Sony MHC-V50D - CDM Section

65
MHC-V50/V50D
7-9. CDM SECTION
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
401 2-345-115-01 SCREW (S), FLOAT
402 4-533-702-01 STEP SCREW
403 4-533-939-01 SPRING, INSULATOR (F)
404 4-533-940-01 SPRING, INSULATOR (R)
405 4-533-382-01 INSULATOR
#2 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
ns not supplied
CD mechanism section
(CDM90-DVBU204//C)
ns
403
403
405
404
404
402
401
405
402
405
402
405
402
401
ns
ns
#2
