Sony MVC-CD200 Service Manual

6-10
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C323 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C401 1-107-690-11 TANTAL. CHIP 6.8uF 20.00% 35V
(CD300)
C402 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
(CD300)
C403 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(CD300)
C404 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
(CD300)
C405 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(CD300)
C407 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(CD300)
C408 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(CD300)
C409 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 16V
(CD300)
C412 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(CD300)
C413 1-125-827-91 CERAMIC CHIP 1uF 10% 25V
(CD300)
< CONNECTOR >
CN203 1-785-482-41 CONNECTOR, BOARD TO BOARD 70P
* CN301 1-784-178-11 CONNECTOR, FFC (ZIF) 26P (CD200)
CN302 1-766-336-21 CONNECTOR, FFC/FPC 6P (CD300)
CN303 1-573-356-21 CONNECTOR, FFC/FPC 16P (CD300)
< DIODE >
D101 8-719-073-01 DIODE MA111-(K8).S0 (CD200)
D301 8-719-073-01 DIODE MA111-(K8).S0 (CD200)
D302 8-719-075-62 DIODE 1SS401(TE85L) (CD200)
D401 8-719-073-01 DIODE MA111-(K8).S0 (CD300)
< FERRITE BEAD >
FB101 1-414-228-11 FERRITE 0uH
FB201 1-216-797-11 METAL CHIP 10 5% 1/16W
(CD300)
* FB201 1-500-282-11 FERRITE 0uH (CD200)
FB202 1-414-228-11 FERRITE 0uH (CD300)
FB203 1-500-283-11 FERRITE 0uH
FB205 1-216-797-11 METAL CHIP 10 5% 1/16W
(CD300)
* FB205 1-500-282-11 FERRITE 0uH (CD200)
FB206 1-500-283-11 FERRITE 0uH
FB208 1-500-284-21 FERRITE 0uH
FB209 1-414-228-11 FERRITE 0uH
FB210 1-414-228-11 FERRITE 0uH
FB211 1-414-229-11 FERRITE 0uH
FB212 1-414-229-11 FERRITE 0uH
FB213 1-414-229-11 FERRITE 0uH
FB214 1-414-229-11 FERRITE 0uH
FB215 1-414-229-11 FERRITE 0uH
FB216 1-414-229-11 FERRITE 0uH
FB217 1-414-229-11 FERRITE 0uH
FB218 1-414-229-11 FERRITE 0uH
FB219 1-414-229-11 FERRITE 0uH
FB220 1-414-229-11 FERRITE 0uH
FB221 1-414-229-11 FERRITE 0uH
FB222 1-414-229-11 FERRITE 0uH
FB223 1-414-229-11 FERRITE 0uH
FB224 1-414-229-11 FERRITE 0uH
FB225 1-218-990-11 SHORT 0
FB226 1-218-990-11 SHORT 0
FB301 1-216-864-11 METAL CHIP 0 5% 1/16W
(CD300)
FB302 1-216-864-11 METAL CHIP 0 5% 1/16W
(CD300)
FB303 1-216-864-11 METAL CHIP 0 5% 1/16W
(CD300)
FB304 1-216-864-11 METAL CHIP 0 5% 1/16W
(CD300)
FB305 1-216-864-11 METAL CHIP 0 5% 1/16W
(CD300)
FB306 1-216-864-11 METAL CHIP 0 5% 1/16W
(CD300)
FB307 1-216-864-11 METAL CHIP 0 5% 1/16W
(CD300)
FB308 1-216-864-11 METAL CHIP 0 5% 1/16W
(CD300)
FB401 1-414-228-11 FERRITE 0uH (CD300)
< IC >
IC101 A-7031-236-A CCD BLOCK ASSY (CCD IMAGER) (CD200)
IC201 8-752-397-43 IC CXD2470R-T4 (CD200)
IC201 8-752-404-95 IC CXD2497R-T4 (CD300)
IC202 6-700-042-01 IC AD80044JSTRL
IC301 8-759-637-96 IC uPD16877MA-6A5-E2
IC302 8-759-637-96 IC uPD16877MA-6A5-E2
IC303 8-759-693-13 IC NJM12904V(TE2) (CD200)
IC304 8-759-681-42 IC NJM12902V(TE2) (CD200)
IC401 A-7031-268-A CCD BLOCK ASSY (CCD IMAGER) (CD300)
< COIL >
L101 1-469-528-91 INDUCTOR 100uH (CD200)
L201 1-414-756-11 INDUCTOR 47uH (CD300)
L202 1-414-756-11 INDUCTOR 47uH
L203 1-414-754-11 INDUCTOR 10uH (CD200)
L203 1-414-756-11 INDUCTOR 47uH (CD300)
L301 1-412-951-11 INDUCTOR 10uH
L302 1-414-398-11 INDUCTOR 10uH
L303 1-412-951-11 INDUCTOR 10uH
L304 1-412-951-11 INDUCTOR 10uH (CD200)
L401 1-469-528-91 INDUCTOR 100uH (CD300)
< TRANSISTOR >
Q101 8-729-037-74 TRANSISTOR UN9213J-(K8).SO (CD200)
Q102 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1(CD200)
Q301 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
(CD200)
Q302 8-729-042-26 TRANSISTOR 2SB1462J-QR(K8).SO
Q303 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
(CD200)
Q401 8-729-037-74 TRANSISTOR UN9213J-(K8).SO (CD300)
Q402 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1(CD300)
CD-334CD-333
Be sure to read “Precautions Upon Replacing CCD Imager”
on pages 4-15 (CD200) and 4-16 (CD300) when changing
the CCD imager.
