Sony MHC-V50D - Optical Device and Flat Cable Removal; Detaching Optical Device and Flat Cable

MHC-V50/V50D
23
2-15. SERVICE OPTICAL DEVICE (7G), FLEXIBLE FLAT CABLE
7 four insulator screws
0 connector
qa insulator
qa insulator
6 belt
3 Insert the clip etc.
5 tray
qs service, optical
device(7G)
ql
wa flexible flat cable
(24 core)
1 three claws
4
8
9
2 chuck holder assy (MB)
– Bottom view –
loading assy (MB)
qd loading base assy
w; holder, flexible flat cable
qh flexible flat cable
(5 core)
Under the guide
Under the guide
(Fold area)
1 flexible flat cable (24 core)
2 Through the hole
3 Through the hole
terminal face
loading assy (MB)
7 flexible flat cable (24 core)
6 holder, FFC
5 three claws
5 two claws
8 flexible flat
cable (5 core)
,QVWDOODWLRQRIIOH[LEOHIODWFDEOHFRUHDQGIOH[LEOHIODWFDEOHFRUH
Note: This illustration sees the loading assy (MB) from bottom side.
4
1 three claws
–5HDUYLHZ–
qk cushion (H)
qj filament tape
qg filament tape
qf cushion (H)
q; cushion (H)
qs cushion (H)
qa filament tape
9 filament tape
