Sony MVC-CD200 Service Manual

6-11
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< RESISTOR >
R101 1-218-977-11 RES-CHIP 100K 5% 1/16W
(CD200)
R102 1-218-931-11 RES-CHIP 15 5% 1/16W
(CD200)
R103 1-218-931-11 RES-CHIP 15 5% 1/16W
(CD200)
R104 1-218-939-11 RES-CHIP 68 5% 1/16W
(CD200)
R105 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
(CD200)
R106 1-208-643-11 RES-CHIP 22 5% 1/16W
(CD200)
R107 1-218-981-11 RES-CHIP 220K 5% 1/16W
(CD200)
R108 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
(CD200)
R201 1-216-864-11 METAL CHIP 0 5% 1/16W
(CD200)
R202 1-218-941-11 RES-CHIP 100 5% 1/16W
R203 1-218-941-11 RES-CHIP 100 5% 1/16W
(CD300)
R203 1-218-945-11 RES-CHIP 220 5% 1/16W
(CD200)
R206 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R207 1-218-941-11 RES-CHIP 100 5% 1/16W
R211 1-218-953-11 RES-CHIP 1K 5% 1/16W
R212 1-218-945-11 RES-CHIP 220 5% 1/16W
R214 1-218-945-11 RES-CHIP 220 5% 1/16W
R216 1-218-990-11 SHORT 0 (CD200)
R217 1-218-990-11 SHORT 0 (CD200)
R219 1-218-977-11 RES-CHIP 100K 5% 1/16W
R221 1-218-943-11 RES-CHIP 150 5% 1/16W
R222 1-218-943-11 RES-CHIP 150 5% 1/16W
R223 1-218-943-11 RES-CHIP 150 5% 1/16W
R224 1-218-943-11 RES-CHIP 150 5% 1/16W
R225 1-218-943-11 RES-CHIP 150 5% 1/16W
R226 1-218-943-11 RES-CHIP 150 5% 1/16W
R227 1-218-943-11 RES-CHIP 150 5% 1/16W
R228 1-218-943-11 RES-CHIP 150 5% 1/16W
R229 1-218-943-11 RES-CHIP 150 5% 1/16W
R230 1-218-943-11 RES-CHIP 150 5% 1/16W
R231 1-218-943-11 RES-CHIP 150 5% 1/16W
R232 1-218-943-11 RES-CHIP 150 5% 1/16W
R233 1-218-943-11 RES-CHIP 150 5% 1/16W
R234 1-218-943-11 RES-CHIP 150 5% 1/16W
R239 1-218-953-11 RES-CHIP 1K 5% 1/16W
R240 1-218-953-11 RES-CHIP 1K 5% 1/16W
R241 1-218-953-11 RES-CHIP 1K 5% 1/16W
R242 1-218-990-11 SHORT 0
R244 1-208-635-11 RES-CHIP 10 5% 1/16W
R246 1-218-990-11 SHORT 0 (CD300)
R247 1-218-990-11 SHORT 0 (CD200)
R250 1-218-953-11 RES-CHIP 1K 5% 1/16W
R303 1-216-797-11 METAL CHIP 10 5% 1/16W
(CD200)
R304 1-218-953-11 RES-CHIP 1K 5% 1/16W
(CD200)
R305 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R306 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
(CD200)
R307 1-218-977-11 RES-CHIP 100K 5% 1/16W
(CD200)
R308 1-218-965-11 RES-CHIP 10K 5% 1/16W
(CD200)
R309 1-218-977-11 RES-CHIP 100K 5% 1/16W
(CD200)
R310 1-218-974-11 RES-CHIP 56K 5% 1/16W
(CD300)
R311 1-218-975-11 RES-CHIP 68K 5% 1/16W
(CD200)
R312 1-218-973-11 RES-CHIP 47K 5% 1/16W
(CD200)
R313 1-218-974-11 RES-CHIP 56K 5% 1/16W
(CD300)
R314 1-218-947-11 RES-CHIP 330 5% 1/16W
(CD200)
R315 1-218-973-11 RES-CHIP 47K 5% 1/16W
(CD200)
R316 1-218-980-11 RES-CHIP 180K 5% 1/16W
(CD200)
R317 1-218-975-11 RES-CHIP 68K 5% 1/16W
(CD200)
R318 1-218-980-11 RES-CHIP 180K 5% 1/16W
(CD200)
R319 1-218-969-11 RES-CHIP 22K 5% 1/16W
(CD200)
R320 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
(CD200)
R321 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
(CD200)
R322 1-218-966-11 RES-CHIP 12K 5% 1/16W
(CD200)
R323 1-218-980-11 RES-CHIP 180K 5% 1/16W
(CD200)
R324 1-208-712-11 METAL CHIP 16K 0.5% 1/16W
(CD200)
R325 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
(CD200)
R326 1-218-969-11 RES-CHIP 22K 5% 1/16W
(CD200)
R327 1-218-977-11 RES-CHIP 100K 5% 1/16W
(CD200)
R328 1-218-977-11 RES-CHIP 100K 5% 1/16W
(CD200)
R329 1-218-965-11 RES-CHIP 10K 5% 1/16W
(CD200)
R330 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
(CD200)
R332 1-218-973-11 RES-CHIP 47K 5% 1/16W
R333 1-218-944-11 RES-CHIP 180 5% 1/16W
(CD300)
R334 1-218-944-11 RES-CHIP 180 5% 1/16W
(CD300)
R335 1-218-990-11 SHORT 0
R336 1-218-990-11 SHORT 0
R401 1-218-990-11 SHORT 0 (CD300)
R402 1-218-990-11 SHORT 0 (CD300)
R403 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
(CD300)
R404 1-218-989-11 RES-CHIP 1M 5% 1/16W
(CD300)
R406 1-218-939-11 RES-CHIP 68 5% 1/16W
(CD300)
