67
MHC-V50/V50D
SECTION 8
ELECTRICAL PARTS LIST
A-2144-058-A BACK PARTY LIGHT L BOARD, COMPLETE
**********************************
< CONNECTOR >
CN3700 1-794-362-51 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 5P
*************************************************************
A-2144-059-A BACK PARTY LIGHT R BOARD, COMPLETE
**********************************
< CONNECTOR >
CN3701 1-794-362-51 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 5P
*************************************************************
A-2144-066-A DAMP BOARD, COMPLETE
*********************
< IC >
IC2001 6-723-247-01 IC TAS5534DGGR-S
IC2002 6-723-248-01 IC TAS5614LA-S
IC2003 6-723-248-01 IC TAS5614LA-S
*************************************************************
IR BOARD
********
< IC >
IC2200 6-600-766-01 IC PNA4823M01S0 (
)
*************************************************************
A-2144-050-A LCD BOARD, COMPLETE
********************
*************************************************************
MIC BOARD
**********
< CONNECTOR >
CN2100 1-784-923-11 PIN, CONNECTOR 7P
< DIODE >
D2100 6-502-961-01 DI DA2J10100L
D2102 6-502-961-01 DI DA2J10100L
D2104 6-500-400-01 DIODE BAV99-215
D2105 6-500-400-01 DIODE BAV99-215
< FERRITE BEAD >
FB2100 1-469-092-11 FERRITE, EMI (SMD) (1608)
FB2101 1-469-092-11 FERRITE, EMI (SMD) (1608)
< IC >
IC2100 8-759-909-71 IC BA4558F
IC3001 6-713-989-01 IC NJM2783V (TE2)
< JACK >
J2100 1-822-967-12 JACK (MIC1)
J2101 1-822-967-12 JACK (MIC2/GUITAR)
< JUMPER RESISTOR >
JR2001 1-216-296-11 SHORT CHIP 0
JR2002 1-216-296-11 SHORT CHIP 0
JR2003 1-216-296-11 SHORT CHIP 0
JR2004 1-216-296-11 SHORT CHIP 0
JR2005 1-216-864-91 SHORT CHIP 0
JR2006 1-216-296-11 SHORT CHIP 0
JR2008 1-216-296-11 SHORT CHIP 0
JR2009 1-216-296-11 SHORT CHIP 0
JR2011 1-216-296-11 SHORT CHIP 0
JR2012 1-216-296-11 SHORT CHIP 0
< TRANSISTOR >
Q2100 6-552-967-01 TR RHK005N03T146
Q2101 6-552-936-01 TR LTC014EUBFS8TL
*************************************************************
A-2181-058-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (V50)
9 A-2181-059-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (V50D: LA9)
9 A-2181-060-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (V50D: AEP, UK)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• CAPACITORS
uF: μF
• COILS
uH: μH
• Abbreviation
AUS : Australian model
CND : Canadian model
LA9 : Latin-American model
DAMP MICLCDIR
MOTHERBOARD
Note 1: When the DAMP board is replaced, spread the com-
pound referring to “NOTE OF REPLACING THE IC2002
and IC2003 ON THE DAMP BOARD AND THE COM-
PLETE DAMP BOARD” on servicing notes (page 5).
Note 2: When the complete MOTHERBOARD board is replaced,
refer to “NOTE OF REPLACING MOTHERBOARD
BOARD OR BLUETOOTH MODULE OR RC-S730 (WW)
BOARD” on page 6.
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi denti-
elles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
BACK PARTY LIGHT L
BACK PARTY LIGHT R
To Next Page
