Sony MHC-V50D - SENSOR Board (Component Side)

MHC-V50/V50D
MHC-V50/V50D
4747
6-15. PRINTED WIRING BOARD - SENSOR Board (Component Side) -
• See page 32 for Circuit Boards Location. • : Uses unleaded solder.
1
A
B
C
D
E
F
G
H
I
2 3 4 5 6 7 8 9 10 11 12 13
D1000
D1001
D1002
D1003
D1004
D1005
D1006
D1008
D1009
D1010
D1011
D1012
D1014
1-981-705-
11
(11)
SENSOR BOARD
(COMPONENT SIDE)
Note: When the SENSOR board is defective, exchange the
SERVICE, TOP PANEL ASSY.
