MHC-V50/V50D
31
2. The sound is not outputted
Check that the signal is input to
DAMP board IC2001 pin 24 and 27.
The sound is not outputted.
Yes
Yes
Replace FFC insert to DAMP Board
CN2004.
No
Exchange DAMP board IC2001
(6-723-247-01)
No
Exchange DAMP board IC2002
(6-723-248-01)
No
Yes
Check that the PWM signal is
outputted from the following pins.
DAMP board IC2001 pin 38, 39,
42, 43, 48 and 49.
Check that the signal is outputted
from DAMP board IC2002
pin 35 and 39 (SP FRONT R)
pin 27 and 32 (SP FRONT L)
Exchange DAMP board IC2003
(6-723-248-01)
No
Yes
Check that the signal is outputted
from DAMP board IC2003
pin 27, 32, 35 and 39
(SP WOOFER)
DAMP Mount Diagnosis Flow (2/2)
To Next Page
