMITITE))
3 SMPS board
– Rear view –
1 six screws (STEP SCREW M4)
2 one claw
2 one claw
3 chassis
– Rear view –
