Sony MHC-V50D

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MHC-V50/V50D
68
SPK RGB R
SPK RGB L
VOLUMETOP PARTY LIGHT USB
9 A-2181-062-A MOTHERBOARD BOARD, COMPLETE
(for SERVICE) (V50D: AUS)
*****************************
*************************************************************
MS-476 BOARD
************
When the MS-476 board is defective, exchange the entire CDM90 ASSY.
*************************************************************
A-2144-062-A PARTY LIGHT DRIVER BOARD, COMPLETE
**********************************
< CONNECTOR >
CN1400 1-820-112-41 CONNECTOR, FFC/FPC 9P
CN1401 1-794-362-51 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 5P
CN1402 1-794-362-51 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 5P
< IC >
IC1401 6-719-142-01 IC TC62D723FNG
*************************************************************
SENSOR BOARD
*************
When the SENSOR board is defective, exchange the SERVICE, TOP PANEL
ASSY.
*************************************************************
0 A-2144-068-A SMPS BOARD, COMPLETE
*********************
*************************************************************
A-2144-060-A SPK RGB L BOARD, COMPLETE
*************************
< CONNECTOR >
CN1700 1-573-290-21 PIN, CONNECTOR (1.5MM) (SMD) 4P
< DIODE >
* D1700 6-503-912-01 DI_LTRB R8SF
*************************************************************
A-2144-061-A SPK RGB R BOARD, COMPLETE
*************************
< CONNECTOR >
CN1750 1-573-290-21 PIN, CONNECTOR (1.5MM) (SMD) 4P
< DIODE >
* D1750 6-503-912-01 DI_LTRB R8SF
*************************************************************
A-2144-057-A TOP PARTY LIGHT BOARD, COMPLETE
*******************************
< CONNECTOR >
CN3900 1-573-290-21 PIN, CONNECTOR (1.5MM) (SMD) 4P
*************************************************************
USB BOARD
**********
< CONNECTOR >
CN1500 1-819-866-11 USB CONNECTOR (A) (
REC/PLAY 5V 1A)
< DIODE >
D1500 6-502-970-01 DI DZ2J068M0L
D1501 6-500-400-01 DIODE BAV99-215
D1502 6-500-400-01 DIODE BAV99-215
D1503 6-500-400-01 DIODE BAV99-215
*************************************************************
A-2144-056-A VOLUME BOARD, COMPLETE
***********************
< CONNECTOR >
CN1002 1-820-117-41 CONNECTOR, FFC/FPC 19P
* CN1003 1-691-591-11 PIN, CONNECTOR (1.5MM) (SMD) 8P
CN1004 1-820-112-41 CONNECTOR, FFC/FPC 9P
CN1252 1-820-125-41 CONNECTOR, FFC/FPC 29P
CN1253 1-820-112-41 CONNECTOR, FFC/FPC 9P
CN1254 1-820-113-41 CONNECTOR, FFC/FPC 11P
CN1255 1-691-550-11 PIN, CONNECTOR (1.5MM) (SMD) 3P
< DIODE >
D1211 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1212 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1213 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1214 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1215 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1216 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1217 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1218 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1219 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1220 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1221 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1222 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1223 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1224 6-504-279-01 DI HL-PST-1608H233W (WHITE)
D1225 6-504-279-01 DI HL-PST-1608H233W (WHITE)
< ROTARY ENCODER >
EN1251 1-493-008-11 ENCODER, ROTARY (VOLUME/DJ CONTROL)
< IC >
IC1000 6-719-142-01 IC TC62D723FNG
IC1001 6-719-142-01 IC TC62D723FNG
IC1003 6-719-142-01 IC TC62D723FNG
< SWITCH >
S1252 1-798-528-11 TACTILE SWITCH (1)
*************************************************************
MISCELLANEOUS
**************
0 101 1-855-006-41 FAN, DC
153 1-912-093-11 FLEXIBLE FLAT CABLE (6 CORE)
Note 2: If fl exible fl at cable is replaced, install it after bending it in
the same form as that before replacement.
MS-476
PARTY LIGHT DRIVER
SENSOR SMPS
Note 1: When the complete MOTHERBOARD board is replaced,
refer to “NOTE OF REPLACING MOTHERBOARD
BOARD OR BLUETOOTH MODULE OR RC-S730 (WW)
BOARD” on page 6.
MOTHERBOARD
